Overview
20
1
2
3
4
5
6
7
1 Machine handle
2 cord strain relief
3 Power outlet max. strain 700W
4 Power cord
5 Guide rod
6 Cable mount
7 pad holder
8 Additional equipment holder
9 transport wheels
10 Protecting ring
5
19
18
17
8
16
15
14
9
10
11 Castor
12 Motor covering
13 Motor ventilation
14 guide rod
15 Safety switch
16 Right lever (Motor ON/OFF)
17 Display ON (plug is in power outlet)
18 Tool holder (pads)
19 Pushbutton for electrical spray unit
20 Left lever (Motor ON/OFF)
