Summary of Contents for Audix M40
- Page 1 AUDIX M40 INSTALLATION GUIDE Thank you for choosing Audix! Our products are designed to provide you with many years of reliable service. Please read this manual before using the system for optimal installation and operation.
- Page 2 OPEN JMB40 BOX LID AND PLACE BOX ON TOP OF 5/8 INCH HOLE IN THE CEILING TILE. (SEE #1) • PLACE JBM40 BOX OVER THE CEILING TILE 5/8 INCH HOLE. • INSERT M40 THREADED CEILING MOUNT THROUGH CEILING TILE AND INTO THE JBM40 BOX • SECURELY TIGHTEN THE KNURLED NUT. (SEE #2) •...
- Page 3 INSTALLATION AND WIRING INSTRUCTIONS FOR AUDIX M40 CEILING MICROPHONES Open lid of JBM40 box and Insert ceiling mount through ceil- place on top of ceiling tile ing tile hole, and into JBM40 box drilled hole. then tighten the knurled nut.
- Page 4 SEISMIC RESTRAINT INSTRUCTIONS CABLE EXPLODED VIEW: PLENUM RATED CABLE PLENUM RATED BOX Wrap the cable around a beam, eyebolt or hanger. Next, slip the cable through the top of cable stay barrel pulling excess cable until taut. CABLE STAY CABLE RELEASE BARREL PUSH PIN IN TO RELEASE...
