Standard Module Details

Master Controller & Motherboard:
The master controller mounts in Slot 4 of a two slot
motherboard (Slots 3 and 4 of the Master Controller Bay)
and provides a standard RUI communications channel,
selectable as Style 4 or Style 7, available at Slot 4
RUI communications control up to 31 remote
annunciators per channel including the 4603-9101 LCD
Annunciator, the 4602-9101 Status Command Unit
(SCU), and 4602-9102 Remote Command Unit (RCU)
Up to four RUI channels are allowed (use 4100-1291 as
required)
A Network Interface Module is mounted in Slot 3
Optional Service Modem 4100-6030 mounts onto the
master controller board with its own on-board
connections
System Power Supply:
Rating is 9 A total, including module currents
Outputs are power-limited, except for the battery charger

NDU Equipment Selection

Network Display Unit, Non-Voice
Model Model Type/Listing
4100-9141 120 VAC Input
4100-9143 Canadian, English
4100-9144 Canadian, French
4100-9241 220-240 VAC Input
Network Display Unit with Voice Command Center (VCC)
Model Model Type/Listing
4100-9142 120 VAC Input
4100-9145 Canadian, English
4100-9146 Canadian, French
4100-9242 220-240 VAC Input

NDU, or NDU with VCC Communication Modules

Model Description
4100-6056 Wired Network Media Card
4100-6057 Fiber Optic Media Card
Network Access Dial-in Service Modem, mounts to supplied Network Interface Module,
4100-6055
requires telephone line connection
4100-1291 Remote Unit Interface Module (RUI); up to three maximum per control panel
Service Port Modem for local panel access only, mounts to Master Controller Module,
4100-6030
requires telephone line connection, accesses same information as front panel port
4100-6031 City Circuit, with disconnect switches
4100-6032 City Circuit, without disconnect switches
4100-6033 Alarm Relay, 3 Form C relays, 2 A @ 32 VDC (one per RPS)
4100-6038 Dual RS-232 Interface; 3 maximum; can mount in Slot 3 or Slot 2 of Master Controller
4100-6052 DACT, Point or Event Reporting; includes 2, 14 ft (4.3 m) DACT cables
4100-6036 Physical Bridge, Style 4, includes 1 modem module and 2 wired modules
4100-6037 Physical Bridge, Style 7, includes 2 modem and 2 wired modules
4100-0156 8 VDC Converter, required for multiple Physical Bridge Modules; 3 A @ 8 VDC maximum
4100-9816 Master Clock Interface Module with one standard RS-232 port (see S4100-0033)
4100-1290 24 Point I/O Module for external connections, select each point as either input or output
Description
UL 4100U NDU with Master Controller, LCD and operator interface,
Network Interface Module (select media card separately), 9 A system
ULC
power supply/battery charger, and external RUI communications interface
ULC
(power supply/battery charger is an SPS with its IDNet™ channel and
UL NACs disabled)
Description
UL 4100U NDU with VCC includes the first bay equipment described for the
NDU (above) and a second bay assembly with separate: Master
ULC
Controller for voice functions, Network Interface (select media card
ULC
separately), and a standard SPS with 250 point IDNet channel; and 3, 3 A
UL
Class A/B NACs capable of SmartSync™ two-wire operation
Select per Network connection requirements, two media
cards are required per network interface; mounts on the
supplied Network Interface Module(s)
For use with SPS
only, not RPS
System Power Supply (Continued):
Provides system power, battery charging, auxiliary power,
earth detection, and provisions for either an optional City
Connect Module or an optional Alarm Relay Module
Dual rate, temperature compensated battery charger
charges up to 50 Ah sealed lead-acid batteries mounted
in the battery compartment; charger is UL listed for
charging up to 110 Ah batteries mounted in an external
cabinet (refer to data sheet S2081-0012 for details)
Performs battery monitor including low battery warning
Provides status information to the master controller and
analog values for battery voltage, charger voltage and
current, and actual system voltage and current
2 A Auxiliary Power Output
reset, door holder, or coded output operation
Optional City Connect Module
disconnect switches, or 4100-6032, without disconnect
switches) can be selected for conventional dual circuit
city connections
Optional Alarm Relay Module
three Form C relays that are used for Alarm, Trouble,
and Supervisory, rated 2 A resistive @ 32 VDC
Select one per
SPS (mounts on
SPS/RPS)
4
is selectable for detector
(4100-6031, with
(4100-6033) provides
Battery Current
Supv. Alarm
419 mA 476 mA
see below for
selected Network
Media Card current
Battery Current
Supv. Alarm
828 mA 947 mA
see below for
selected Network
Media Card current
Battery Current
Module
Size
Supv. Alarm
N.A. 55 mA 55 mA
N.A. 25 mA 25 mA
N.A. 75 mA 75 mA
1 Slot 85 mA 85 mA
N.A. 70 mA 70 mA
N.A. 20 mA 36 mA
N.A. 20 mA 36 mA
N.A. 15 mA 37 mA
1 Slot 132 mA 132 mA
1 Slot 30 mA 40 mA
1 Slot 260 mA 260 mA
2 Slots 304 mA 304 mA
1 Block 1.5 A maximum
1 Slot 132 mA 132 mA
1 Slot (see S4100-0032)
