Install Instructions For:
RF122-150
Speaker will fit 2 cubic foot backcans/grilles from:
AMK, Atlas, Elkay, Lowell, Quam and others

Box contents

1 Speaker
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
VC/ Transformer
selector switch
Euroblock jack
