SoundTube Surface-Mount Speaker SM590i Specifications

SM590i
Specifications: SM590i
System Type
1
Frequency Response (- 3 dB)
Low Frequnecy (-10 dB) 1
Max. Program Power
Max. Continuous Power RMS 2
Max. SPL dB @ 1 M
3
Sensitivity dB @ 1W/1M
Impedance (nominal)
Coverage Angle (-6 dB @ 500 Hz)
Coverage Angle (-6 dB @ 4 kHz)
Directivity Factor (Q)
Directivity Index (DI)
Tap Selector
Transformer Taps
70.7 V Output 100 V
33 W 104.5 dB 33 W
17 W 102 dB 17 W
9 W 99 dB 9 W
6 W 97.5 dB 6 W
3 W 97.5 dB
Transducers
Low Frequency Driver
High Frequency Driver
Low Frequency Voice Coil
Crossover Frequency
Network Type
Low Pass
High Pass
Enclosure Material
Motor Board
Grille
Inputs
Colors
Length
Height
Width (including bracket)
Weight
Shipping Weight
Accessories
Included
Optional
Packaging
1 Frequency response is measured in half space and includes a low-frequency peak > + 3 dB.
2
Continuous power rating, EIA-426-B test.
3 2.83 Volts at a distance of 1 meter.
SoundTube continually develops new product innovations and improvements. Updates to existing
products without prior notice are an example of SoundTube's drive for constant improvement.
© 2006 SoundTube Entertainment. All rights reserved. PN TS-SM590 REV 03.03.06
Surface-Mount Speaker
Preliminary Technical Information for System Engineers
5.25" Coax, open-ceiling, ported (33 Watt transformer for
25/70.7/100 Volt or voice coil / 8 Ohm direct)
71 Hz - 22 kHz
61 Hz - 20 kHz
160 Watts
80 Watts
108.5 dB
89.5 dB
8 Ohm (nominal value)
166º (average)
88º (average)
5.69 (Averaged 100 Hz - 10 kHz); 5.87 @ 2 kHz
6.12 dB (Averaged 100 Hz - 10 kHz); 7.69 dB @ 2 kHz
6-Position rotary switch with voice coil direct (8 Ohm)
Output 25 V Output
104.5 dB 5 W 96.5 dB
102 dB 2.5 W 93.5 dB
99 dB 1.3 W 90.5 dB
97.5 dB 0.63 W 87.5 dB
1 x 133 mm (5.25 in) Polypropylene cone, butyl rubber surround
25 mm (1.0 in) Convex aluminum horn-loaded tweeter
25 mm (1.0 in)
3 kHz
N/A
12 dB per octave, 2nd order
Drawn aluminum backcan with ABS baffle
Cast aluminum
Iridite-plated steel with powder-coat finish
4 Pin, 5 mm Euroblock for individual or daisy chain connection
Black or white
305.1 mm / 12.01 in
316.9 mm / 12.48 in
216.6mm / 8.53 in
4.3 kG / 9.5 lbs
10 kG / 22.0 lbs (2 per box)
Hanging hardware, Euroblock connector & terminal
weather boot
U-Mount Bracket (AC-SM-UB5), Pole Mount Adaptor
(AC-SM-PMA5), Bent Shaft (AC-SM-BS5)
2 Per box, can ship as single
Mounting hardware included
Key Features
• High-power output (108.5 dB) for longer
throw and higher SPL requirements.
• One 133 mm (5.25 in) polypropylene
woofer and one 25 mm (1.0 in) horn-
loaded convex aluminum dome tweeter
mounted to a proprietary cast-alumi-
num HP5 baffle & heat sink.
TM
• 89.5 dB Average sensitivity offers high
output capabilities and reduced amplifi-
cation costs.
• Weatherized components for indoor/
outdoor applications. Includes a
tool-free SpeedLever captured ball
TM
mounting system for a fast & secure
installation.
• Included accessories: Mounting hard-
ware, Euroblock connector & terminal
weather boot.
• Vertical and horizontal pivoting offer
precision aiming for indoor & outdoor
applications.
• Easy access 6-position selectable tap
switch for 25, 70.7 & 100 Volt applica-
tions with voice coil/8 Ohm direct sim-
plifies ordering and inventory tracking.
• Optional accessories: Pole-Mount Adap-
tor, Bent Shaft, U-Bracket.
• High quality black or white paint finish.
Description
The SM590i is a high-powered 5.25"
2-way horn-loaded loudspeaker in a ported
surface-mount enclosure design. The SM590i
incorporates a low-profile grille, proprietary
HP5 motor-board and 6-position tap
TM
switch with voice coil/8 Ohm direct. Hang-
ing hardware is included and features a
fast-action Speed-Lever for easy and secure
TM
installation with a proprietary captured ball
mounting system. Optional accessories
include a pole mount adaptor, a bent shaft
and a u-bracket.
Applications
Engineered for high-SPL and effective
low-end response (61 Hz @ - 10 dB), the
SM590i delivers consistent high-perfor-
mance music and paging for applications
requiring longer throw or higher volume
above the existing ambient noise level.
The SM590i is ideal for suface-mount
sound reinforcement/PA in applications
with high ambient noise levels including
casinos, warehouses, airports, transporta-
