RF31-EZ-T
Box contents
1 Speaker
1 Grille
1 Paint mask
4 Mounting screws
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Install Instructions For:
RF31-EZ-T speaker
Optional Accessories
Theft-resistant, stainless steel
grille (AC-RF31-TRG)
NOTE: the RF31-EZ-T is designed to install
into a standard 2-gang junction box.
SoundTube recommends you test the fit
before installing the junction box.
© 2010 SoundTube Entertainment, Inc. All rights reserved. PN INS-RF-31-T Rev 09.7.10
Warning
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Advertisement
Table of Contents
Related Manuals for SoundTube RF31-EZ-T
Summary of Contents for SoundTube RF31-EZ-T
- Page 1 Warning Warning SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for Do not spec or install speaker near support beam, ventilation duct or optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
- Page 2 RF31-EZ-T Installation Instructions For: 1.435.647.9555 800.647.TUBE www.soundtube.com RF31-EZ-T speaker Terminal 100v 70.7v Ground Ground Ground 1.3w 0.7w 2.5w 0.4w 2.5w 1.3w 0.2w 1. Unpack speaker. 2. Connect signal wires to 2a. Terminal Settings speaker using terminal block. Connect - wire to "C".
