SoundTube DS31-EZ Install Instructions

DS31-EZ

Box contents

(1) Speaker assembly
(1) Cylindrical or Tapered sleeve
(2) Safety cables
(2) Speed clamps
(5) Zip ties
(1) Magnetic grille
(1) Mounting Assembly
(2) Mounting screws
(2) 2.25" sleeve screws
(2) 0.50" screws
(2) Wire nuts
Mounting screws (2)
Tapered Sleeve
Speaker
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Install Instructions For:
DS31-EZ
Safety leash
Grille
Dual-Gang Junction Box (not included)
Mounting plate
Adjustment loop
Cover plate
1.435.647.9555
© 2021 SoundTube Entertainment, Inc. All rights reserved. PN INS-DS31-EZ Rev 12.01.21
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Tap Settings
Tapered Sleeve
Cylindrical Sleeve
(two pieces)
|
800.647.TUBE
Warning
|
