FP633
FP633
Sound-Focusing Speaker
Technical Information for System Engineers
Specifications:
FP633-4 & FP633-T32
System Type
1
Frequency Response (-3 dB)
1
Frequency Response (-6 dB)
1
Low Frequency (-10 dB)
Max. Program Power
2
Max. Continuous Power RMS
Max. SPL dB @ .5M
3
Sensitivity dB @ 1W/0.5M
Impedance
Tap Selector
Transformer Taps
70.7 V
Output
100 V
32 W
109 dB
16 W
106 dB
32 W
8 W
103 dB
16 W
4 W
100 dB
8 W
Coverage Angle (-6 dB)
Directivity Factor (Q)
Directivity Index (DI)
Transducers
Low Frequency Driver
High Frequency Driver
Crossover Frequency
Network Type
Inputs
Dome Material
Enclosure Material
Colors
Dome Diameter
Total Height
Weight
Shipping Weight
Optional Accessories
1
Frequency response is measured in full space.
2
Continuous power rating, EIA-426-B test.
3
2.0 Volts at a distance of 0.5 meters.
SoundTube continually develops new product innovations and improvements. Updates to existing
products without prior notice are an example of SoundTube's drive for constant improvement.
© 2004 SoundTube Entertainment, Inc. All rights reserved. REV 07.20.04
5.25" 2-way mono high-directivity (voice coil/4 Ohm
direct or 32 Watt transformer for 70.7/100V applications)
140 Hz – 13.2 kHz
120 Hz – 14.2 kHz
95 Hz – 20 kHz
100 W
50 W
111 dB
91 dB
4 Ohm (nominal value). The FP633-4 is a 4 Ohm product.
Tap setting must be specified at time of order.
Output
n/a
n/a
109 dB
106 dB
103 dB
22º @ 2 kHz
68.11 (100 Hz to 10 kHz averaged) 125 @ 2 kHz
14.51 dB (100 Hz to 10 kHz averaged) 21 dB @ 2 kHz
1 x 133 mm (5.25 in) Polypropylene cone,
butyl rubber surround
1 x 25 mm (1.0 in) Polypropylene balance dome
5 kHz
1st Order series
Corrosion resistant binding post
Custom molded PETG clear dome
Polyethylene driver enclosure
Clear, custom translucent & opaque colors available
781 mm (30.75 in)
376 mm (14.80 in)
5.2 kG (11.45 lbs)
9.1 kG (20.0 lbs)
SoundSleeves™ & Wall Mount Bracket
Key Features
• Patented Dual-Parabolic
control technology delivers precise audio
coverage.
• 781 mm (30.75 in) Custom-molded PETG
clear polymer dome. Custom-colors
available.
• One 133 mm (5.25 in) polypropylene
woofer and one 25 mm (1.0 in) poly-
propylene balanced dome tweeter
®
with FerroFluid
cooling.
™
• Patented ZeroReflection
sure for accurate sound reproduction
• Narrow 22° coverage angle for sharp
focus.
• Single point balanced mounting for
easier and cleaner-looking installs.
• Shipped fully assembled; bulk shipping
available upon customer request.
• Optional wall-mount bracket available.
• Custom colors and printed decorative
and promotional dome covers optional.
Applications
The SoundTube FP633 uses patented
™
Dual-Parabolic
dome technology for con-
tained music & messaging in venues
requiring a targeted hot spot for 1-3 lis-
teners. With full-range sound, enhanced
bass response and a Max SPL of 111 dB
(@ 0.5 M), the FP633 is the ideal choice for
focused audio solutions in louder ambient
noise applications, including kiosks, P.O.P.
displays, education, trade shows, plasma
displays and sports bars.
Patented Dual-Parabolic™
Technology
SoundTube Entertainment is constantly
developing new technologies that enhance
audio product performance. SoundTube
Entertainment's innovations are protected
by multiple U.S. & international patents,
which explicitly cover SoundTube dome,
enclosure and dispersion technologies.
SoundTube Entertainment actively defends
its patents in order to protect SoundTube
resellers and end users.
Technical Data
SoundTube Entertainment strives to pro-
vide complete and effective technical infor-
mation and data to dealers, engineers
and designers. All data are available
™
dispersion
driver enclo-
