Do not connect a power source to the DC input jack while the MoCoBus connector is
in-use if the power source is running at a different voltage than the MoCoBus.

3.1.3. USB Connector

The USB connector can be used when connected to a computer or a powered hub, for powering
the MX3 alone. This can be useful for setting up the MX3, or using it as an intervalometer alone.
Motors cannot be used with USB power, this 5V source is not enough power to drive
motors. The controller will reset if motors are turned on under USB power.
