7.7. Manual Motor Control

There are times when you'll want to manually position an axis, such as during initial shot setup,
testing framing, and more. You can take manual control over a motor in the Manual Move action
within the Motor Sub-menu. In the manual move screen, you'll see a speed displayed. You can
use [Up] and [Down] to change the movement speed. Pressing
in that direction, and pressing
move action, simply press
Menu Navigation:
1. [Enter] to enter the Main System Menu
2. [Up] or [Down] until Motors is selected
3. [Enter] to enter Motors menu
4. [Up] or [Down] until correct axis is selected
5. [Enter] to enter axis menu
6. [Up] or [Down] until Manual Move is selected
7. [Enter] to activate the Manual Move screen
8. [Enter] to exit the Manual Move screen

7.8. Swapping Directions

If you find that Left and Right (or Clockwise and Counter-Clockwise for rotary axes) are
consistently backwards from how you expect them to operate for a given axis, you could turn the
whole rig around - or, better yet, invert the directions for that axis. Each axis can have its
direction display inverted by setting the Invert Dir parameter within the motor sub-menu. Set this
to 'on' to flip directions around, or 'off' to leave them as-is.
Menu Navigation:
Asymmetric Ramp is Set
[Left] or [Right] again will stop movement. To exit the manual
[Enter] to return to the motor sub-menu.
All Contents licensed under the Creative Commons Attribution Share-Alike 3.0 License
[Left] or [Right] will begin moving
Page 29 of 45
Copyright © 2013 Dynamic Perception LLC
