Changing The Input Trigger Type - Dynamic Perception MX3 User Manual

● Start
○ Start the program running, does nothing if it's already running
● Stop
○ Stop the program running, does nothing if it's already stopped
● Toggle
○ Toggles run status: stops the program if its running, and starts it if its stopped
● Ext. Int
○ Provide an external interval signal, uses this signal instead of the internal
intervalometer
● Dir.
○ Switch directions for any moving motors
The action to take for any specific input can be set by first going to the Main System menu, then
to the Settings menu, and then to the Aux I/O menu and selecting the correct Aux I/O Mode.
The Aux I/O Mode parameters allow you to set the Aux I/O line as an input or output
based on the parameter value.
You must run the Init I/O action from the Aux I/O menu after making any changes to
the mode for any of the Aux I/O lines.
Menu Navigation:
1. [Enter] to enter the Main System Menu
2. [Up] or [Down] until Settings is selected
3. [Enter] to enter Settings menu
4. [Up] or [Down] until Aux I/O is selected
5. [Enter] to enter Aux I/O menu
6. [Up] or [Down] until correct I/O Mode is selected
7. [Enter] to edit the I/O Mode parameter
8. [Up] or [Down] to change the parameter value
9. [Enter] to save the parameter value
10. [Up] or [Down] to select Init I/O
11. [Enter] to run to the Init I/O action
12. [Enter] to exit the Init I/O screen when it says Done
