11. System Settings

Some advanced system settings are available, should they need to be changed.

11.1. Metric Display

Linear motion speeds can be displayed either in Inches (default), or Centimeters. To switch
between inches and cm for linear motor speed displays, use the Metric Display parameter in the
main settings menu.
Menu Navigation:
1. [Enter] to enter the Main System Menu
2. [Up] or [Down] until Settings is selected
3. [Enter] to enter Settings menu
4. [Up] or [Down] until Metric Display is selected
5. [Enter] to edit the Metric Display parameter
6. [Up] or [Down] to change the parameter value
7. [Enter] to save the parameter value
Only linear motion speeds are displayed in inches or cm, rotary motion speeds are
always displayed in degrees.

11.1. LCD Backlight Auto-Off

The LCD backlight is designed to automatically turn off after a period of time, to preserve energy.
You can extend or reduce the amount of time it takes before the backlight turns off via the LCD
AutoOff Sec parameter (in seconds), in the Settings menu.
Menu Navigation:
1. [Enter] to enter the Main System Menu
2. [Up] or [Down] until Settings is selected
3. [Enter] to enter Settings menu
4. [Up] or [Down] until LCD AutoOff Sec. is selected
5. [Enter] to edit the LCD AutoOff Sec. parameter
6. [Up] or [Down] to change the parameter value
