All out before triggers share the same parameter values, you may not configure each
out before trigger individually.
Out before triggers are executed before focus control.

9.3.2. Out After Exposure

When output after exposure is chosen, you can control how long after the exposure the output is
triggered with the Out Aft Time parameter (in milliseconds), and you can control how long the
output is triggered for with the Out Aft Trig mS (in milliseconds) parameter. Both parameters are
available in the Aux I/O menu.
All out after triggers share the same parameter values, you may not configure each
out before trigger individually.
Out after triggers are executed after exposure delay.
Out after triggers are sent after all exposure repeats have been completed, not
between exposure repeats.

9.3.3. Changing the Output Level

Different devices may require different signals to register the trigger, some devices may require
a high signal (+5VDC), whereas others may require a low signal (GND). You can change the
output level for all outputs using the Out Level parameter in the Aux I/O Menu.
All outputs share the same output level, you cannot configure each output
individually.
