- Page 1 Operating Guide EPIA-P720 Mainboard...
-
Page 2: Table Of Contents
Configuration 4 ....................................8 Boot to Idle......................................... 9 Stress Tool........................................9 3DMark2003....................................... 9 PowerDVD 6.0......................................9 Power Specifications....................................10 VIA EPIA-P720 Microsoft and Linux Driver Support ........................11 Microsoft Driver Support ..................................11 Linux Driver Support .....................................11 Contact Information ....................................12 June 24, 2013 - i -... -
Page 3: Via Epia-P720 Overview
VIA Padlock Security Engine, VIA CoolStream™ Architecture, VIA StepAhead™ Technology Suite, and VIA TwinTurbo™ technology. The VIA EPIA-P720 delivers the performance levels with its included sizeable support of up to 2 GB of 800 MHz DDR2 memory and native support for SATA 3Gb/s storage devices. -
Page 4: Layout Diagrams
EPIA-P720 Operating Guide Layout Diagrams EPIA-P720 ( TOP AND BOTTOM VIEWS June 24, 2013 - 3 - Version 1.06... -
Page 5: Via Epia-P720 Specifications
EPIA-P720 Operating Guide VIA EPIA-P720 Specifications Model Name EPIA-P720-10E Processor VIA Eden ULV 1 GHz NanoBGA2 processor Chipset VIA VX855 All-in-One System Processor System Memory - 1 x DDR2 800/667 SODIMM socket - Up to 2 GB memory size - VIA Chrome™ 9 HCM DX9 Integrated Graphics with MPEG-2 accelerators Onboard Storage - 1 x IDE 2.0 mm 44-pin connector... -
Page 6: Via Epia-P720 Processor Sku
EPIA-P720 Operating Guide VIA EPIA-P720 Processor SKU The VIA EPIA-P720 Pico-ITX mainboard is available in the following speed grades: • 1.0 GHz VIA Eden ULV NanoBGA2 Processor June 24, 2013 - 5 - Version 1.06... -
Page 7: Via Epia-P720 Dimensions & Mounting Holes
EPIA-P720 Operating Guide VIA EPIA-P720 Dimensions & Mounting Holes Note: The mounting holes at the four corners can only fit M2 size screws (Ø1.86 mm – Ø1.89 mm). June 24, 2013 - 6 - Version 1.06... -
Page 8: Via Epia-P720 Height Distribution
EPIA-P720 Operating Guide VIA EPIA-P720 Height Distribution June 24, 2013 - 7 - Version 1.06... -
Page 9: Power Consumption
EPIA-P720 Operating Guide Power Consumption Power consumption tests were performed on eight different configurations. The following tables show the mainboard’s voltage, amp and wattage values while running common applications in the Windows XP environment. ESTED ONFIGURATIONS Configuration 1 • VIA Eden ULV 1 GHz NanoBGA2 Processor with 533 MHz FSB •... -
Page 10: Boot To Idle
EPIA-P720 Operating Guide OOT TO Measured Voltage Measure Amp Watts Configuration 1 11.997 0.89 10.677 Configuration 2 11.997 1.34 16.076 Configuration 3 11.997 0.66 7.918 Configuration 4 11.997 0.75 8.998 TRESS Measured Voltage Measure Amp Watts Configuration 1 11.997 1.00 11.997... -
Page 11: Power Specifications
EPIA-P720 Operating Guide Power Specifications The VIA EPIA-P720 Pico-ITX mainboard utilizes a +12V DC-in power connector for providing power to the mainboard. The dimensions of the DC-in port are show in the figure below. June 24, 2013 - 10 -... -
Page 12: Via Epia-P720 Microsoft And Linux Driver Support
RIVER UPPORT The VIA EPIA-P720 Pico-ITX mainboard is compatible with Microsoft operating systems. The latest Windows XP drivers can be downloaded from the VIA Embedded website at www.viaembedded.com. For embedded operating systems (Windows XP Embedded), the related drivers can be found in the VIA Arena website at www.viaarena.com. -
Page 13: Contact Information
EPIA-P720 Operating Guide Contact Information For more information on the VIA EPIA-P720 Pico-ITX mainboard contact your sales representative or visit our website at www.viaembedded.com. Taiwan Headquarters Europe 1F, 531 Zhong-Zheng Road 940 Mission Court In den Dauen 6 Xindian District, New Taipei City 231,...
