- Page 1 Operating Guide EPIA-P710 Mainboard March 21, 2018 Version 1.01...
-
Page 2: Table Of Contents
Configuration 6 ......................13 Boot to Idle ........................14 3DMark2001 SE ......................14 Power Specifications ......................15 VIA EPIA-P710 Microsoft and Linux Driver Support ..............16 Microsoft Driver Support....................16 Linux Driver Support ......................16 Contact ..........................17 March 21, 2018 - i - Version 1.01... -
Page 3: Via Epia-P710 Overview
StepAhead™ Technology Suite, and VIA TwinTurbo™ technology. The VIA EPIA-P710 delivers the performance levels with its included sizeable support of up to 2 GB of 667 MHz DDR2 memory and native support for SATA 3Gb/s storage devices. In addition to EPIA-P710 is highly extensible. -
Page 4: Layout Diagrams
EPIA-P710 Operating Guide Layout Diagrams EPIA-P710 ( TOP AND BOTTOM VIEWS Item Function GigaLAN pin header connector Front panel pin header Front audio pin header VGA pin header Clear CMOS jumper LVDS power Selector DC-In power connector LVDS connector SUMIT QMS connector (Bank B) - Page 5 EPIA-P710 Operating Guide Item Function PS/2 KBMS connector Memory slot (DDR2 SODIMM) SATA power connector BAT1 CMOS Battery connector March 21, 2018 - 4 - Version 1.01...
-
Page 6: P710-A (Top And Bottom Views)
EPIA-P710 Operating Guide P710-A ( TOP AND BOTTOM VIEWS Item Function LPC pin header USB port USB port COM Port pin header SPI connector PCIE1 PCIe 1-Lane socket PCIE2 PCIe 4-Lane slot PCIE3 PCIe 1-Lane slot March 21, 2018 - 5 -... - Page 7 EPIA-P710 Operating Guide Item Function SUMIT QFS connector (Bank B) SUMIT QFS connector (Bank A) March 21, 2018 - 6 - Version 1.01...
-
Page 8: P710-B (Top And Bottom Views)
EPIA-P710 Operating Guide P710-B ( TOP AND BOTTOM VIEWS March 21, 2018 - 7 - Version 1.01... -
Page 9: Via Epia-P710 Specifications
Specifications subject to change without notice. The EPIA-P710-B LAN port accessory board is highly recommended to maintain the LAN performance. SUMIT interface supports up to three USB 2.0, one LPC, two x1 PCIe, one x4 PCIe, SMBus, and SPI interfaces. -
Page 10: Via Epia-P710 Processor Sku
EPIA-P710 Operating Guide VIA EPIA-P710 Processor SKU The VIA EPIA-P710 Pico-ITXe mainboard is available in the following speed grades: • 1.0 GHz VIA C7 NanoBGA2 Processor March 21, 2018 - 9 - Version 1.01... -
Page 11: Via Epia-P710 Dimensions & Mounting Holes
EPIA-P710 Operating Guide VIA EPIA-P710 Dimensions & Mounting Holes March 21, 2018 - 10 - Version 1.01... -
Page 12: P710-A I/O Board Dimensions
EPIA-P710 Operating Guide P710-A I/O Board Dimensions March 21, 2018 - 11 - Version 1.01... -
Page 13: P710-B Lan Module Dimensions
EPIA-P710 Operating Guide P710-B LAN Module Dimensions March 21, 2018 - 12 - Version 1.01... -
Page 14: Power Consumption
EPIA-P710 Operating Guide Power Consumption Power consumption tests were performed on eight different configurations. The following tables show the mainboard’s voltage, amp and wattage values while running common applications in the Windows XP environment. ESTED ONFIGURATIONS Configuration 1 • VIA C7 1 GHz NanoBGA2 Processor •... -
Page 15: Boot To Idle
EPIA-P710 Operating Guide OOT TO Measured Voltage Measure Amp Watts Configuration 1 11.65 0.986 11.487 Configuration 2 11.60 1.092 12.667 Configuration 3 11.60 1.147 13.305 Configuration 4 11.56 1.151 13.306 Configuration 5 11.63 1.267 14.735 Configuration 6 11.65 1.284 14.959... -
Page 16: Power Specifications
EPIA-P710 Operating Guide Power Specifications The VIA EPIA-P710 Pico-ITXe mainboard utilizes a +12V DC-in power connector for providing power to the mainboard. The dimensions of the DC-in port are show in the figure below. Figure 1: DC-in dimensions March 21, 2018 - 15 - Version 1.01... -
Page 17: Via Epia-P710 Microsoft And Linux Driver Support
ICROSOFT RIVER UPPORT The VIA EPIA-P710 Pico-ITXe mainboard is compatible with Microsoft operating systems. The latest Windows Windows 2000 and Windows XP drivers can be downloaded from the VEPD website at www.viaembedded.com. For embedded operating systems (Windows XP Embedded), the related drivers can be found in the VIA Arena website at www.viaarena.com. -
Page 18: Contact
EPIA-P710 Operating Guide Contact For more information on the VIA EPIA-P710 Pico-ITXe mainboard contact your sales representative or visit our website at www.viaembedded.com. MERICA 940 Mission Court Fremont, CA 94539 Tel: (510) 683 3300 Fax: (510) 687 4654 Email: vpsd_sales@viatech.com...
