user manual
EPIA-P830
Pico-ITX Embedded Board
1.13-03212018-181200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPIA-P830 and is the answer not in the manual?

Questions and answers

Summary of Contents for VIA Technologies EPIA-P830

  • Page 1 EPIA-P830 Pico-ITX Embedded Board 1.13-03212018-181200...
  • Page 2 VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice. Regulatory Compliance...
  • Page 3 Battery Recycling and Disposal Only use the appropriate battery specified for this product. Do not re-use, recharge, or reheat an old battery. Do not attempt to force open the battery. Do not discard used batteries with regular trash. Discard used batteries according to local regulations. Safety Precautions Always read the safety instructions carefully.
  • Page 4 Box Contents and Ordering Information Model Number Description EPIA-P830-12L Standard kit 1 x P830-A daughter card 1 x SATA cable 1 x SATA power cable 1 x DC-in cable P830-B This companion card is for project based enquiries only. MOQ is required. Please...
  • Page 5: Table Of Contents

    ABLE OF ONTENTS 1 Overview ......................... 1 Key Components ....................2 VIA Nano™ NanoBGA2 CPU ..............2 VIA VX900H System Processor ..............2 Layout........................3 Layout (I/O panel)....................5 Specifications ......................6 2 Onboard I/O ......................8 External I/O ......................9 VGA port ......................
  • Page 6 Installing the P830-B ..................29 5 BIOS Setup ......................30 Entering the BIOS Setup Menu ..............31 Control Keys ......................31 Getting Help ......................32 Main Menu ......................33 AMIBIOS ......................33 Processor ......................33 System Memory ..................... 33 System Time ....................33 System Date ....................
  • Page 7 USB Endpoint0 Ctrl Clk ................46 USBD Interface Selection ................46 CRB Configuration .................... 47 DRAM Clock ....................47 Select Display Device 1 and 2 ..............47 Panel Type ....................... 48 VGA Share Memory (Frame Buffer) ........... 48 OnChip HDAC Device................48 WATCH-DOG ....................
  • Page 8: Overview

    Overview...
  • Page 9: Key Components

    VIA VT1708S High Definition Audio codec. The EPIA-P830 is based on the VIA VX900H Unified Digital Media IGP chipset featuring the VIA C-9 HD with 2D/3D graphics and video accelerators for rich digital media performance.
  • Page 10: Layout

    AYOUT...
  • Page 11 Item Description Page FAN1: System fan CN5: LPC, SMBus, and GPIO combination pin header CN4: Front panel and PS2 combination pin header CN2: USB, and USB Device combination pin header CN1: Front audio pin header PWR2: SATA power connector J1: UART port 2 SATA1, SATA2: SATA 3Gb/s connectors CN6: PCIe and USB 2.0 combination connector CN3: LAN pin header...
  • Page 12: Layout (I/O Panel)

    (I/O AYOUT PANEL Item Description Page VGA1: VGA port (on P830-A) USB1, USB2: USB 2.0 ports (on P830-A) ® HDMI1: HDMI port RJ1: Gigabit LAN port (on P830-A)
  • Page 13: Specifications

    PECIFICATIONS Processor VIA 1.2GHz U3300 Nano processor Chipset VIA VX900H Unified Digital Media IGP Chipset Super I/O Fintek F81801U-I Memory 1 x DDR3 1066/800 MHz SODIMM slot (supports a 4 GB module**) Integrated VIA C-9 HD 3D/2D graphics Storage 2 x SATA 3Gb/s connectors VIA VT6130 PCIe Gigabit Ethernet controller VIA VT1708S High Definition audio codec Audio...
  • Page 14 System Monitoring - Wake-on-LAN, Keyboard power-on, RTC Timer power-on, Watch Dog Timer - System power management, AC Power failure recovery Operating environment 0°C ~ 60°C 0% ~ 95% (relative humidity; non-condensing) Form Factor 12 layer Pico-ITX (10 cm x 7.2 cm) Compliance CE/FCC/RoHS/BSMI Note:...
  • Page 15: Onboard I/O

    Onboard I/O...
  • Page 16: External I/O

    XTERNAL The external I/O panel has the following ports: VGA port The 15-pin VGA port is for connecting to analog displays. ® HDMI port ® ® The HDMI port is for connecting to HDMI displays. Gigabit LAN port The Gigabit Ethernet port is controlled through the VIA VT6130 PCIe Gigabit Ethernet controller.
  • Page 17: Onboard Connectors

    NBOARD CONNECTORS LVDS panel connector The onboard LVDS panel connector (LVDS1) supports a single- channel 24-bit display. Backlight controls are integrated into the LVDS connector pinout. Signal Signal LVDSD0-- LVDSD1- LVDSD0+ LVDSD1+ PVDD2 LVDSD2- PVDD2 LVDSD2+ LCD1_DATA LCD1_CLK LVDSCLK+ LVDSCLK- VDD_BL VDD_BL LVDSD3-...
  • Page 18: Vga And Usb Combination Pin Header

    VGA and USB combination pin header The VGA and USB combination pin header block (VGA_USB1) is used to connect to the P830-A companion card. The pin header block provides support for one VGA port and two USB 2.0 ports. Signal Signal REDN GREENN...
  • Page 19: Sata Connectors

    SATA connectors There are two onboard SATA connectors that support data transfer speeds up to 3 Gbps. Both SATA connectors have a 7 pin that can provide +5V power to a SATA Disk-on-Module (DOM). When a regular SATA hard drive is connected, the 7 pin will be a ground pin.
  • Page 20: Pcie And Usb Combination Connector

    PCIe and USB combination connector The onboard combination PCI Express and USB connector (CN6) is for connecting directly to the P830-B companion card. Standard PCIe or USB connectors are not supported. The connector pinout supports the equivalent of two PCIe x1 ports and one USB 2.0 port. Signal Signal 1–25...
  • Page 21: Usb And Usb Device Combination Pin Header

    USB and USB Device combination pin header The onboard USB and USB Device combination pin header block (CN2) enables the addition of five more USB 2.0 ports and one USB device port. Signal Signal USB_VD0+ USB_VD6+ USB_VD0- USB_VD6- +5VSUS +5VSUS USB_VD1- USB_VD3- USB_VD1+...
  • Page 22: Lan Pin Header

    LAN pin header The onboard LAN pin header block (CN3) is used to connect to the P830-A companion card. The pin header block provides support for one RJ45 Gigabit Ethernet port. Signal Signal VDDTXRX AVDD33 TD2- TD3- TD2+ TD3+ TD0- TD1- TD0+ TD1+...
  • Page 23: Uart Connectors

    UART connectors The mainboard includes two UART ports. UART port 1 (J2) is the 12-pin port on the bottom side. UART port 2 (J1) is the 10-pin port on the top side. UART 2 (J1) UART 1 (J2) Signal Signal SIN2 -LPCRST SOUT2...
  • Page 24: Lpc, Smbus, And Gpio Combination Pin Header

    LPC, SMBus, and GPIO combination pin header The mainboard includes one LPC, SMBus, and GPIO combination pin header block (CN5). Signal Signal LAD3 SIO_CLK1 LAD2 PCICLK2 LAD1 -LDRQ0 -LFRAME SERIRQ LAD0 -PCIRST SMB_CLK SMB_DAT +3.3V -INTD/GPIO12 -RING/GPI8 -INTC/GPIO9 -THRM/GPI9 GPO12 -EXTSMI/GPI5 GPIO32 -BATLOW/GPI4...
  • Page 25: Spi Connector

    SPI connector The onboard SPI connector (J3) is for updating the SPI flash ROM. Signal MSPIDO MSPIDI MSPICLK MSPISSO SPIVCC CMOS battery connector The onboard battery connector (BAT1) provides power to the CMOS RAM. If disconnected all configurations in the CMOS RAM will be reset to factory defaults.
  • Page 26: Front Panel And Ps/2 Combination Pin Header

    Front panel and PS/2 combination pin header The mainboard includes one Front Panel and PS/2 combination pin header block (CN4). The PS/2 pin headers support one PS/2 keyboard and one PS/2 mouse. Signal Signal +5VSUSLED1 +5VLED2 +5VSUSLED1 -HD_LED PW_BN- SPEAK_BZ RST_SW -PWR_LED +5VSUS...
  • Page 27: System Fan Connector

    System fan connector The System fan (FAN1) runs on +5V and maintains system cooling. Signal FANIN1 +5V FANCTL FAN1 VIA Nano VX900H PWR1 DC-in power connector The mainboard has an onboard DC-In 2-pin power connector (PWR1) to connect the DC-In power cable. Signal DC-in (+12V±5%)
  • Page 28: Sodimm Ddr3 Memory Slot

    SODIMM DDR3 memory slot The mainboard has one 204-pin DDR3 SODIMM slot that supports non-ECC DDR3 1066/800 MHz memory modules. It can support memory sizes up to 4 GB.
  • Page 29 Installing memory modules Step 1 Locate the SODIMM slot in the mainboard and align the notch on the SODIMM with the memory slot. Step 2 Insert the SODIMM module at a 30 degree angle. Then push the SODIMM down until it snaps into the locking mechanism.
  • Page 30: Onboard Jumpers

    Onboard Jumpers...
  • Page 31: Clear Cmos Jumper

    Clear CMOS jumper The onboard CMOS RAM stores system configuration data and has an onboard battery power supply. To reset the CMOS settings, set the jumper (JM1) on pins 2 and 3 while the system is off. Return the jumper to pins 1 and 2 afterwards. Setting the jumper while the system is on will damage the mainboard.
  • Page 32: Lvds Jumper Settings

    LVDS jumper settings The LVDS jumper (JM2) determines the input voltage for the LCD connector. +3.3V (default) LCD Backlight Power selector The backlight jumper (JM3) determines the input voltage for the LCD backlight inverter. +12V (default)
  • Page 33: Hardware Installation

    Hardware Installation...
  • Page 34: Installing The P830-A

    Align the CON1 and CON2 connectors on the P830-A with the VGA_USB1 combination pin header block and LAN pin header block on the EPIA-P830, respectively. In the figure below, the dotted rectangles represent the CON1 and CON2 connectors on the bottom side of the P830-A companion card.
  • Page 35 Step 2 Then gently press down until the pins on the EPIA-P830 mainboard have been fully inserted into the CON1 and CON2 connectors of the P830-A companion card. Step 3 Secure the EPIA-P830-A to the EPIA-P830 with two screws.
  • Page 36: Installing The P830-B

    P830-B NSTALLING THE Step 1 Align the CN6 connector on the EPIA-P830 with the CN2 connector on the P830-B. Then gently insert the CN6 connector into the CN2 connector until the CN6 connector is fully inserted.
  • Page 37: Bios Setup

    BIOS Setup...
  • Page 38: Entering The Bios Setup Menu

    BIOS S NTERING THE ETUP Power on the computer and press <Delete> during the beginning of the boot sequence to enter the BIOS setup menu. If you missed the BIOS setup entry point, restart the system and try again. ONTROL Keys Description Move to the previous item...
  • Page 39: Getting Help

    ETTING The BIOS setup program provides a “General Help” screen. You can display this screen from any menu/sub-menu by pressing <F1>. The help screen displays the keys for using and navigating the BIOS setup. Press <Esc> to exit the help screen.
  • Page 40: Main Menu

    AMIBIOS BIOS version number and related information. Processor This section describes the detected CPU name, speed, and number of processors. System Memory This section describes the detected memory size. System Time Use the key “+” or “-” to configure system time. The time format is [Hour : Minute : Second].
  • Page 41: Advanced Settings

    DVANCED ETTINGS Available submenus include the following: • CPU Configuration • IDE Configuration • SuperIO Configuration • Hardware Health Configuration • ACPI Configuration • APM Configuration • Event Log Configuration • Spread Spectrum Configuration • USB Configuration • CRB Configuration...
  • Page 42: Cpu Configuration

    CPU C ONFIGURATION Nano CPU TM3 Control This option is used to enable the internal thermal protection features inside the onboard Nano CPU. Settings Description Disabled No thermal monitoring Enabled Enables Thermal Monitor 3...
  • Page 43: Ide Configuration

    IDE C ONFIGURATION Available submenus include the following: • Primary IDE Master • Primary IDE Slave...
  • Page 44: Ide Drives

    IDE D RIVES PIO Mode The Programmed Input/Output mode is a data transfer method that uses the CPU registers to transfer data. Settings Description Auto The Programmed Input/Output mode is automatically selected. Maximum transfer rate of 3.3 MB/s. Cycle time: 600ns. Defined in ATA specification.
  • Page 45: Superio Configuration

    IO C UPER ONFIGURATION Serial Port Address, IRQ, and Type The SuperIO configuration menu enables the BIOS to specifically define the resources used for serial ports 1 and 2. Port Address/IRQ 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3, Disabled 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled...
  • Page 46: Hardware Health Configuration

    ARDWARE EALTH ONFIGURATION The Hardware Health Configuration displays all monitored information. Smart FAN 1 Settings Description Auto Fan speed is dynamically adjusted as required to maintain optimal system temperature. Full Speed Fan speed is fixed at the maximum RPM of the system fan.
  • Page 47: Acpi Configuration

    ACPI C ONFIGURATION Suspend Mode Select the ACPI state used for system suspend. Settings Description S1(POS) S1/Power On Suspend (POS) is a low power state. In this state, no system context (CPU or chipset) is lost and hardware maintains all system contexts S3(STR) S3/Suspend To RAM (STR) is a power-down state.
  • Page 48: Apm Configuration

    APM C ONFIGURATION Power Button Mode Settings Description On/Off Pressing the power button will Instantly cause the system to power on or off. Standby Requires the user to press and hold the power button for 4 seconds before powering off the system. Suspend Pressing the power button will Instantly cause the system to enter suspend mode.
  • Page 49: Resume On Ps/2 Kbc

    Resume On PS/2 KBC Enables any detected keyboard activity to restore the system from a power saving mode to an active state. Settings Description PS/2 keyboard activity will be detected if the system is in S3 power saving mode. S3/S4/S5 PS/2 keyboard activity will be detected if the system is in S3/S4/S5 power saving mode.
  • Page 50: Rtc Alarm Date (Days)

    RTC Alarm Date (Days) This option enables the user to specify the frequency of the RTC Alarm Date recurrence. Settings Description Every Day Triggers the RTC Alarm Date daily. 1 – 31 (days) Triggers the RTC Alarm Date according to the increment specified.
  • Page 51: Event Log Configuration

    VENT ONFIGURATION View Event Log This option enables users to view messages regarding recorded events. Pressing the <Enter> button while this option is selected will open a separate window containing a list of recorded event logs. Mark all events as read This option enables users to quickly flag all event logs as having been read —...
  • Page 52: Spread Spectrum Configuration

    PREAD PECTRUM ONFIGURATION Spread Spectrum Configuration The Spread Spectrum Configuration feature enables the BIOS to help limit Electromagnetic Interference (EMI) emanating from the system. Higher percentages reduce the EMI. However, higher percentages may result in reduced system stability. If the system is not placed near EMI sensitive electronics, it is recommended to leave this feature disabled.
  • Page 53: Usb Configuration

    USB C ONFIGURATION The USB configuration page detects all connected USB devices. USB Device Mode Enable Settings Description Enabled Unlocks the USB device port. Disabled Locks the USB device port. Note: The USB device port driver must be installed in order for the port to function. USB Endpoint0 Ctrl Clk This option is only available if USB Device Mode Enable is enabled.
  • Page 54: Crb Configuration

    CRB C ONFIGURATION DRAM Clock Settings Description Auto Auto adjusts the DRAM clock 400 MHz Sets the DRAM clock to 400 MHz. DDR3 modules will operate at 800 MHz. 533 MHz Sets the DRAM clock to 533 MHz. DDR3 modules will operate at 1066 MHz.
  • Page 55: Panel Type

    Panel Type This feature enables the user to specify the resolution of the display being used with the system. The panel types are predefined in the VGA VBIOS. Settings Description 640 x 480 800 x 600 1024 x 768 1280 x 768 1280 x 1024 1400 x 1050 1440 x 900...
  • Page 56: Time-Select

    Time-Select This option is only available if WATCH-DOG is enabled. Settings Description Disable 1–255 Sets the number of units to count. If Unit-Select is set to Minutes, the maximum acceptable integer is 17. Backlight Control This option sets the brightness control for an LCD device. Settings Description Level 0...
  • Page 57: Boot Settings

    ETTINGS The Boot Settings menu has the following submenus: Boot Settings Configuration Configuration settings during system boot. Boot Device Priority...
  • Page 58: Boot Settings Configuration

    ETTINGS ONFIGURATION Quick Boot Settings Description Enabled Enables the BIOS to skip certain tests in order to reduce boot up time. Disabled Support for this feature will be unavailable. Quiet Boot Settings Description Enabled Displays an OEM logo instead of POST messages. Disabled Displays POST messages.
  • Page 59: Hit 'Del' Message Display

    Hit ‘DEL’ Message Display Settings Description Enabled Shows the POST message that informs the user how to enter the BIOS setup menu. However, this message will be hidden if the Display Logo option is enabled. Disabled Hides the POST message that informs the user how to enter the BIOS setup menu.
  • Page 60: Boot Device Priority

    EVICE RIORITY This menu automatically detects and lists all bootable storage devices. The boot seek sequence can be changed in this menu.
  • Page 61: Security Settings

    ECURITY ETTINGS Change Supervisor Password This option is for setting a password for accessing the BIOS setup utility. When a password has been set, a password prompt will be displayed whenever the BIOS setup utility is launched. This prevents an unauthorized person from changing any part of the system configuration.
  • Page 62: Change User Password

    Change User Password This option is for setting a password for non-supervisors. When a user password is set, the Clear User Password and Password Check options will be unlocked. Clear User Password This option is only available when the user accesses the BIOS Setup Utility when the user password has been specified.
  • Page 63: Exit Options

    PTIONS Save Changes and Exit Save all changes to the BIOS and exit the BIOS Setup Utility. The “F10” hotkey can also be used to trigger this command. Discard Changes and Exit Exit the BIOS Setup Utility without saving any changes. The “Esc” hotkey can also be used to trigger this command.
  • Page 64: Driver Installation

    Driver Installation...
  • Page 65: Microsoft Driver Support

    ICROSOFT RIVER UPPORT The VIA EPIA-P830 mainboard is compatible with Microsoft operating systems. The latest Windows drivers can be downloaded from the VIA Embedded website at http://www.viatech.com/en/boards/pico-itx/epia-p830/. For embedded operating systems, the related drivers can be found in the VIA Embedded website at www.viatech.com.
  • Page 66: A Appendix

    Appendix...
  • Page 67: Pin Header And Connector Vendor Lists

    EADER AND ONNECTOR ENDOR ISTS Label Function Pins Vendor Part No. LVDS1 LVDS ACES 87216-2416-06 SODIMM1 Memory Foxconn AS0A626-J6RG-7H SATA1, SATA2 SATA connector Win Win WATM-07DBN4A2B8UW FAN1 Fan connector Neltron 1251S-03-SM1-TR-F5 BAT1 Cable battery Neltron 1251R-02-SM1-TR-F5 connector VGA_USB1 VGA and USB Neltron 2208SM-18G-BK-CP combination...
