Technical Reference Guide
For receipt models
Product Overview
Describes features of the product.
Setup
Describes setup and installation of the product.
Application Development Information
Describes how to control the printer and necessary information
when you develop applications.
Handling
Describes how to handle the product.
Replacement of the TM-P60
Describes information for replacement.
Appendix
Describes general specifications and character code tables.
M00057003
Rev. C

Advertisement

Table of Contents
loading

Related Manuals for Epson TM-P60II

Summary of Contents for Epson TM-P60II

  • Page 1 For receipt models Technical Reference Guide Product Overview Describes features of the product. Setup Describes setup and installation of the product. Application Development Information Describes how to control the printer and necessary information when you develop applications. Handling Describes how to handle the product. Replacement of the TM-P60 Describes information for replacement.
  • Page 2 • Neither is any liability assumed for damages resulting from the use of the information contained herein. • Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating...

  • Page 3: For Safety

    For Safety Key to Symbols The symbols in this manual are identified by their level of importance, as defined below. Read the following carefully before handling the product. You must follow warnings carefully to avoid serious bodily injury. WARNING Provides information that must be observed to prevent damage to the equipment or loss of data.

  • Page 4: Warnings

    Continued use may lead to fire. Immediately turn the power off, disconnect the battery pack, and then contact your dealer or a Seiko Epson service center for advice.  Never attempt to repair this product yourself. Improper repair work can be dangerous.

  • Page 5: Cautions

    Cautions  Do not connect cables in ways other than those mentioned in this manual. Different connections may cause equipment damage or fire.  Be sure to set this equipment on a firm, stable, horizontal surface. CAUTION The product may break or cause injury if it falls. ...

  • Page 6: Restriction Of Use

    • Never disassemble or modify this product or the installed Radio Frequency module. • Seiko Epson Corporation shall not be liable for interference to radio/TV resulting from changes or modifications to this product or the installed Radio Frequency module not...

  • Page 7: About This Manual

    About this Manual Aim of the Manual This manual was created to provide information on the development, design, and installation of POS systems and the development and design of printer applications for developers. Manual Content The manual is made up of the following sections: Chapter 1 Product Overview Chapter 2...

  • Page 8: Table Of Contents

    Contents ■ For Safety ..........................3 Key to Symbols............................3 Warnings ..............................4 Cautions ..............................5 ■ Restriction of Use ........................6 ■ Note about interference...................... 6 ■ About this Manual ........................ 7 Aim of the Manual ..........................7 Manual Content .............................7 ■ Contents..........................8 Product Overview ................13 ■...
  • Page 9 Setup .....................27 ■ Flow of Setup ........................27 ■ Installing the Printer ......................28 Notes on Using the Wi-Fi Models ......................28 ■ Changing the Paper Width ....................29 Removing the Spacer ......................... 29 Installing the Spacer ..........................30 ■ Installing the Battery......................32 ■...
  • Page 10 Handling ..................73 ■ Charging Battery........................ 73 ■ Cleaning the Printer ......................74 Cleaning the Printer Case ........................74 Cleaning the Thermal Head .......................74 Replacement of the TM-P60............75 ■ Compatibility ........................75 ■ Additional Functions and Functional Improvements............78 Appendix ..................81 ■ Product Specifications ....................... 81 Printing Specifications..........................81 Character Specifications........................83 Paper Specifications ..........................84...
  • Page 11 ■ Character Code Tables......................97 Common to All Pages ......................... 97 Page 0 [PC437: USA, Standard Europe] .................... 98 Page 1 (Katakana) ..........................99 Page 2 (PC850: Multilingual) ......................100 Page 3 (PC860: Portuguese)......................101 Page 4 (PC863: Canadian-French) ....................102 Page 5 (PC865: Nordic) ........................

  • Page 13: Product Overview

    Chapter 1 Product Overview Product Overview This chapter describes features and specifications of the TM-P60II, a portable receipt printer. Features Printing Maximum printing speed of 100 mm/s is possible. Printer handling • Easy drop-in paper loading. • 58 mm and 60 mm width paper can be used.

  • Page 14: Product Configurations

    Product Configurations Interfaces • Wi-Fi (IEEE802.11a/b/g/n) + USB interface model • Bluetooth (Ver. 2.1 + EDR) + USB interface model Accessories Included • Thermal roll paper (for operation check) • Battery pack (OT-BY60II) • Wire saddle • USB cable • User’s manual •...

  • Page 15: Part Names And Functions

    Chapter 1 Product Overview Part Names and Functions Roll paper cover Open button Control panel "Control Panel" on page Battery cover Connector for AC USB connector cover Belt clip Roll Paper Cover Open this cover to install or remove the roll paper. Battery Cover Open this cover to install or remove the battery.

  • Page 16: Control Panel

    Control Panel Feed button Power button Error Charge Battery LED Power LED Charge LED Error LED Buttons Power Button Press this button to turn the printer on. Press this button for 2 seconds or more to turn the printer off. ...
  • Page 17 Chapter 1 Product Overview LEDs The printer does not operate and the LEDs go out when the battery is not installed in the printer even if the printer is connected to the optional AC adapter. Power LED (Green) • Lights when the power is on. •...

  • Page 18: Offline

    Offline The printer automatically goes offline under the following conditions: • During power on until the printer is ready • When the roll paper cover is open • When paper is out • During the self-test • While roll paper is fed using the Feed button •...

  • Page 19: Power Functions

    Chapter 1 Product Overview Power Functions You can customize the printer using the power functions, the auto-power off function and battery charge mode function to save the battery power or minimize the battery deterioration. Auto-Power Off The printer turns off the power automatically after the specified amount of time elapses in the power saving status.

  • Page 20: Operation Mode When Battery Is Low

    Operation Mode When Battery is Low The printer acts differently depending on the remaining battery charge and the operation mode when battery is low. The printer has two modes and is initially set to the mode 1.  It is recommended to replace or charge the battery when the remaining battery charge goes down to the level L.

  • Page 21: Mode 2

    Chapter 1 Product Overview Mode 2 : On : Flash : Off Remaining Battery LED Error LED Printing Communication battery charge Approx. 60  100% Level H Possible Possible Approx. 20  60% Level M Possible Possible Approx. 10  20% Level L Possible Possible...

  • Page 22: Error Status

    Error Status When an error occurs, the printer stops operating, goes offline, and the Error LED flashes. There are three possible error types: automatically recoverable errors, recoverable errors, and unrecoverable errors. Automatically Recoverable Errors Printing is no longer possible when automatically recoverable errors occur. They can recover easily, as described below.

  • Page 23: Unrecoverable Errors

    Printing is no longer possible when unrecoverable errors occur. If the same error occurs again even after turning the power back on, contact your dealer or a Epson service center. Immediately turn off the power and remove the battery when unrecoverable errors occur.

  • Page 24: Nv Memory (Non-Volatile Memory)

    Graphics, such as shop logos to be printed on receipts, can be stored. Even if communication speed is low, high speed graphic printing is possible. Use the TM-P60II Utility to register graphics. You can also print and confirm the registered graphics in the TM-P60II Utility or NV graphics memory print mode.

  • Page 25: Customized Values And Memory Switches

    NV memory. You can read or reset the information with TM-P60II Utility, the Status API of the APD, or OPOS ADK to use it for periodical checks or part replacement.

  • Page 27: Setup

    Chapter 2 Setup Setup This chapter describes setup and installation of the product and peripherals. Flow of Setup This chapter consists of the following sections, along with the setup flow of the product. Installing the Printer (page 28) Changing the Paper Width (page 29) Installing the Battery (page 32) 4.

  • Page 28: Installing The Printer

    Installing the Printer You can install the printer horizontally or vertically. You can also carry it using the belt clip on the back of the printer to hang the printer on your belt.  When you install the printer vertically, only the orientation shown below is available. Do not install the printer upside down.

  • Page 29: Changing The Paper Width

    Chapter 2 Setup Changing the Paper Width The printer is initially set to print on 58 mm {2.28"} width paper. If you use 60 mm {2.36"} width paper, remove the spacer installed in the printer. You can also install it again to use 58 mm width paper.

  • Page 30: Installing The Spacer

    Release the hook in direction (1) by using a pointed tool, such as tweezers or a small screwdriver, and lift up (2) the spacer to take it off. Installing the Spacer Follow the steps below to install the spacer when you use 58 mm width paper. Make sure that the printer is turned off.
  • Page 31 Chapter 2 Setup Install the spacer by inserting hook 1 and then hook 2.

  • Page 32: Installing The Battery

    Installing the Battery The printer does not operate without a charged battery installed. Follow the steps below to install the battery. Be sure to use the battery OT-BY60II. Using a battery other than the one specified may cause fire, explosion, leakage, overheating or other damage.

  • Page 33: Installing Or Replacing The Roll Paper

    Chapter 2 Setup Installing or Replacing the Roll Paper Follow the steps below to install or replace the roll paper. If you hang the printer vertically on a belt using a belt clip on the back of the printer, see "When Installing the Printer Vertically"...

  • Page 34: When Installing The Printer Vertically

    Pull out some paper, close the cover, and tear off the paper. When Installing the Printer Vertically Press the open button to open the roll paper cover. Remove the used roll paper core, if there is one.
  • Page 35 Chapter 2 Setup Set the new roll paper in the correct direction on the inside of the roll paper cover. Pull the leading edge of the roll paper.
  • Page 36 Align the left edge of the roll paper with the edge of the cover. Pull out some paper, close the cover, and tear off the paper.

  • Page 37: Connecting The Printer

    Chapter 2 Setup Connecting the Printer The TM-P60II has dual interfaces: a built-in USB interface and another interface selected by the customer, wireless LAN or Bluetooth interface. See the corresponding section for the interface you selected. • Wi-Fi models: "USB Interface" on page 37 "Wireless LAN Interface"...
  • Page 38 Attach the enclosed wire saddle to the printer as shown in the picture below. Put the USB cable through the wire saddle. Connect the USB cable from the host computer to the USB upstream connector. Connect the other end of the interface cable to the host computer. Wire saddle...

  • Page 39: Wireless Lan Interface

    Chapter 2 Setup Wireless LAN Interface If your printer is a Wi-Fi model, wireless LAN connection is available. Use EpsonNet Config, which is a utility for wireless LAN settings by following the steps below.  Examine the radio wave situation in the surrounding area before use. ...

  • Page 40: Bluetooth Interface

    Use a tool, such as a built-in Bluetooth connection tool of your device to establish the connection with the printer. If your device is a Windows computer, use EPSON TM Bluetooth Connector, which is a utility to easily pair a terminal and the printer.
  • Page 41 Chapter 2 Setup Turn on the printer. Start TM Bluetooth Connector. Select [Search all printers around this computer], and then click [Search]. Select the printer to be paired ( Not been paired yet), and then click [Connect].
  • Page 42 [OK]. Select the port to be used from the pull-down list, and then click [OK]. Printing method Port name APD print queue ESDPRTxxx (TM-P60II: Queue name) UPOS ESDPRTxxx (UPOS for TM-P60II) ESC/POS command Displayed virtual COM port (e.g. COM4) The “Connection complete” window appears. Click [Test Buzzer] or [Test Printing] to check operation.
  • Page 43 Chapter 2 Setup  If “Error” is displayed when you click the [Search] on the TM Bluetooth Connector, check whether:  The Bluetooth adapter is installed to the computer.  Bluetooth is ON in the Windows settings.  If the device is not displayed on the TM Bluetooth Connector or the TM Bluetooth Connector Status shows “...

  • Page 44: Software Settings

    With the customized values and memory switches, which are software settings for this printer, you can set the various functions. For an outline of those functions, see the following section. Use TM-P60II Utility, Software setting mode, or ESC/POS commands, to set the customized values and memory switches.

  • Page 45: Print Density

    Chapter 2 Setup User NV memory capacity • 1 KB (initial setting) • 64 KB • 128 KB • 192 KB NV graphics memory capacity • None • 64 KB • 128 KB • 192 KB • 256 KB • 320 KB •...

  • Page 46: Print Speed

    Selectable from: automatic selection, fixed to wireless LAN/Bluetooth interface, or fixed to built- in USB.  The TM-P60II has dual interfaces: a built-in USB interface and another interface selected by the customer, wireless LAN or Bluetooth. The tables below describe the modes you can set for the printer to control the dual interfaces.
  • Page 47 Chapter 2 Setup Command execution during offline When this function is enabled, you can execute specified commands even if the printer is offline due to specified causes. • Enabled (initial setting) • Disabled Autocutting at roll paper cover close • Cuts (initial setting) •...
  • Page 48 • Battery status levels for the TM-P60II (initial setting) • Battery status levels for the TM-P60 While the battery status for the TM-P60II has 6 levels, that for the TM-P60 has 4 levels. Transmission of Status notice • Transmits (initial setting) •...
  • Page 49 Chapter 2 Setup Error signal output • Enabled (initial setting) • Disabled USB class • Printer Class • Vendor Class (initial setting) Bluetooth interface • Passkey (initial setting: 0000) • Device name (initial setting: TM-P60II_xxxxxx) • Device available for search (initial setting: Enabled) The device name is initially set to TM-P60II_xxxxxx.

  • Page 51: Application Development Information

    Chapter 3 Application Development Information Application Development Information This chapter describes how to control the printer and gives information useful for printer application development. Controlling the Printer Use a driver, ESC/POS commands, or ePOS-Print to control the printer. ePOS-Print is available only with the Wi-Fi models.

  • Page 52: Esc/Pos Commands

    ESC/POS Commands ESC/POS is the Epson original printer command system. With ESC/POS commands, you can directly control all the TM printer functions, but detailed knowledge of printer specifications or combination of commands is required. To use ESC/POS commands, you need to agree to a nondisclosure contract first and obtain the ESC/POS Application Programming Guide.
  • Page 53 Chapter 3 Application Development Information Character Commands Cancel print data in page mode Set right-side character spacing Select print mode(s) Turn underline mode on/off Turn emphasized mode on/off Print and feed paper Select character font Select an international character set Turn upside-down print mode on/off Select character size Turn white/black reverse print mode on/off...
  • Page 54 Transmit the key code list of stored record Delete all data in the NV user memory Change into the use setting mode End the user setting mode session Set the memory switch values Transmit memory switch values Set the customized setting values Transmit the customized setting values Set the configuration item for the Bluetooth interface Transmit the configuration item for the Bluetooth interface...
  • Page 55 Chapter 3 Application Development Information Select the setting values of the work area after the initialization process Specify Windows BMP graphics data Two Dimensions Code Commands Set up and print the symbol Barcode Commands Select print position of HRI characters Select font for HRI characters Set barcode height Print barcode...

  • Page 56: Epos-Print

    Kanji Commands (only for Traditional Chinese model) Select print mode(s) for Kanji characters Select Kanji character mode Turn underline mode on / off for Kanji characters Cancel Kanji character mode Define user-defined Kanji characters Set Kanji character spacing Turn quadruple-size mode on / off for Kanji characters ePOS-Print ePOS-Print is functionality to control POS printers in a multi-platform environment.

  • Page 57: Software And Manuals

     APD Printer Specification paper cut, a cash drawer, or customer display. The  Devmode API/PRINTERINFO Manual Status API (Epson original DLL) that monitors printer  Status API Manual status and sends ESC/POS commands is also  Sample Program Guide attached to this driver.
  • Page 58 Windows drivers. It is not a driver to be used for printing from commercial applications. *2: This guide describes general information on how to control printers using the OPOS ADK (in the chapter “POS Printer” and “Appendix A”). It does not describe Epson’s specific functions.

  • Page 59: Utilities

    Use to pair a terminal and the printer for TM Bluetooth connection. Monitoring Tool: Monitoring Tool User’s Manual Use to check a list of status for the Epson printers connected to the network. You can also update certificates for multiple printers used for WPA- Enterprise in a batch.

  • Page 60: Epsonnet Config (Web Version)

    Mode" on page  A user name and a password will be required on the authentication screen. Enter “epson” for both the user name and the password. You can change the password with [Password] in the Optional configuration menu.

  • Page 61: Settings

    Chapter 3 Application Development Information EpsonNet Config starts. Settings Select from the menu list on the left to check or configure the settings. Enable the time server when using a certificate. Otherwise, the printer's Stored Date/Time may not be set correctly and the wireless LAN may be unavailable. If this happens, enable the time server, or initialize the Stored Date/Time from one of the following: ...

  • Page 62: Information Menu

    Information menu You can check the settings as shown in the table below. Menu Settings Administrator Name, Location, interface Card Model Name, MAC Address, Hardware Version, Software Version, Model Name, Basic Information Communication Standard, Network Mode, SSID, Channel, Transmission Rate, Access Point MAC Address, Signal Condition, Printer Status IP Address Settings (Acquiring the IP Address, IP Address, Subnet Mask, Default Gateway)

  • Page 63: Configuration Menu

    Chapter 3 Application Development Information Configuration menu You can configure the settings as shown in the table below. Menu Settings Wireless Settings (Communication Standard, Network Mode, SSID, Channel, Encryption Type) Wireless WPA Pre-Shared Key, Default WEP Key, WEP Key 1/2/3/4, Authentication Algorithm Power Save Server Certificate, Encryption Strength, Automatic Redirect...

  • Page 64: Setting/Checking Modes

    Setting/Checking Modes Besides the ordinary print mode, the printer has the following modes to set or check settings of the printer. • Self-test mode: page 65 • Hexadecimal dumping mode: page 66 • NV graphics print mode: page 67 • Software setting mode: page 68 •...

  • Page 65: Self-Test Mode

    Chapter 3 Application Development Information Self-test Mode In the self-test mode, the printer prints the current status of the printer and resident characters as a test print). You can confirm the following information with the status print. • ROM version •...

  • Page 66: Hexadecimal Dumping Mode

    Hexadecimal Dumping Mode In the hexadecimal dumping mode, the printer prints the data transmitted from a host computer in hexadecimal numbers and their corresponding characters. Starting the hexadecimal dumping mode Follow the steps below to run this mode.  If there is no character corresponding to print data, “.” is printed. ...

  • Page 67: Nv Graphics Print Mode

    Chapter 3 Application Development Information NV Graphics Print Mode You can confirm the following information by running NV graphics print mode:  Capacity of the NV graphics  Used amount of the NV graphics  Unused capacity of the NV graphics ...

  • Page 68: Software Setting Mode

    Software Setting Mode In the software setting mode, you can set the following customized values and memory switches which are software switches of this printer.  NV graphics memory capacity  Roll paper width  Print density  Print speed ...

  • Page 69: Wireless Communication Setting Initializing Mode

    Chapter 3 Application Development Information Wireless Communication Setting Initializing Mode You can initialize the wireless communication settings by running this mode. When you run this mode with a Wi-Fi model connecting with the wireless LAN interface, the wireless LAN setting will be initialized. When you run this mode with a Bluetooth model connecting with the Bluetooth interface, the Bluetooth setting will be initialized.

  • Page 70: Radio Field Intensity Check Mode (Only For Wi-Fi Models)

    Radio Field Intensity Check Mode (Only For Wi-Fi Models) In the radio field intensity check mode, the printer prints information about the wireless LAN intensity. Starting the field intensity check mode Follow the steps below to run this mode. Install the roll paper. Close the roll paper cover.

  • Page 71: Dynamic Status Sheet Print Mode (Only For Wi-Fi Models)

    Chapter 3 Application Development Information Dynamic Status Sheet Print Mode (Only for Wi-Fi Models) In the dynamic status sheet print mode, the printer prints the dynamic status sheet indicating the wireless LAN settings. Starting the dynamic status sheet print mode Follow the steps below to run this mode.

  • Page 73: Handling

    Chapter 4 Handling Handling This chapter describes basic handling of the printer. Charging Battery Follow the steps below to charge the battery. You can charge the battery using the printer itself with the optional AC adapter (PS-11). Be sure to use the battery OT-BY60II. Using a battery other than the one specified may cause fire, explosion, leakage, overheat- ing or other damage.

  • Page 74: Cleaning The Printer

    Cleaning the Thermal Head Epson recommends cleaning the thermal head periodically (generally every 3 months) to maintain receipt print quality.  After printing, the thermal head can be very hot. Do not touch it and let it cool before you clean it.

  • Page 75: Replacement Of The Tm-P60

    Chapter 5 Replacement of the TM-P60 Replacement of the TM-P60 The TM-P60II is designed so that it can smoothly replace the TM-P60. This chapter describes useful information for the replacement. Compatibility TM-P60 TM-P60II Paper width Changeable (58 mm/60 mm) Density 203 ×...
  • Page 76 TM-P60 TM-P60II Reliability Printer 10 million lines printing mechanism Thermal head 100 million pulses (for each element) Autocutter Receipt paper: 500,000 cuts Continuous paper: 100,000 cuts MTBF 120,000 hours MCBF 16 million lines Power supply From the battery or AC...
  • Page 77 Startup time Approx. 2 sec. Wi-Fi models: Approx. 10 sec. Bluetooth models: Approx. 2 sec. ESC/POS commands You can control a TM-P60II with the ESC/POS commands that you used for a TM-P60. Drivers Available Available OPOS ADK Available Available...

  • Page 78: Additional Functions And Functional Improvements

    Approx. 20 hours Approx. 46 hours Mass (including the battery) Approx. 670 g Approx. 630 g Battery charge LED Not available Orange LED EPSON TM Virtual Port Driver Not available Available Utilities TM-P60II Utility Not available Available EpsonNet Config Not available...
  • Page 79 Chapter 5 Replacement of the TM-P60 TM-P60 TM-P60II Barcode UPC-A, UPC-E, UPC-A, UPC-E, printing JAN13/EAN13, JAN8/EAN8, JAN13/EAN13, JAN8/EAN8, Code39, ITF, CODABAR, Code39, ITF, CODABAR, Code93, Code128 Code93, Code128, GS-1-128, GS1 DataBar, GS1 DataBar Truncated, GS1 DataBar Limited, GS1 DataBar Expanded...

  • Page 81: Appendix

    Appendix Appendix Product Specifications Printing Specifications 58 mm {2.28"} width paper printing 60 mm {2.36"} width paper printing Printing method Thermal line printing Dot density 203 × 203 dpi Printing direction Unidirectional with friction feed Maximum print speed* Receipt paper: 100 mm/s {3.94"/s} Continuous label Paper: 80 mm/s {3.15"/s} (Recommended) Printing width 52.5 mm {2.07"}, 420 dots...
  • Page 82  When changing the paper width, you need to install or remove the spacer and to change the setting for the paper width with the customized value. For details, see "Changing the Paper Width" on page  The maximum printing speed listed above may not be achieved depending on the type of interface, the data transmission speed, and the combination of control commands.

  • Page 83: Character Specifications

    Appendix Character Specifications 58 mm {2.28"} width paper printing 60 mm {2.36"} width paper printing Number of characters Alphanumeric characters: 95 Extended graphics: 128 × 43 pages (including user-defined page) International characters: 12 sets Traditional Chinese* : Big5 13,535 Character structure Font A: 12 ×...

  • Page 84: Paper Specifications

    Paper Specifications 58 mm {2.28"} width paper printing 60 mm {2.36"} width paper printing Type Thermal paper Form Roll paper Size Width 57.5 ± 0.5 mm {2.26 ± 0.02"} 59.5 ± 0.5 mm {2.34 ± 0.02"} Outside diameter 51.0 mm {2.01"} maximum Roll width when 57.5 ±...

  • Page 85: Printable Area

    Appendix Printable Area Printing is automatically performed in one to four-part energization depending on the printing conditions. During printing with two to four-part energization, a maximum misalignment (horizontal ruled line shift) of 1/4 to 1/2 dot might occur in the paper feeding direction due to segmented printing.

  • Page 86: Printing And Cutting Positions

    Printing and Cutting Positions Manual-cutter position Approx. 10.9 mm Approx. Auto-cutter blade position 6.4 mm Center of the print dotline Paper feed direction  The values above may vary slightly as a result of paper slack or variations in the paper. Take this into account when setting the cutting position of the auto-cutting.

  • Page 87: Electrical Characteristics

    Appendix Electrical Characteristics  Be sure to install the battery in the printer. The printer does not operate with the optional AC adapter only.  Always use a limited power source (LPS) for the printer.  Be sure to use the optional PS-11 as the AC adapter. Dedicated battery Model: D141A Rated voltage: DC 7.4 V...

  • Page 88: Reliability

    Reliability Life* Printer mechanism 10 million lines printing (3.75 mm {0.15"} for one line) Thermal head 100 million pulses (for each element), 100 km Autocutter Receipt paper: 500,000 cuts Continuous paper: 100,000 cuts MTBF (Mean Time Between 120,000 hours Failure)* MCBF (Mean Cycle Between 16 million lines Failure)*...

  • Page 89: Environmental Conditions

    During operation Approximately 53 dB (bystander position) (including autocutting operation) Note: The values above are measured in the Epson evaluation condition. Acoustic noise differs depending on the paper used, printing contents, and the setting values, such as print speed or print density.

  • Page 90: External Dimensions And Mass

    External Dimensions and Mass • Width: Approximately 103 mm {4.06"} • Depth: Approximately 159 mm {6.26"} • Height: Approximately 65 mm {2.56"} (including the belt clip) • Mass: Approximately 630 g {1.39 lb} (including the battery) Colors EBCK (Epson Black)

  • Page 91: Specifications Of Interfaces And Connectors

    Appendix Specifications of Interfaces and Connectors USB (Universal Serial Bus) Interface USB interface connector Has a USB upstream port connector (mini USB type-B connector) USB transmission specifications USB function Overall specifications According to USB 2.0 specifications Transmission speed USB Full-Speed (12 Mbps) Transmission method USB bulk transmission method Power supply specifications...

  • Page 92: Ieee802.11A/B/G/N Wireless Lan Interface

     Using W53 (CH52 - CH64) outdoors in Australia or Hong Kong is prohibited.  Using W58 (CH149 - CH165) is either prohibited or unavailable.  Using the TM-P60II outdoors in France is prohibited.  In Italy, if used outside of own premises, general authorization is required.
  • Page 93 Appendix Specification • IEEE802.11a/b/g/n (2.4 GHz band or 5 GHz band) compliant wireless LAN communication compatible • Infrastructure mode and 802.11 Ad-hoc mode are supported Communication Speed • IEEE802.11a (5 GHz): Automatic change • IEEE802.11b (2.4 GHz): Automatic change • IEEE802.11g (2.4 GHz): Automatic change •...

  • Page 94: Bluetooth Wireless Interface

    Notes on Wireless LAN Connection Because not all the combinations of the printer and wireless LAN devices have been checked for operation, the operation of the printer in combination with all the wireless LAN devices is not guaranteed. Especially in the ad-hoc mode, the printer may not operate normally, depending on the combination of the device to connect with.

  • Page 95: Notes On Use

    Appendix Specification • Conforms to Bluetooth Specification Version 2.1 + EDR • Bluetooth Power Class 2 • Built-in antenna • Pass key setting is possible • Device name setting is possible Notes on use Time required until printing starts If the host computer and the printer are not connected on a continuous basis but rather connected every time the printer starts printing, some time may be needed for the printer to actually start printing after the host computer commands printing.

  • Page 96: Printing Communication Protocol

    Printing Communication Protocol • LP, LPR: Transfers printing data • TCP Socket Port: Transfers printing data and printer status via unidirectional direct socket communication. LP , LPR • Max. simultaneous connections: • Number of connections for which printing is 1 (Other users need to wait until printing available: is completed.) •...

  • Page 97: Character Code Tables

    Appendix Character Code Tables  The character code tables show only character configurations. They do not show the actual print pattern.  “SP” in the table shows a space. Common to All Pages When the international character set (See "International Character Sets" on page 141.) is USA:...

  • Page 98: Pc437: Usa, Standard Europe]

    Page 0 [PC437: USA, Standard Europe]...

  • Page 99: Katakana)

    Appendix Page 1 (Katakana)

  • Page 100: Pc850: Multilingual)

    Page 2 (PC850: Multilingual)

  • Page 101: Pc860: Portuguese)

    Appendix Page 3 (PC860: Portuguese)

  • Page 102: Pc863: Canadian-French)

    Page 4 (PC863: Canadian-French)

  • Page 103: Pc865: Nordic)

    Appendix Page 5 (PC865: Nordic)

  • Page 104: Pc851: Greek)

    Page 11 (PC851: Greek)

  • Page 105: Pc853: Turkish)

    Appendix Page 12 (PC853: Turkish)

  • Page 106: Pc857: Turkish)

    Page 13 (PC857: Turkish)

  • Page 107: Pc737: Greek)

    Appendix Page 14 (PC737: Greek)

  • Page 108: Iso8859-7: Greek)

    Page 15 (ISO8859-7: Greek)

  • Page 109: Wpc1252)

    Appendix Page 16 (WPC1252)

  • Page 110: Pc866: Cyrillic #2)

    Page 17 (PC866: Cyrillic #2)

  • Page 111: Pc852: Latin2)

    Appendix Page 18 (PC852: Latin2)

  • Page 112: Pc858: Euro)

    Page 19 (PC858: Euro)

  • Page 113: Thai Code 42)

    Appendix Page 20 (Thai Code 42)

  • Page 114: Thai Code 11)

    Page 21 (Thai Code 11)

  • Page 115: Thai Code 18)

    Appendix Page 26 (Thai Code 18)

  • Page 116: Tcvn-3: Vietnamese)

    Page 30 (TCVN-3: Vietnamese)

  • Page 117: Tcvn-3: Vietnamese)

    Appendix Page 31 (TCVN-3: Vietnamese)

  • Page 118: Pc720: Arabic)

    Page 32 (PC720: Arabic)

  • Page 119: Wpc775: Baltic Rim)

    Appendix Page 33 (WPC775: Baltic Rim)

  • Page 120: Pc855: Cyrillic)

    Page 34 (PC855: Cyrillic)

  • Page 121: Pc861: Icelandic)

    Appendix Page 35 (PC861: Icelandic)

  • Page 122: Pc862: Hebrew)

    Page 36 (PC862: Hebrew)

  • Page 123: Pc864: Arabic)

    Appendix Page 37 (PC864: Arabic)

  • Page 124: Pc869: Greek)

    Page 38 (PC869: Greek)

  • Page 125: Iso8859-2: Latin2)

    Appendix Page 39 (ISO8859-2: Latin2)

  • Page 126: Iso8859-15: Latin9)

    Page 40 (ISO8859-15: Latin9)

  • Page 127: Pc1098: Farsi)

    Appendix Page 41 (PC1098: Farsi)

  • Page 128: Pc1118: Lithuanian)

    Page 42 (PC1118: Lithuanian)

  • Page 129: Pc1119: Lithuanian)

    Appendix Page 43 (PC1119: Lithuanian)

  • Page 130: Pc1125: Ukrainian)

    Page 44 (PC1125: Ukrainian)

  • Page 131: Wpc1250: Latin 2)

    Appendix Page 45 (WPC1250: Latin 2)

  • Page 132: Wpc1251: Cyrillic)

    Page 46 (WPC1251: Cyrillic)

  • Page 133: Wpc1253: Greek)

    Appendix Page 47 (WPC1253: Greek)

  • Page 134: Wpc1254: Turkish)

    Page 48 (WPC1254: Turkish)

  • Page 135: Wpc1255: Hebrew)

    Appendix Page 49 (WPC1255: Hebrew)

  • Page 136: Wpc1256: Arabic)

    Page 50 (WPC1256: Arabic)

  • Page 137: Wpc1257: Baltic Rim)

    Appendix Page 51 (WPC1257: Baltic Rim)

  • Page 138: Wpc1258: Vietnamese)

    Page 52 (WPC1258: Vietnamese)

  • Page 139: Kz1048: Kazakhstan)

    Appendix Page 53 (KZ1048: Kazakhstan)

  • Page 140: User-Defined Page)

    Page 255 (User-Defined Page)

  • Page 141: International Character Sets

    Appendix International Character Sets ASCII code (Hex) Country France Germany U.K. Denmark I Sweden Italy Spain I Japan Norway Denmark II Spain II Latin America Korea Slovenia/ Croatia China Vietnam Arabia...

Table of Contents
