- Page 1 WALKEASE, MOTORIZED TREADMILL OWNER’S MANUAL MODEL# 97295 2011, June...
-
Page 2: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY LifeGear Inc. warrants to the original purchaser that this product is free from defects in material and workmanship when used for the purpose intended, under the conditions that it has been installed and operated in accordance with LifeGear's Owner's Manual. LifeGear's obligation under this warranty is limited to replacing or repairing, free of charge, any parts which may prove to be defective under normal home use. - Page 3 Basic precautions should always be followed, including the following safety instructions when using this treadmill: Read all instructions before using this treadmill. DANGER: To reduce the risk of electric shock, please read the following: Always unplug the treadmill from the electrical outlet immediately after using and befor cleaning, assembling, or servicing. NOTE: Failure to follow these instructions may lead to personal injury and cause damage to the treadmill.
- Page 4 Only one person should be on the treadmill while in use. Always hold on to the handrails while using the treadmill. Always make sure the storage latch is in place when folding and moving the treadmill. Do not leave children who are under 12 year-old unsupervised near or on the treadmill. Pull up the Safety Tether Key for emergency stop.
- Page 6 Part # Description Quantity Part # Description Quantity Main Frame End Cap (25x50) Base Frame Upper Dust Cover Adjustable Pad Lower Dust Cover End Cap for Base Frame Screw (M4x60) Moving Wheel Left Handrail Computer Right Handrail Computer Bracket Handlebar Bolt (M5x10) End Cap for Handlebar Running Deck...
- Page 7 Part # Description Quantity Part # Description Quantity Left Rear Cap Bolt (M8x12) Right Rear Cap Bolt (M8x45) Incline Beam Bolt (M4x12) End Cap for Incline Beam Carriage Bolt (M8x45) Bolt (M10x40) Spacer Ø 14xØ 10x5.5mm Bushing Ø 16xØ 10.5x15.5mm Round Head Bolt (M8x45) Tapping Screw (ST4x10) Nylon Nut (M4)
- Page 8 Part # Description Quantity Bolt (M8x45)-------------------------------------------------------------------------------------------------4 Bolt (M8x16)-------------------------------------------------------------------------------------------------6 Spring Washer (M8)---------------------------------------------------------------------------------------6 Allen Wrench/Screwdriver Wrench 1 PC 1 PC Allen Wrench Silicone Oil (6 ml) 1 PC...
- Page 9 Step 1 Connect the Sensor Cable I (38) from the Base Frame (2) to the Sensor Cable II (39) from the Right Handrail (35) and then attach the Right and Left Handrails (35, 34) to the Base Frame (2) with six M8x16 Bolts (50) and M8 Spring Washers (55).
- Page 10 Step 4 Remove four M5x10 Bolts (8) from the back of the Computer (6). Connect the Sensor Cable III (40) from the Handlebar (36) to the socket that comes from the Computer (6) and then attach the Computer (6) onto the Computer Bracket (7) with four M5x10 Bolts (8) that were removed.
-
Page 11: Folding Up The Treadmill
Folding Up the Treadmill Place one hand on the rear end of deck and the other hand to pull the Spring Knob, then lift the deck up from the rear of treadmill until the Spring Knob "pops" down into the locked position. (See diagrams A and B.) Check the Spring Knob is "pop"... -
Page 12: Quick Start
Quick Start: Press the Master Power Switch that is located at the front of the treadmill to ON position. Before beginning a workout session ensure that the Safety Tether Key is properly installed onto the Computer Console and the Safety Clip is securely attached to an article of your clothing. -
Page 13: Computer Functions
Computer Functions: TIME: Displays your elapsed workout time in minutes and seconds. Press the START button and then press the SPEED + button, the running belt starts moving with the speed at 0.8km/h. You may press the SPEED + or SPEED - button to increase or decrease the running speed during exercise. - Page 14 CALORIES: Displays the total accumulated calories burned during workout. Press the START button and then press the SPEED + button, the running belt starts moving with the speed at 0.8km/h. You may press the SPEED + or SPEED - button to increase or decrease the running speed during exercise.
-
Page 15: Troubleshooting Guide
WARNING: To prevent electrical shock, please turn off and unplugged the treadmill before cleaning or routine maintenance. CLEANING The treadmill can be cleaned with a soft cloth and mild detergent. Do not use abrasives or solvents. Be careful not get excessive moisture on the display panel as this might cause an electrical hazard or electronics to fail. -
Page 16: Running Belt Adjustment
Running Belt Adjustment: The running belt is adjusted at the factory; it may come loose during transportation and from use. After prolong use of running, the belt will stretch out. If the running belt is shifting to the left, turn on the main power switch of treadmill and let the running belt run at the speed of 2~3 km/h. - Page 17 A good exercise program consists of a warm-up, aerobic exercise, and a cool down. Do the entire program at least two to three times a week, resting for a day between workouts. After several months you can increase your workouts to four or five times per week.
-
Page 18: Inner Thigh Stretch
SIDE STRETCHES Open your arms to the side and lift them until they are over your head. Reach your right arm as far toward the ceiling as you can for one count. Repeat this action with your left arm. QUADRICEPS STRETCH With one hand against a wall for balance, reach behind you and pull your right foot up. -
Page 19: Calf/Achilles Stretch
TOE TOUCHES Slowly bend forward from your waist, letting your back and shoulders relax as you stretch toward your toes. Reach as far as you can and hold for 15 counts. HAMSTRING STRETCHES Extend your right leg. Rest the sole of your left foot against your right inner thigh. - Page 20 e-mail:lifegear@lifegear.com.tw...
