- Page 1 PC VGA to TV Video Converter - Ultimate XP ID# 519 Operation Manual...
- Page 2 The PC VGA to TV Video Converter - Ultimate XP is ideal for Professions like Advertising, Academic Lecturers, Retail Businesses or just for Home use, the PC VGA to TV Video Converter - Ultimate XP has simple and easy to use controls.
- Page 3 2. VIDEO OUT : Connects ULTIMATE XP to the VIDEO input of TV , VCR or Video projector. 3. S-VIDEO OUT : Connects ULTIMATE XP to your TV , VCR or Video projector supporting the S-VIDEO input. 4. RGB OUT (SCART) : Connects ULTIMATE XP to the RGB input of TV - VCR or Video projector.
- Page 4 NTSC, NTSC-EIAJ and PAL-M is 60Hz. The refresh rate of PAL- N, PAL and PAL combination N is 50Hz. 4. FINE TUNE : Press this to fine-tune the video image. (the same as sharpness) 5. MENU : Press this button to cyclically activate the functions. The functions are Freeze, Horizontal SIZE (H-SIZE), Vertical SIZE (V- SIZE), Brightness, Contrast, Hue, Saturation, Flicker, OSD color &...
- Page 5 Installation for IBM PC Users The PC VGA to TV Video Converter - Ultimate XP is a "Plug and Display" video converter. The only thing required to get the image of computer on TV is to make the proper connection. Please read the following sections carefully for the installation of the hardware.
- Page 6 TV picture. Step 4 : Connect one end of the supplied USB or PS/2 power cable to the DC IN port on the ULTIMATE XP and connect the other end to your PC. Step 5 Power on your PC.
- Page 7 Specifications Video Type: NTSC/PAL. • Video Outputs: Composite (RCA socket) & S-Video • (4pin mini-din socket), RGB (9pin mini- din socket). PC/Monitor Connections: 15 pin D-sub socket (Y cable) • Power Supply: 5vDC • Power Source: PC USB or PS/2 port •...
