Ink bottle replacement and charging

This unit manages the use-by date and the amount of ink remaining by reading the information of ink IC chip
attached on the ink bottle.
Replace the ink bottle, according to the following procedures.
1
Replace the inkbottle.
(1) Remove the bottle cap.
(2) Insert the ink pipe near the center of the inside pig.
• Be sure to check the type and color of
• If its insertion is not enough, it becomes
• In such a case, widen the insertion of
2
Insert the ink IC chip into the ink IC slot.
• Use the IC chip attached on the ink bottle.
• Insert the ink IC chip facing the contacts of IC chip up.
• Do not dirty or damage the contact of ink IC
3
Confirm the information of ink IC chip, and press
key.
• Confirm the color, ink type, capacity displayed on the
display. If incorrect, press
• When an error message such " WRONG INK IC " is
displayed, remove the IC chip once and reinsert it.
• The ink IC chip charged once cannot be
4
Confirm the charge completion display.
• When the ink charging is normally completed, the new ink
remaining amount is displayed.
• Reinsert the IC chip when an error occurs.
• Do not remove the ink IC chip during charging. It may cause a trouble of unit or ink IC chip.
ink to be set before replacement.
impossible for ink to use up to the last.
inner cap until the pipe can move
downward with its own weight.
If the pipe moves upward, you cannot
use ink up to the last.
chip.
It may cause not to read the stored
information correctly.
key and reenter.
undone.
Be sure to press
displayed information is confirmed.
Contacts
of IC chip
key after the
Fitting
< L O C A L >
w i d t h : 1 0 0 0 mm
IC chip
IC chip information
C O L : K C S 1 0 0 : 2 0 0 0 c c
C H A R G E S T A R T
(In charging)
* * C H A R G I N G * *
D O N ' T R E M O V E I N K
Charging completion
C O M P L E T E I N K C H A R G E
C O L : K C S 1 0 0 : 2 0 0 0 c c
1
3
[ E N T ]
4
I C
5
6
