This document bridges the gap between the Fiery XF documentation and the Mimaki UJV55-320 documentation.
Refer to the Installation section before you connect the printer to a computer.
The Operation section has information on profile generation and everyday use. Please refer also to the Operation
Manual.
For a UJV55-320 printer, select the Fiery XF driver that matches the ink configuration in the printer:
Fiery XF model
Mimaki UJV55-320 CMYK
Mimaki UJV55-320 CMYKcmW
From the computer viewpoint, the Mimaki UJV55-320 is a special USB device with Ethernet support. The latest driver is
downloadable from
http://www.mimaki.co.jp/
Follow the instructions in the Mimaki USB Driver Install Guide before you connect the printer. Mimaki USB Driver
version 4.0 or later is recommended. Furthermore, the Mimaki network driver is supported from version 1.2 onwards.
1 Install Fiery XF and the latest Fiery XF service pack that supports the Mimaki UJV55-320 printer. The minimum
requirement is Fiery XF 7.1.
2 To configure the Fiery XF printer:
• In System Manager, add the printer by clicking on the plus (+) icon and selecting "Mimaki"as the manufacturer
and "
Mimaki UJV55-320 CMYKcmW
• In the Connection panel. select the Connection type "Print via port" or "Print via IP network".
Description
Double CMYK set for higher speed and uninterruptible ink supply
Ink type: UV Curable Ink (LUS-120)
CMYKcm, plus White
Ink type: UV Curable Ink (LUS-120)
" as the printer type.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MIMAKI UJV55-320
Summary of Contents for MIMAKI UJV55-320
- Page 1 Mimaki UJV55-320 CMYKcmW CMYKcm, plus White Ink type: UV Curable Ink (LUS-120) From the computer viewpoint, the Mimaki UJV55-320 is a special USB device with Ethernet support. The latest driver is downloadable from http://www.mimaki.co.jp/ Follow the instructions in the Mimaki USB Driver Install Guide before you connect the printer. Mimaki USB Driver version 4.0 or later is recommended.
- Page 2 Printer supplement In Color Tools, select the printer for which you want to create a calibration file. The calibration file forms the basis for creating a media profile. • You can access the ink layers settings via the “Media type” setting. •...
- Page 3 Printer supplement Separated file formats, e.g. PS, PDF, EPS, support spot colors. For Fiery XF, the spot color name WHITE_INK has a special meaning. It is a pre-defined printer-specific internal spot color. During job processing, it goes directly to the printer, by-passing color management.
- Page 4 Printer supplement • Print mode There are six ways to print White: Name Meaning The spot color of this name or alias from a separated document prints White. This is the Spot color WHITE_INK default mode. Inked image Every pixel which does not have CMYK = 0,0,0,0 on the printer side adds White Every pixel in the image rectangle adds White.
- Page 5 Printer supplement The temperature can be set either through Fiery XF (20 – 60 °C) or at the printer control panel. • Refresh Level - For nozzle clogging prevention, set the amount of ink to be discharged from the nozzle. •...
- Page 6 Printer supplement • Mimaki UJV55-320 CMYKcmW Serial. Printing order Resolution Media type White mode Off 300 x 600 dpi Tarpaulin/PVC 300 x 900 dpi 600 x 900 dpi 900 x 1200 dpi PVC/Soft media 1200 x 1200 dpi 600 x 600 dpi...
