- Page 1 BEDIENUNGSANLEITUNG INSTRUCTION MANUAL Luftentfeuchter Air Dehumidifier Series DS 10 DS 20 DS 40 DS 10 / 20 / 40 2014 Rev. 2...
-
Page 2: Table Of Contents
Transport and installation ____________________________________ 6 Transport __________________________________________________ 6 Installation__________________________________________________ 6 Operation and operator control________________________________ 6 Series DS 10 / 20 / 40 operating elements _________________________ 7 Maintenance and service _____________________________________ 9 Cleaning and filter change ____________________________________ 10 Spare parts and customer service ______________________________ 11... -
Page 3: Notes On This Instruction Manual
Qualification of staff This instruction manual addresses all users / operators of the devices manufactured by AERIAL. These persons must have read and understood the instruction manual. The device may only be operated by persons commissioned and instructed by the user. -
Page 4: Operating Conditions
Improper operation or misuse will cause danger to: the operator, the device and other material property of the user, efficient operation of the device. All persons installing, operating, servicing or cleaning the device must be aware of the risks related to electrical equipment operated in a damp ... -
Page 5: Performance Description
Scope of delivery Air dehumidifier Tank for condensate produced: 2.5 l for DS 10 and DS 20 7.2 l for DS 40 One instruction manual B – 4... -
Page 6: Device Description
Device description Fig. 1: Air dehumidifier DS 10 / 20 / 40 overview Recessed grips Filter retainer Drain pipe for condensate Air intake with filter hose Tank Air flaps for air outlet Operating panel Castors The condensate can be collected in the tank (Fig. 1, item 7) supplied with the device or discharged directly into an outlet by connecting a condensate hose to the condensate drain pipe on the device. -
Page 7: Transport And Installation
Transport and installation Transport Danger to life due to electric shock Touching live parts can lead to death. DANGER Switch off the device via the on/off switch, disconnect the mains plug from the socket outlet and empty the water tank before moving the device! ... -
Page 8: Series Ds 10 / 20 / 40 Operating Elements
Series DS 10 / 20 / 40 operating elements Fig. 2: Series DS 10 / DS 20 operating panel Display of operating states and Green pilot lamp - fan stage current humidity "low" active Timer, adjustable in full hours Fan, speed setting... - Page 9 If you the device is used as laundry dryer adjust the air flaps (Fig. 1, item 3) so that the air is blown directly onto the laundry. We recommend the following adjustments: - ironing dry: relative humidity = 55 % - cupboard dry: relative humidity = 40 % The stated values are guide values and must, if necessary, be adjusted to the local conditions.
-
Page 10: Maintenance And Service
Use the hygrostat (Fig. 2 and Fig. 3, item 11) to set the desired humidity. During setting. the selected humidity value is indicated in the display (Fig. 2, item 1 / Fig. 3, item 9). After setting, the current humidity is displayed in per cent.. If the existing humidity is higher than the set value the device will start. -
Page 11: Cleaning And Filter Change
In order to guarantee trouble-free functioning of the device also in continuous operation the device - in particular the air filter - must be checked and cleaned at regular intervals. Fig. 4: DS 10 / DS 20 filter change (on the left), DS 40 without filter Filter Proceed as follows: Switch the device off. -
Page 12: Spare Parts And Customer Service
Insert new or cleaned filter. Connect power cable. The device is ready for operation. Spare parts and customer service If you have any question concerning the device, or if you need spare parts, please contact your authorised dealer or the customer service. Troubleshooting In the event of any malfunctions please check at first the following points. -
Page 13: Shutdown, Storage And Disposal
Problem Possible cause Remedy The device The device does not Install it on a level surface and generates noise stand on a level surface ensure that the condensate is and vibrates or properly discharged condensate is leaking out The device Air circulation is Check the air openings for generates noise,... -
Page 14: Disposal
Protection class IP X0 Operating conditions + 5 °C to + 32 °C 40% r. h. to 95% r. h. Type Unit DS 10 DS 20 DS 40 Air circulation rate Fan speed I cbm / h Fan speed II... -
Page 15: 11 Ec Declaration Of Conformity
AERIAL GmbH - Systeme zur Luftbehandlung Oststraße 148, D-22844 Norderstedt Product description: - Air dehumidifier Series DS 10 - Air dehumidifier Series DS 20 - Air dehumidifier Series DS 40 The product described is an air dehumidifier ready for connection. - Page 16 Phone 0049 (0) 40 526 879 0 Telefax 526 879 20 E-Mail: info@aerial.ch Internet: www.aerial.ch klima24.ch E-Mail: info@aerial.de Internet: www.aerial.de Niederlassung Österreich: Untere Sprachen 18 A 6330 Kufstein Phone +43 5372 22468-10 Telefax +43 5372 22468 -20 E-Mail: info@aerial-gmbh.at DS 10 / 20 / 40 2014 Rev. 2...
