Table Of Contents - Sun Microsystems X7198A Owner's Manual

Index
Warning, Caution ......................................................................................................................... English-1
Unpacking the Flat Panel LCD Monitor ........................................................................................ English-2
Contents ....................................................................................................................................... English-3
Front Panel Overview .................................................................................................................. English-4
Back Panel Overview ................................................................................................................... English-5
Quick Start ................................................................................................................................... English-6
Controls ...................................................................................................................................... English-10
Safty Instractions ....................................................................................................................... English-12
Specifications ............................................................................................................................. English-14
Features ..................................................................................................................................... English-15
Troubleshooting ......................................................................................................................... English-16
TCO'03.......................................................................................................................................English-17
Manufacturer's Recycling and Energy Information .................................................................... English-18
Preliminary Information
• Recommended timing: 1280x1024x60
(Alternate 1280x1024 timings will work with the analog mode only. No composite sync
timings, such as 1280x1024x75 or 1280x1024x75 will work for the DVI digital input)
• DVI input is preferred
• For DVI input, many OSD items are not active due to the high quality and precision and
quality of the digital DVI signals.
• This monitor will not scale alternate resolutions natively, and using resolutions <1280x1024
will fill the screen in a way which degrades the video quality. Only 1280x1024x60 should be
used to assure optimal video performance.
Features
• 4-position joystick for ease of navigation of OSD.
• Tilt, height adjustment, and swivel
• Cable management inside rear cover
• Master power switch to assure all power to the monitor is disabled.
• Plug and Play: Allows the monitor to send its capabilities (such as screen size and
resolutions supported) directly to your computer, automatically optimizing display performance.
• No Touch Auto Adjust automatically adjusts your optimal image settings upon initial power-on.
(Analog only)
15503961-cover 2 3/1/2005, 6:01 PM
