The tting of an extractor fan in the same room as the stove, or
an adjacent room is not permitted. A spillage test will be required
to determine how any extractor fans may a ect the required size
of ventilation requirements.
For more detailed guidelines on required ventilation sizes please refer to the
HETAS Guide which can be found on the HETAS website.
If you plan to use an external air supply on a suitable stove, and have bought
the appropriate Arada External Air Supply Kit, please refer to the instructions
included with the kit on how to install it.
The accompanying stove technical product sheet states whether or not your
appliance is compatible with a Direct Air Supply Kit.

2.4 Fitting the ue outlet

The ue outlet spigot may be tted onto the stove, but will not be fully
tightened.
Figure 1: Fitting the ue outlet for a rear ue con guration.
The ue outlet assembly can be orientated for top or rear ue exit as shown
in gure 1 and 2 on the following page.
The outlet pipe ange is pre tted with a gasket rope seal. Additional re
cement may be added if required.
