- Page 1 P80184021A 050310 5/3/10 5:10 PM Page 1 gas barbecue professional 482 Assembly instructions premium 382 Instructions d’assemblage Montageanweisungen Istruzioni per il montaggio Montage-instructies Montering Kokoamisohjeet Instrucciones de armado Instruções para Montagem Monteringsvejledning Montering...
-
Page 2: Built-In Installation
P80184021A 050310 5/3/10 5:10 PM Page 2 WARNINGS INFORMATION BUILT-IN INSTALLATION DO NOT OBSTRUCT THE VENTILATION OPENINGS IN THE TROLLEY. NE PAS BOUCHER LES OUVERTURES DE VENTILATION DANS LE CHARIOT. NICHT DIE VENTILATIONSÖFFNUNGEN IM WAGEN BLOCKIEREN. NON OSTRUIRE LE APERTURE DI VENTILAZIONE DEL CARRELLO. DE VENTILATIEOPENINGEN IN DE TROLLEY NIET BLOKKEREN. -
Page 3: Cooking Component Installation
P80184021A 050310 5/3/10 5:10 PM Page 3 IGNITION BATTERY LIGHT BBQ WITH MATCH Right body panel Match Lighting battery tube Igniter Spring Contact COOKING COMPONENT INSTALLATION Secondary cooking / warming rack, Ref # 7 Hot plate, Ref # 8b TEMPERATURE GAUGE Flame tamer, Ref # 9 Grill plate, Ref # 8a Pot support, Ref # 6... - Page 4 P80184021A 050310 5/3/10 5:10 PM Page 4 INJECTOR WARNINGS INFORMATION • MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS MUST BE: REAR – 450 mm SIDES – 250 mm TOP – 1000 mm Main burner Side burner Rotisserie burner 250 mm 250 mm •Main 1.00 mm –...
- Page 5 P80184021A 050310 5/3/10 5:10 PM Page 5 COOKING WITH HOOD OPEN COOKING WITH HOOD DOWN 250˚...
-
Page 6: Parts List
P80184021A 050310 5/3/10 5:10 PM Page 6 PARTS LIST Ref Description 382 Part # 482 Part # Qty Ref Description 382 Part # 482 Part # Hood assembly P00146179C P00119126A Control knob – main burner P03419123M P03419153H Hinge support – left P00127414C 25a Control knob –... - Page 7 P80184021A 050310 5/3/10 5:10 PM Page 7 PARTS DIAGRAM – Premium 382 This diagram is provided to assist you identify parts if replacement is necessary. Contact your place of purchase to enquire about parts, availability and or service. Items included in your barbecue specification may differ from the parts list, depending on region or specific dealer specification.
- Page 8 P80184021A 050310 5/3/10 5:10 PM Page 8 PARTS DIAGRAM – Professional 482 This diagram is provided to assist you identify parts if replacement is necessary. Contact your place of purchase to enquire about parts, availability and or service. Items included in your barbecue specification may differ from the parts list, depending on region or specific dealer specification.
- Page 9 P80184021A 050310 5/3/10 5:10 PM Page 9 THIS PAGE HAS BEEN LEFT BLANK...
- Page 10 P80184021A 050310 5/3/10 5:10 PM Page 10 THIS PAGE HAS BEEN LEFT BLANK...
- Page 11 P80184021A 050310 5/3/10 5:10 PM Page 11 THIS PAGE HAS BEEN LEFT BLANK...
- Page 12 P80184021A 050310 5/3/10 5:10 PM Page 12 SERVICE service@grandhall.eu Grand Hall Europe PO Box 431 7570 AK Oldenzaal The Netherlands T: +31 (0) 541 531669 F: +31 (0) 541 534563 www.grandhall.eu NOTE: This information is a guide only. Items included in your BBQ All specifications are subject to change specification may differ depending on region or specific dealer specification.
