- Page 1 Maxim 499P Assembly instructions Instructions d’assemblage Montageanweisungen Istruzioni per il montaggio Montage-instructies Montering Kokoamisohjeet Instrucciones de armado Instruções para Montagem Monteringsvejledning Montering...
- Page 2 PARTS DIAGRAM - Maxim 499P This diagram is provided to assist you identify parts if replacement is necessary. Contact your place of purchase or the manufacturer to enquire about parts, availability and or service. Items included in your barbeque specification may differ from the parts list, depending on region or specific dealer specification.
- Page 3 PARTS LIST - 499P Ref Description Part Ref Description Part Hood P0015407F6 – back burner - 30mbar P06509003A Hood hinge set Y0200007 - 50mbar P06535001A Temperature gauge P00601451E Back burner extension tube P03717046A Hood hinge support – left P00127434B Control knob – back P03436071R Hood hinge support –...
- Page 4 ASSEMBLY OPEN LEFT CABINET SIDE PANEL ASSEMBLY INSTALL LEFT CABINET REAR PANEL • Install the rear panel as shown, then tighten the four screws Ref # 67 Hole for NG connection INSTALL LEFT CABINET BOTTOM SHELF AND INSTALL GAS CYLINDER BRACKET UPPER PARTITION PANEL •...
- Page 5 INSTALL LEFT DOOR OPEN RIGHT CABINET SIDE PANEL ASSEMBLY Step 1 Ref # 68 NOTE: Spring hinge pin to bottom. Step 2 INSTALL RITHT CABINET REAR PANEL INSTALL TRANSFORMER • Install the rear panel as shown, then tighten the four screws.
- Page 6 INSTALL RIGHT CABINET BOTTOM SHELF AND INSTALL SIDE BURNER GREASE RECEPTACLE MIDLLE PARTITION PANEL AND RIGTHT CABINET UPPER PARTITION PANEL • Install the bottom shelf as shown. • Install upper partition panel as shown, then tighten the four screws. • First attach two screws half hung on the "...
- Page 7 INSTALL BARBEQUE HEAD • Remove cooking components from barbeque head. With an assistant, lift and position barbeque head on the cabinet. • Tighten securely using screws. • Note: feed gas regulator through the opening in the top panel, close the shutter after assembly is complete. Phillips flat-head screw "...
- Page 8 Socket Plug CONNECT SIDE BURNER GAS VALVE Diagram A. NOTE: Remove plastic protection sleeve from male fitting before connecting side burner hose. • Position hose socket over valve plug. See diagram A. Sleeve Diagram B. • Pull and hold back socket sleeve. •...
-
Page 9: Connect Transformer
COOKING COMPONENT INSTALLATION IGNITION BATTERY Secondary cooking / warming rack Ref # 12 Grill plate Ref # 13 Flame tamer Ref # 15 battery Igniter Hot plate Spring Contact Ref # 14 Slots for secondary cooking / warming rack CONNECT TRANSFORMER TEMPERATURE GAUGE CONNECTION GAS CONNECTION Light wire... - Page 10 INJECTOR WARNINGS INFORMATION • MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS MUST BE: REAR - 450 mm SIDES - 250 mm TOP - 1000 mm 1.00 1.00 1.05 Main Side Rotisserie 250mm • Main / Rotisserie 1.00 mm – I 3+ (28-30/37) –...
- Page 11 COOKING WITH HOOD OPEN COOKING WITH HOOD DOWN 250˚...
- Page 12 Grand Hall Europe PO Box 431 7570 AK Oldenzaal The Netherlands www.grandhall.eu NOTE: This information is a guide only. Items included in your BBQ All specifications are subject to change specification may differ depending on region or specific dealer specification.
