Grandhall Odeon Assembly Instructions Manual
Outdoor kitchen
Hide thumbs
Also See for Odeon:
- Operating instructions manual (52 pages) ,
- Assembly instructions manual (12 pages)
Advertisement
Quick Links
OUTDOOR KITCHEN
Assembly instructions
IE
GB
Instructions d'assemblage
CH
FR
Montageanweisungen
AT
CH
DE
Istruzioni per il montaggio
CH
IT
Montage-instructies
LU
BE
NL
Montering
SE
Kokoamisohjeet
FI
Instrucciones de armado
ES
Instruções para Montagem
PT
Monteringsvejledning
DK
Montering
NO
Instrukcje
PL
Odeon
0087
Advertisement
Related Manuals for Grandhall Odeon
Summary of Contents for Grandhall Odeon
- Page 1 Odeon OUTDOOR KITCHEN Assembly instructions Kokoamisohjeet 0087 Instructions d’assemblage Instrucciones de armado Montageanweisungen Instruções para Montagem Istruzioni per il montaggio Monteringsvejledning Montage-instructies Montering Montering Instrukcje...
- Page 2 ASSEMBLY CAUTION : While possible for one person to assemble this barbecue, it is recommended obtaining assistance from a second person when handling some of the larger heavier pieces. Install rear trim panel onto grill head and grease tray Pan Head Screw 3/16"x3/8"...
- Page 3 Install gas cylinder LEAK CHECK GAS CONNECTIONS Install grease tray heat shield and cooking components. hen grill is hot use the grate lifter to lift this round cooking grid on or off W o k support CAUTION : Refer to this table when designing the island unit for the grill. Side and Rear show the minimum amount of distance the unit must be from combustibles e .
- Page 4 – I 3B/P (30) 0.90 mm – I 3B/P (50) INPUT 18.4 kW – 1335 grams / h NOTE: Register your Outdoor Kitchen at www.grandhall.eu For Tips and Tricks, visit www.grandhall.eu/tips Push and hold COOKING WITH HOOD OPEN COOKING WITH HOOD DOWN...
-
Page 5: Parts List
PARTS LIST Description Part # Description Part # Hood Hood P00147319B Electrode – LR P02618047A Temperature gauge P00601381B Electrode – RR P02618048A Hood handle bracket – left P00307028E Electrode – RF P02618049A Hood handle bracket – right P00308028E Heat shield bracket P0300612FD Hood handle P00215036H... -
Page 6: Parts Diagram
PARTS DIAGRAM This diagram is provided to assist you identify parts if replacement is necessary. Contact your place of purchase or the manufacturer to enquire about parts, availability and or service. Items included in your barbecue may differ from the Parts List, depending on region or specific dealer specifications. - Page 7 NOTES...
- Page 8 SERVICE 7,475,632 service@grandhall.eu Grand Hall Europe PO Box 431 7570 AK Oldenzaal The Netherlands T: +31 (0) 541 531669 F: +31 (0) 541 534563 www.grandhall.eu NOTE: This information is a guide only. Items included in your BBQ All specifications are subject to change specification may differ depending on region or specific dealer specification.
