- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Grand Hall UN3212ACT Owner's Manual Shop genuine replacement parts for Grand Hall UN3212ACT Find Your Grand Hall Grill Parts - Select From 203 Models -------- Manual continues below --------...
- Page 2 Replacement of Damaged or Missing parts properly assembled, installed and maintained. visit www.grandhall.com or call: Ÿ Use your grill at least 3 feet away from any wall or surface. Use your grill at least 3 feet...
-
Page 3: Table Of Contents
Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions.......3 Do not store or use gasoline or other Part Diagrams and Lists......4-13 flammable liquids or vapors in the Assembly Instructions.........14-17 vicinity of this or any other appli- Use & Care Instructions: ances. -
Page 4: Pre-Assembly Instructions
Pre-Assembly Instructions For Your Safety PRE-ASSEMBLY CAUTION Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury. -
Page 5: Part Description
Hardware Parts List for Models BTE3212BLP/NG & BTE3812BLP/NG PART # PART DESCRIPTION PURPOSE OF PART For use in assembly of Model BTE3212BLP/NG, P06013018A Hardware Pack BTE3812BLP/NG S182G03061 Pan Head Screw 3/16" x 3/8" Install the Transformer Bracket Install the Bracket with LP Regulator S182G03061 Pan Head Screw 3/16"... - Page 6 Parts Diagram for Models BTE3212ALP/NG & BTE3212BLP/NG 26 25...
- Page 7 Parts List for Models BTE3212ALP/NG & BTE3212BLP/NG DESTRIPTION PART# QTY. Lid Assembly P0014734AA Tem perature Gauge P00601551A Tem perature Gauge Seat P00614031A Lid Handle Bracket, Left P00307058N Lid Handle Bracket, Right P00308058N Lid Handle P00215039H Protective Pad P05518002I Lid Assembly Bracket, Left P03320007C Lid Assembly Bracket, Right P03320008C...
- Page 8 Parts List for Models BTE3212ALP/NG & BTE3212BLP/NG DESTRIPTION PART# QTY. Lam p Wire Set Protector P05533011A Lam p,12V, 10W P05352012B Lam p Cover P05352013E Back Burner Frame P02011075B Back Burner Assembly (LPG) Y0030028 Back Burner Assembly (NG) Y0030029 Back Burner Extension Tube P03701011A Back Burner Cover P06906099C...
- Page 9 Parts Diagram for Model BTE3812BLP/NG 25 24...
- Page 10 Parts List for Model BTE3812BLP/NG DESTRIPTION PART# QTY. Lid Assembly P0011979AA Tem perature Gauge P00601551A Tem perature Gauge Seat P00614031A Lid Handle Bracket, Left P00307058N Lid Handle Bracket, Right P00308058N Lid Handle P00215040H Protective Pad P05518002I Lid Assembly Bracket, Left P03320007C Lid Assembly Bracket, Right P03320008C...
- Page 11 Parts List for Model BTE3812BLP/NG DESTRIPTION PART# QTY. Lam p Cover P05352013E Back Burner Frame P02011076B Back Burner Assem bly (LPG) Y0030028 Back Burner Assem bly (NG) Y0030029 Back Burner Extension Tube P03701011A Back Burner Cover P06906099C Thermocouple Protector P03328050C Thermocouple for Back Burner P05305072B Back Burner Electrode...
- Page 12 Parts Diagram for Model UN3212ACT(OPTIONAL)
- Page 13 Parts List for Model UN3212ACT(OPTIONAL) DESTRIPTION PART# QTY. LP Regulator Hose Holder P055360034 Grill Bowl Trim Panel, Left P007420264 Grill Bowl Trim Panel, Right P007430564 Cart Side Panel, Left P076020294 Cart Side Panel, Right P076030324 Side Shelf, Left P01106052B Side Shelf, Right P01107048B Side Shelf Trim Plate, Left P07503023A...
- Page 14 Rotisserie Assembly Parts Diagram for BTE3212A(B)LP/NG & BTE3812BLP/NG Rotisserie Assembly Parts List for BTE3212A(B)LP/NG & BTE3812BLP/NG PART# DESCRIPTION Rot. Collar P05508229A Rot. Thumbscrew 1/4"x1/2" S196G04081 Rot. Spit (for BTE3212B(A)LP/NG Models) P05508230A Rot. Spit (for BTE3812BLP/NG Models) P05508231A Rot. Holding Fork P055082125 Rot.
- Page 15 Installation Instructions for Models BTE3212BLP/NG & BTE3812BLP/NG NOTE: The grill head you purchased is to be installed on the island which is not included in this purchase. You either need to purchase a prebuilt island or you have to build your own island. Before building your grill island, please read the construction guidelines and clearances in Fig.6 and on pages 16 &...
- Page 16 Install Natural Gas(NG) Regulator and 12 Foot Hose Connect the NG regulator to the inlet of gas manifold. (See Fig. 4) Connect the swivel nut of the 12 ft. NG hose to the vertical fitting of the NG Regulator. WHEN YOU FINISHED THIS STEP, PLEASE SKIP TO STEP 6. Gas Manifold NG Regulator Vertical fitting...
- Page 17 Install Partition Panel The gas grill is designed for use with a maximum of 20 lb tank. As per standard, a partition panel (not included) or equivalent device is required to be installed in the left cabinet of the island for preventing the use of 30 lb tank.
- Page 18 Main Burner Electrode Check with the Warming Rack assistance of another person, perform this Electrode Check before proceeding. Cooking Grids This test will ensure that the Spark Electrode Flame Tamer Tips are properly positioned so your grill lights easily. Flame Tamer Rack Be sure all control knobs are set to "OFF"...
-
Page 19: Use & Care Instructions
USE AND CARE INSTRUCTIONS Keep fire extinguisher readily accessible. In the event CORRECT LP GAS TANK USE of a oil/grease fire, do not attempt to extinguish with LP Gas grill models are designed for use with a standard water. Use type B extinguisher or smother with dirt, 20 lb. - Page 20 USE AND CARE INSTRUCTIONS LP Gas Model only: NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Grill Ÿ Many retailers that sell grills offer you the option of (for BTE3212BLP & BTE3812BLP) replacing your empty LP Gas tank through an exchange service.
- Page 21 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.
-
Page 22: Natural Gas Connection
Natural Gas Connection Fig.1 Natural Gas Model only: Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Hose to the vertical fitting of NG Regulator as shown in Fig.1. Connect the other hose end Vertical Fitting (male plug) to the gas supply line from your Swivel Nut... -
Page 23: Grill Lighting Instructions
USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened. -
Page 24: Troubleshooting
USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset If the grill fails to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait at least 5 minutes for gas to clear, then retry. Turn Control Knobs to the OFF position. - Page 25 USE AND CARE INSTRUCTIONS WARNING CORRECT ROTISSERIE USE Read all instructions before initial use. IMPORTANT: When using electrical appliances, basic safety To protect against electrical shock, do not immerse precautions should always be used. The Rotisserie Motor is set for 120V, 60Hz AC current. electrical cord, plugs or motor in water or expose to The Rotisserie is for outdoor use only.
-
Page 26: Rotisserie Instruction
Rotisserie Instructions 1. Remove all components from the carton. Attach the Motor Bracket on the outside of the right bowl side panel. Align the two holes of the Bracket with the holes on the right bowl side panel. Tighten securely using 2 Rotisserie Screws 3/16"x1/2" UNC, 2 Rotisserie Washers 3/16", and 2 Hex Nuts 3/16"... - Page 27 Slide the pointed end of the Spit through the piece of meat. Place the Holding Forks onto each end of the Spit. Adjust spacing between Holding Forks to accommodate your food, then tighten the Thumbscrews to keep the Holding Forks in position. Slide the Collar onto the square end of the Spit. Do not tighten the Collar Thumbscrew until the Rotisserie is placed into your grill.
-
Page 28: Cleaning And Maintenance
Cleaning Exterior Stainless Steel Surfaces: CLEANING AND MAINTENANCE Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures steel. - Page 29 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must clean the Burner Tubes as follows at least once a month in use, we recommend that you also complete the follow- ing cleaning regimens to help prolong Burner life.
-
Page 30: Cooking Instructions
Cooking Instructions Burn-Off Indirect Cooking using Main Burners Before cooking on your gas grill for the first time, you should "burn off" the grill to eliminate any odor or foreign The indirect cooking method can also be used with the matter. - Page 31 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on , close Lid and preheat your grill T-bone steak Medium: 10-14 minutes 10 to 15 minutes.
-
Page 32: Baking Techniques
Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance. - Page 33 Guide to Rotisserie Cooking Guide to Smoking Slow Cooking with a Rotisserie Preparing to Smoke Rotisserie cooking produces foods that are moist, flavor- Smoking gives food a distinctive, delicious flavor. You will find ful and attractive. The rotisserie system is most com- a variety of wood chips available for use in smoking grilled monly used for cooking meat or poultry and is designed foods.
-
Page 34: Warranty
Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light. - Page 35 To help main- tain the finish of stainless steel follow these cleaning pro- cedures for the best results: You may also review FAQ’s, Troubleshooting and Care & Maintenance Tips online at www.grandhall.com.
- Page 36 All remaining parts - 2 Year Limited Warranty Grand Hall will require reasonable proof of your date of purchase. Therefore, you should send in the owner registration card or register online at www.grandhall.com. Save your receipt in case it is required as proof of purchase.
