OPTIONAL UNIT INSTALLATION

You can install two of the following optional units in the transceiver.
UT-105
SmarTrunk II
UT-111
,
UNIT TRUNKING BOARD

' ' Installation

q Unscrew nut a, and remove the knobs.
w Unscrew screw b, 2 screws c then remove multi-connector
cover and rear panel.
e Unscrew 2 screws d, then remove multi-connector.
r Unscrew 2 screws e then separate the chassis from the front
panel in the direction of the arrow.
Be careful!: A flat cable is connected between the MAIN unit on the
t Install the desired optional unit. Insert tightly to avoid bad contact.
NOTE: When installing
UT-105 or UT-111, the
unit MUST BE plugged
into SLOT 1. Otherwise
the unit will not work cor-
rectly.
(Other optional units
can be plugged into either
slot.)
y Program the necessary information with the cloning software before
operation. Please ask your dealer or system operator for details.
TM Logic Board
,
chassis and front panel.
a
, UT-109/UT-110
UT-113
MAN DOWN UNIT
c
e
d
d
8
VOICE
SCRAMBLER
.
b
Slot 1
Slot 2
