4.3.9 Menu Button

The Menu button provides the user with access to the system settings and also allows for the enabling
of options. The Menu screen displays the following options:
•
Basic
•
User
•
Advanced
•
Tools
•
Language
•
Test

4.3.10 Basic Settings

Selecting the Basic button allows for access to the basic settings. These include the following:
•
Printer Mode
•
Media
•
Print Adjust
Printer Mode
The printer is available with several options which are enabled or disabled via the Printer screen. Three
of the modes cannot happen concurrently so the highest priority mode will take precedence. The order
is as follows:
1. Pause Mode (High)
2. Present Sensor Enable (Medium)
3. GPIO (Low)
a. Cutter Mode
The cutter supports the cutting of media into separate labels.
For printers with a print media cutter installed, select from the following Cutter Mode options:
•
Off
•
Cut By Label
•
Cut By Job
•
Cut By Count
Cut By Count enables the user to specify the number of labels printed prior to being cut. Select the Cut
By Count field and enter the number of labels to be printed.
