AT&T Definity 7313H User Manual page 6

Hold/Pause button
Liquid Crystal Display
(LCD)
Message button
Message light
Microphone/Mic button
Microphone light
Mode switch
Recall button
Ringer volume control
Set button
Speakerphone button
Speakerphone light
For putting a call on hold. The Pause subfeature is not
supported by AT&T DEFINITY
Generic 1. (Pause can be programmed into an abbreviated
dial string by pressing "8" rather than pressing the Pause
button.)
Available only on the 7315H and 7317H voice terminals, a
1-line, 16 character alphanumeric display, with the ability
to scroll to a second line, used as a clock, calendar, alarm,
and timer in Local mode, and used to display number
dialed, account code, and calling party ID in Normal mode.
A fixed feature button, not supported by AT&T
DEFINITY Communications System Generic 1.
A green light which goes on steadily when a message has
been left for you.
A fixed feature which comes on automatically when an
internal automatic answer call is answered. It can also be
turned on or off manually.
A green light which goes on steadily when the microphone
is activated.
A sliding switch with 3 settings - test (T), operate ( ) and
program (P). To test your voice terminal's ringer and
lights (and the alarm on display voice terminals), slide the
switch up away from you (T) - the ringer will sound and
the red and green lights will flash alternately until you
release the switch. (See your System Manager if either the
ringer or the lights do not respond during the test.) To
operate your voice terminal, slide the switch to the center
position ( ). The program mode (P) is not supported by
AT&T DEFINITY
A fixed feature button, not supported by AT&T
DEFINITY Communications System Generic 1.
A sliding switch to control the volume for the tone ringer.
Slide it up away from you (Hi) for a louder ring, down
toward you (Lo) for a quieter ring.
Available only on the 7315H and 7317H display voice
terminals, used with Timer Start/Fwd, Timer Stop/Rev and
Time/Timer Exit to set time related information on the
Liquid Crystal Display.
A fixed feature button, with a single LED visual indicator,
for accessing the built-in speaker. Speakerphone goes on
automatically when an internal automatic answer call is
automatically answered.
A green light which goes on steadily when the built-in
speaker is activated.
Communications System
Communications System Generic 1.
4
