IMPORTANT MESSAGE

The Regency Gas Inbuilt must be installed in
accordance with these instructions. Carefully
read all the instructions in this manual first.
Note: Failure to follow these instructions
could cause a malfunction of the
heater which could result in death,
serious bodily injury, and/or prop-
erty damage. Failure to follow these
instructions may also void your fire
insurance and/or warranty.

FOR YOUR SAFETY

This appliance requires air for proper combus-
tion. Always provide adequate combustion
and ventilation air. Follow instructions and
information in the current AS5601, NZS 5262
or local codes. Consult the "authority having
jurisdiction" to determine the need for a permit
prior to starting the installation.

MATERIALS REQUIRED

A 240 Volt AC power cord is hooked up to the
unit. Plug 3 wire cord into a suitable receptacle.
Do not cut the ground terminal off under any
circumstances.
When connected with 240 volts, the appliance
must be electrically grounded in accordance
with local codes.
This unit is polarity sensitive and will not
operate if polarity is incorrect.
WARNING:
Suitable for installation into a masonry
fireplace only.
Regency IG34 Gas Inbuilt Fireplace

BEFORE YOU START

Installation is to be carried out ONLY by an
authorised person.
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions, local gas fitting regulations,
municipal building codes, water supply
regulations, electrical wiring regulations,
with AS5601. (AGA gas installation code)
NZS 5262(New Zealand)
2) Installation and repair should be done
ONLY by an authorised person.
3) The appliance should be inspected before
use and at least annually by an authorised
service person. More frequent cleaning may
be required due to excessive lint from carpet-
ing, bedding material, etc. It is imperative
that control compartments, burners and
circulating air passageways of the appliance
be kept clean and free from excessive lint
from carpeting.
4) See general construction and assembly
instructions. This appliance may only be in-
stalled in a flued, non-combustible fireplace.
The appliance and flue should be enclosed
when installed or passing through a living
area, where children may come in contact
with it.
5) Always connect this space heater to a chim-
ney and flue to the outside of the building
envelope. Never flue to another room. Make
sure that the flue is properly sized and is of
adequate height to provide the proper draft.
6) Inspect the flueing system annually for
blockage and any signs of deterioration.
7) Any safety glass removed for servicing must
be replaced prior to operating the appliance.
8) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9) Installer must mechanically attach the sup-
plied label to the inside of the firebox of the
fireplace into which the gas fireplace insert
is installed.
"WARNING: This fireplace has been converted
for use with a gas fireplace insert only and
cannot be used for burning wood or solid fuels
unless all original parts have been replaced,
and the fireplace re-approved by the authority
having jurisdiction."

INSTALLATION

INSTALLATION
CHECKLIST
Before installing vent system ensure that the
damper plate is open and secure to prevent the
damper plate from falling down and crushing
the liner.
The FPI Gas Inbuilt is installed as listed.
1) Check all clearances to combustibles, (Refer
to sections "Minimum Fireplace Dimensions
and Clearances to Combustibles)
2) Make the gas connection. (Refer to section
"Gas Connection")
3) Install the 3" (76.2mm) flue liner to the sliding
connector plate. (Refer to section "Flue Liner
Installation.")
4) Slide the unit half way into the fireplace.
5) Pull the vent connector plate through the
tapered brackets and fasten to the front plate.
Refer to section "Flue Liner Installation.")
6) Slide the unit fully into the fireplace.
7) Test gas pressure (Refer to section "Gas
Pipe Pressure Testing"). Check aeration
system (Refer to section "Gas Insert Aeration
System").
8) Install standard and optional features. Refer
to the following sections:
a. Log Set
b. Faceplate & Door Trim
c. Inner Stainless Panels
9) Final check: Before leaving this unit with the
customer, the installer must ensure that the
appliance is firing correctly. This includes:
a) Clocking the appliance to ensure the
correct firing rate.
b) Adjusting the primary air and restrictor
settings, if required, to ensure that the
flame does not carbon.
NOTE:
TO BE INSTALLED ON A
NON- COMBUSTIBLE FLOOR.
