Page 1 M155 Self-Propelled Windrower Operator’s Manual 147649 Revision A 2016 Model Year Original Instruction The harvesting specialists.
Page 2 This manual contains instructions for SAFETY, OPERATION, and MAINTENANCE/SERVICE for the ® ® MacDon M155 Self-Propelled Windrower. Featuring the Dual Direction and Ultra Glide suspension on the M155. Published June, 2015 California Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm.
Page 3 Declaration of Conformity Figure 1: Declaration of Conformity (Page 1 of 2) 147649 Revision A...
Page 4 Figure 2: Declaration of Conformity (Page 2 of 2) 147649 Revision A...
Page 5: Noise Levels
Whole Body and Hand-Arm Vibration Levels The weighted root mean square acceleration, to which the whole body is subjected, ranges from 0.57 to 1.06 m/s as measured on a representative machine during typical operations and analyzed in accordance with ISO 5008. During the same operations, the weighted root means square hand-arm vibration was less than 1.45 m/s when analyzed in accordance with ISO 5349.
Page 6: Introduction
This manual contains information on the MacDon M155 Self-Propelled Windrower which, when coupled with one of MacDon’s auger, rotary, or draper headers, provides a package designed to cut and lay in windrows a variety of grain, hay, and specialty crops.
Page 7: List Of Revisions
List of Revisions At MacDon, we’re continuously making improvements: occasionally these improvements impact product documentation. The following list provides an account of major changes from the previous version of this document. Summary of Change Location Declaration of Conformity revised. Declaration of Conformity, page i Fuse panel cover decal was 183481.
Page 8: Serial Number
Serial Number If you require MacDon technical assistance, please have the serial number recorded and ready before you call. Record the model number, model year, and serial number of the windrower and engine on the lines below. The windrower serial number plate (A) is located on the left side of the main frame near the walking beam.
Page 9: Table Of Contents
TABLE OF CONTENTS Declaration of Conformity ........................i Whole Body and Hand-Arm Vibration Levels ..................iii Noise Levels ........................... iii Introduction .............................iv List of Revisions ..........................v Serial Number ..........................vi Safety ..............................1 Safety Alert Symbols........................1 Signal Words........................... 2 General Safety ..........................
Page 10 3.19.7 Calibrating the Header Sensors....................95 Calibrating the Header Height Sensor ................95 Calibrating the Header Tilt Sensor..................98 Calibrating the Header Float Sensors................100 3.19.8 Programming the Windrower....................101 Activating the Hydraulic Center-Link on an M155 .............101 viii 147649 Revision A...
Page 11 Activating the Hay Conditioner..................112 Displaying Reel Speed ....................113 Setting the Windrower’s Tire Size ................... 114 Setting the Engine Intermediate Speed Control (ISC) RPM on an M155/M205 ....115 Clearing Sub-Acres......................116 3.19.9 Activating Cab Display Lock Outs ................... 117 Activating Knife Speed Control Lock Out .................
Page 12 TABLE OF CONTENTS Operating the Windrower.......................157 4.3.1 Operational Safety ........................157 4.3.2 Break-In Period ........................158 4.3.3 Preseason Checks/Annual Service..................158 Air Conditioning Compressor Coolant Cycling..............159 4.3.4 Daily Checks and Maintenance ....................159 4.3.5 Engine Operation ........................160 Starting the Engine ......................160 Engine Warmup ......................162 Engine Intermediate Speed Control (ISC) ................163 Shutting Down the Engine ....................163 Filling the Fuel Tank .......................163...
Page 13 TABLE OF CONTENTS 4.4.11 Swath Roller Operation......................212 Attaching and Detaching Headers....................213 4.5.1 Attaching a D-Series Header....................213 Attaching Header Boots ....................213 Attaching a D-Series Header: Hydraulic Center-Link with Optional Self-Alignment .....214 Attaching a D-Series Header: Hydraulic Center-Link without Self-Alignment ......219 Attaching a D-Series Header: Mechanical Center-Link .............225 4.5.2 Detaching a D-Series Header ....................229 Detaching a D-Series Header: Hydraulic Center-Link ............230...
Page 14 TABLE OF CONTENTS Setting Disc Speed ......................303 Maintenance and Servicing ........................305 Preparation For Servicing......................305 Engine Compartment Hood ......................306 5.2.1 Opening Hood (Lower Position)....................306 5.2.2 Closing Hood (Lower Position) ....................307 5.2.3 Opening Hood (Highest Position) ...................307 5.2.4 Closing Hood (Highest Position) .....................308 Maintenance Platforms .........................309 5.3.1 Opening Platforms (Standard Position) ...................309...
Page 15 TABLE OF CONTENTS Replacing Bulbs in Red and Amber Lights ...............388 Replacing Red Tail Lights (if installed) ................388 Replacing the Bulbs in Beacon Lights (if installed) ............389 Replacing a Console Gauge Light...................394 Replacing the Cabin Dome Light..................395 Replacing the Ambient Light Fixture ................395 Turn Signal Indicators ....................396 Accessing Circuit Breakers and Fuses ................396 5.5.9...
Page 16 TABLE OF CONTENTS 7.1.21 Warning Beacons ........................450 7.1.22 Weight Box ...........................451 7.1.23 Windshield Shades........................451 Reference ............................453 Recommended Torques ........................453 8.1.1 Torque Speciﬁcations ......................453 SAE Bolt Torque Speciﬁcations..................453 Metric Bolt Speciﬁcations ....................455 Metric Bolt Speciﬁcations Bolting into Cast Aluminum ............458 Flare-Type Hydraulic Fittings ..................458 O-Ring Boss (ORB) Hydraulic Fittings (Adjustable) ............460 O-Ring Boss (ORB) Hydraulic Fittings (Non-Adjustable) ...........462 O-Ring Face Seal (ORFS) Hydraulic Fittings ..............463...
Page 17: Safety
1 Safety 1.1 Safety Alert Symbols This safety alert symbol indicates important safety messages in this manual and on safety signs on the . This symbol means: • ATTENTION! • BECOME ALERT! • YOUR SAFETY IS INVOLVED! Carefully read follow safety message accompanying this symbol.
Page 18: Signal Words
SAFETY 1.2 Signal Words Three signal words, DANGER, WARNING, and CAUTION, are used to alert you to hazardous situations. The appropriate signal word for each situation has been selected using the following guidelines: DANGER Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury.
Page 19: General Safety
SAFETY 1.3 General Safety CAUTION The following are general farm safety precautions that should be part of your operating procedure for all types of machinery. Protect yourself. • When assembling, operating, and servicing machinery, wear all the protective clothing and personal safety devices that could be necessary for the job at hand.
Page 20 SAFETY • Wear close-ﬁtting clothing and cover long hair. Never wear dangling items such as scarves or bracelets. • Keep all shields in place. Never alter or remove safety equipment. Make sure driveline guards can rotate independently of the shaft and can telescope freely. •...
Page 21: Maintenance Safety
SAFETY 1.4 Maintenance Safety To ensure your safety while maintaining the machine: • Review the operator’s manual and all safety items before operation and/or maintenance of the machine. • Place all controls in Neutral, stop the engine, set the park brake, remove the ignition key, and wait for all moving parts to stop before servicing, adjusting, and/or repairing.
Page 22: Hydraulic Safety
SAFETY 1.5 Hydraulic Safety • Always place hydraulic controls Neutral before dismounting. • Make sure that all components in the hydraulic system are kept clean and in good condition. • Replace any worn, cut, abraded, ﬂattened, or crimped hoses and steel lines. •...
Page 23: Tire Safety
SAFETY 1.6 Tire Safety • Follow proper procedures when mounting a tire on a wheel or rim. Failure to do so can produce an explosion that may result in serious injury or death. Figure 1.14: Overinﬂated Tire • Do NOT attempt to mount a tire unless you have the proper training and equipment.
Page 24: Battery Safety
SAFETY 1.7 Battery Safety WARNING • Keep all sparks and ﬂames away from the batteries, as a gas given off by electrolyte is explosive. • Ventilate when charging in enclosed space. Figure 1.16: Safety Around Batteries WARNING • Wear safety glasses when working near batteries. •...
Page 25: Welding Precaution
SAFETY 1.8 Welding Precaution High currents and voltage spikes associated with welding can cause damage to electronic components. Before welding on any part of the windrower or an attached mower conditioner, disconnect all electronic module harness connections as well as the battery cables. Refer to your Dealer for proper procedures. 147649 Revision A...
Page 26: Engine Safety
SAFETY 1.9 Engine Safety WARNING Do NOT use aerosol types of starting aids such as ether. Such use could result in an explosion and personal injury. CAUTION • In the initial start-up of a new, serviced, or repaired engine, always be ready to shut the engine off in order to stop an over-speed.
Page 27: Engine Electronics
SAFETY 1.9.2 Engine Electronics WARNING Tampering with the electronic system installation or the original equipment manufacturer (OEM) wiring installation can be dangerous and could result in personal injury or death and/or engine damage. WARNING Electrical Shock Hazard. The electronic unit injectors use DC voltage. The engine control module (ECM) sends this voltage to the electronic unit injectors.
Page 28: Safety Signs
SAFETY 1.10 Safety Signs • Keep safety signs clean and legible at all times. • Replace safety signs that missing become illegible. • If original parts on which a safety sign was installed are replaced, be sure the repair part also bears the current safety sign.
Page 29: Safety Sign Locations
SAFETY 1.11 Safety Sign Locations Figure 1.20: Safety Sign Locations (Left Cab-forward Side) A - Hazard Sign (MD #135378) B - Cab Door and Rim (MD #166454) C - Oil Reservoir under Hood (MD #166466) D - Exhaust Cover (MD #166450) E - Close to Radiator Cap (MD #166461) F - Fan Shroud (Top) (MD #166450) G - Fan Shroud (Middle) (MD #166451)
Page 30 SAFETY Figure 1.21: Safety Signs (Left Cab-forward Side) 147649 Revision A...
Page 31 SAFETY Figure 1.22: Safety Sign Locations (Right Cab-forward Side) A - Hazard Sign on Seat (MD #115148) B - Lift Linkage (MD #166439) C - Frame (MD #166455) D - Frame (MD #166456) E - Cab Frame (MD #184372) F - Platform (MD #166425) G - Shroud (MD #166451) H - Shroud (MD #166452) J - Hydraulic Reservoir (MD #174436)
Page 32 SAFETY Figure 1.23: Safety Signs (Right Cab-forward Side) 147649 Revision A...
Page 33: Understanding Safety Signs
SAFETY 1.12 Understanding Safety Signs MD #166233 Run-over hazard DANGER • Do not start engine by shorting across starter or starter relay terminals. Machine will start with drive engaged and move if starting circuitry is bypassed. • Start engine only from operator’s seat. Do not try to start engine with someone under or near machine.
Page 34 SAFETY MD #166439 Roll-over hazard WARNING • Stop the engine and remove the key from ignition before servicing, adjusting, lubricating, cleaning, or unplugging the machine. Figure 1.27: MD #166439 MD #166438 Crushing hazard DANGER • Rest header on ground or engage safety props before going under unit.
Page 35 SAFETY MD #166439 Crushing hazard DANGER • Rest header on ground or engage safety props before going under unit. Figure 1.29: MD #166439 MD #166441 Loss of control hazard CAUTION • To prevent machine damage and/or loss of control, it is essential that the machine be equipped such that weights are within the speciﬁed limits.
Page 36 SAFETY MD #166450 Hot surface hazard WARNING • To avoid injury, keep a safe distance from hot surface. Figure 1.31: MD #166450 MD #166451 Rotating fan hazard WARNING • To avoid injury, stop the engine and remove the key before opening engine hood. Figure 1.32: MD #166451 147649 Revision A...
Page 37 SAFETY MD #166454 General hazard pertaining machine operation and servicing. CAUTION • Read the operator’s manual and follow all safety instructions. If you do not have a manual, obtain one from your Dealer. • Do not allow untrained persons to operate the machine. •...
Page 38 SAFETY MD #166456 Battery acid hazard WARNING • Corrosive and poisonous battery acid. Acid can severely burn your body and clothing. Figure 1.35: MD #166456 147649 Revision A...
Page 39 SAFETY MD #166457 General hazard pertaining machine operation and servicing CAUTION To avoid injury or death from improper or unsafe machine operation: • Read the operator’s manual and follow all safety instructions. If you do not have a manual, obtain one from your Dealer.
Page 40 • Use slow moving vehicle emblem and ﬂashing warning lights unless prohibited by law. Figure 1.38: MD #166463 • If width of attached header impedes other vehicle trafﬁc, remove header and install MacDon approved weight box. Refer to operator’s manual for safe procedure to tow header. 147649...
Page 41 • Shift high-low speed control to low range. With header removed, steering control is reduced if weight is not added to drive wheels. If you must drive the windrower without header or MacDon weight system: • Operate in low speed range. • Avoid slopes.
Page 42 SAFETY MD #166833 Run-over hazard WARNING • Remove key from ignition. • Read tractor and mower manufacturer’s manuals for inspection and maintenance instructions. • Read the windrower and header manuals for inspection and maintenance instructions. Figure 1.41: MD #166425 MD #167502 Pinch point hazard WARNING •...
Page 43 SAFETY MD #174436 High pressure oil hazard WARNING • Do not go near leaks. • High pressure oil easily punctures skin causing serious injury, gangrene, or death. • If injured, seek emergency medical help. Immediate surgery is required to remove oil. •...
Page 45: Product Overview
It is used to change header angle CGVW Combined vehicle gross weight D-Series header MacDon D50, D60, and D65 rigid draper headers Double Windrow Attachment Engine control module Engine-forward Windrower operation with the Operator and engine facing in the direction of travel...
Page 46 This style of ﬁtting is also commonly called ORS, which stands for O-ring seal Power take-off Revolutions per minute R-Series header MacDon rotary disc header RoHS (Reduction of A directive by the European Union to restrict the use of certain hazardous Hazardous Substances)
Page 47: Speciﬁcations
3.01 cu. in. (50 cc) Displacement High Range 1.93 cu. in. (32 cc) SYSTEM CAPACITIES Fuel Tank 97 US Gallons (367 L) Hydraulic Reservoir 17.2 US Gallons (65 L) HEADER DRIVE (Refer to Table 2.1 M155 Hydraulic Pumps , page 33). 147649 Revision A...
Page 48 PRODUCT OVERVIEW HEADER LIFT/TILT Type Hydraulic Double Acting Cylinders. Tilt - Optional Hydraulic Positioning, Optional Hydraulic Center-Link Function Lift / Tilt / Float HEADER FLOAT Primary Manual, External, Drawbolt With Springs (1 per side). One Inner Booster Adjustment Spring On Left Side. Fine Adjustment Hydraulic, In-Cab Switch Hydraulic, 3 Programmable Settings For All Headers...
Page 49 Headers Rotary Disc R80 and R85 13 FT. Only NOTE: Speciﬁcations and design are subject to change without notice or obligation to revise previously sold units. Table 2.1 M155 Hydraulic Pumps Pump Type Function Speciﬁcations Controller Type Variable Displacement: Pump A 0–2.75 cu.
Page 50: Windrower Dimensions
PRODUCT OVERVIEW 2.3 Windrower Dimensions Figure 2.1: Windrower Dimensions – Cab-Forward A - Drive Tire Tread B - Drive Tire Hubs C - Drive Tires F - 45-3/4 in. (1160 mm) G - 133 in. (3378 mm) H - 158-5/16 in. (4022 mm) J - 207-7/8 in.
Page 51 PRODUCT OVERVIEW Tread (A) Hubs (B) Tires (C) Tire Size Wheel Position in. (mm) in. (mm) in. (mm) Inner/outer 126-1/8 (3203) 140-9/16 (3571) 149-5/16 (3793) (shipping) 23.1-26 turf tires Outer/outer 133-3/16 (3383) 147-11/16 (3751) 156-7/16 (3973) Inner/inner 119 (3023) 133-1/2 (3391) 142-1/4 (3613) Figure 2.2: Windrower Dimensions –...
Page 52: Component Location
PRODUCT OVERVIEW 2.4 Component Location Figure 2.3: Front Cab-Forward View A - Header Lift Leg B - Header Float Springs C - Operator’s Station D - Windshield Wiper E - Turn Signal / Hazard Lights F - Tail Light Engine-Forward G - Field/Road Lights H - Handholds J - Tail Light Engine-Forward...
Page 53 PRODUCT OVERVIEW Figure 2.4: Rear Cab-Forward View A - Caster Wheel B - Walking Beam C - Tail Lights - Cab-Forward (Option) D - Engine Compartment Hood E - Windshield Wiper F - Field Lights G - Horn H - Turn Signal/Hazard Lights J - Mirror K - Door L - Drive Wheel...
Page 55: Operator's Station
3 Operator’s Station The operator’s station is designed for operating the windrower in a cab-forward mode (working mode) or in an engine-forward mode (transport mode). The operator’s station, which includes the seat, console, and steering column, pivots 180 degrees so that the Operator maintains access to the windrower controls and gauges regardless of the direction of travel.
Page 56 OPERATOR’S STATION 2. Adjusting only fore-aft: a. Loosen nuts (A) under console. b. Move console as required. c. Tighten nuts (A). Figure 3.3: Seat Fore-Aft 147649 Revision A...
Page 57: Operator Presence System
OPERATOR’S STATION 3.2 Operator Presence System The Operator Presence System is a safety feature designed to deactivate or alarm selected systems when the Operator is not seated at the operator’s station. These systems include: • Header Drive • Engine and Transmission 3.2.1 Header Drive •...
Page 58: Operator's Seat Adjustments
OPERATOR’S STATION 3.3 Operator’s Seat Adjustments The operator’s seat has several adjustments. Refer to the following for the location and description of each adjustment. 3.3.1 Fore-Aft Adjusts fore-aft position. 1. Pull lever (A) up to release. 2. Move seat forward or rearward. 3.
Page 59: Vertical Dampener
OPERATOR’S STATION 3.3.3 Vertical Dampener Adjusts suspension dampening. INCREASE: Turn knob (A) counterclockwise. DECREASE: Turn knob (A) clockwise. Figure 3.6: Vertical Dampener 3.3.4 Armrest Raise armrest (A) for easier access to seat. Lower armrest (A) after seat belt is buckled. Figure 3.7: Armrest 147649 Revision A...
Page 60: Fore-Aft Isolator Lock
OPERATOR’S STATION 3.3.5 Fore-Aft Isolator Lock Locks seat fore-aft isolator. LOCK: Push lever (A) down. UNLOCK: Pull lever (A) up. Figure 3.8: Fore-Aft Isolator Lock 3.3.6 Seat Tilt To adjust seat tilt: 1. Pull lever (A) up to release. 2. Position seat back as desired. 3.
Page 61: Armrest Angle
OPERATOR’S STATION 3.3.7 Armrest Angle Adjusts angle of armrest. INCREASE: Rotate knob (A) clockwise. DECREASE: Rotate knob (A) counterclockwise. Figure 3.10: Armrest Angle 3.3.8 Lumbar Support Adjusts stiffness of seat back. INCREASE: Rotate knob (A) upward. DECREASE: Rotate knob (A) downward. Figure 3.11: Lumbar Support 147649 Revision A...
Page 62: Training Seat
OPERATOR’S STATION 3.4 Training Seat A wall-mounted fold-up training seat complete with seat belt is provided. WARNING • The training seat is provided for an experienced Operator of the machine when a new Operator is being trained. • The training seat is NOT intended as a PASSENGER SEAT or FOR USE BY CHILDREN. USE THE SEAT BELT whenever operating the machine or riding as a Trainer.
Page 63: Seat Belts
OPERATOR’S STATION 3.5 Seat Belts The windrower is equipped with a seat belt on the operator’s and trainer’s seats. WARNING The seat belt can help ensure your safety if it is used and maintained. • Before starting the engine, securely fasten your seat belt. Ensure that anyone occupying the trainee’s seat is secured by a seat belt as well.
Page 64: Steering Column Adjustment
OPERATOR’S STATION 3.6 Steering Column Adjustment The steering column can be adjusted to suit each particular Operator and for easier entry to and exit from the seat. To adjust the steering column: 1. Hold onto steering wheel, lift handle (A), and move steering wheel up or down to desired position.
Page 65: Lighting
OPERATOR’S STATION 3.7 Lighting The ﬁeld and road light switches are located on a panel in the cab headliner. The position of the operator’s station (cab-forward mode or engine-forward mode) automatically determines the lighting. The hazard lights are activated automatically when certain conditions are met.
Page 66: Engine-Forward Lighting: Road
OPERATOR’S STATION The two ﬁeld lights (A) at the rear of the cab are adjustable. Refer to Adjusting Rear Flood Lights, page 386. The two swath lights (B) in the hood are adjustable but, because they are used as road lights in engine-forward mode and adjusted accordingly, they should NOT be adjusted for ﬁeld operation.
Page 67: Cab-Forward Lighting: Road (Optional)
OPERATOR’S STATION • Amber turn signals and hazard lights (A) on mirror supports front view • Headlights (B) in hood with low/high The two headlights in the hood are adjustable. Refer to Aligning Headlights, page 376. Figure 3.22: Engine-Forward: Front View 3.7.3 Cab-Forward Lighting: Road (Optional) If equipped, the following lights are functional with switch (A) in the ROAD position:...
Page 68: Beacon Lighting (Optional)
IMPORTANT: Optional red tail lighting and marking kit must be installed so that road travel in the cab-forward mode complies with road travel regulations. See your MacDon Dealer. Figure 3.25: Cab Forward: Rear View 3.7.4 Beacon Lighting (Optional) MD #B5582 The beacon lights (A) are functional when the ignition and the beacon switch (B) are ON.
Page 69: Hid Auxiliary Lighting (Optional)
OPERATOR’S STATION 3.7.5 HID Auxiliary Lighting (Optional) Two optional High Intensity Discharge (HID) lights (MD #B5596) provide additional lighting during ﬁeld operation. If installed, HID auxiliary lighting is located on the mirror supports (A) and operates in cab-forward mode only. Figure 3.28: HID Auxiliary Lights (Optional) Optional HID auxiliary lighting is activated with the light switch (B) in the FIELD position.
Page 70: Windshield Wipers
OPERATOR’S STATION 3.8 Windshield Wipers The windshield wiper controls are located in the cab headliner. The illustration shows the controls in cab-forward mode. Figure 3.30: Wiper Controls A - Rear Wiper B - Front Wiper 147649 Revision A...
Page 71: Rear View Mirrors
OPERATOR’S STATION 3.9 Rear View Mirrors Two outside mounted, adjustable mirrors (A) provide a rear view when the windrower is in cab-forward mode. A single interior mounted mirror (B) provides a rear view in the engine-forward mode. The mirror/light assembly (A) is designed to fold back if accidentally struck.
Page 72: Cab Temperature
OPERATOR’S STATION 3.10 Cab Temperature The cab environment is controlled by a climate control system that provides clean air-conditioned or heated air for the Operator. The heater/evaporator/blower assembly is located under the cab ﬂoorboard and is accessible from beneath the windrower. 3.10.1 Heater Shut-Off A shut-off valve (A) at the engine allows the cab heater to be isolated from the engine coolant.
Page 73: Climate Controls
OPERATOR’S STATION 3.10.3 Climate Controls A – BLOWER Switch controls the blower speed. • OFF / LOW / MEDIUM / HIGH B – Air Conditioning (A/C) Switch controls A/C system. • OFF: A/C does not operate. • ON: A/C operates with blower switch ON. C –...
Page 74: Interior Lights
OPERATOR’S STATION 3.11 Interior Lights Two interior lights are installed in the cab headliner. A low intensity LED light (A) is located directly overhead to provide ambient lighting if desired. It functions only when the key is in the run position. An ON/OFF switch is located on the light.
Page 75: Emergency Exit
OPERATOR’S STATION 3.12 Emergency Exit The emergency exit is located behind the operator console. An emergency exit sign (A) is located above the window. Figure 3.36: Emergency Exit Sign To open the emergency exit window, do the following: 1. Release the window latch (A). 2.
Page 76: Operator Amenities
OPERATOR’S STATION 3.13 Operator Amenities The operator’s station includes the following amenities: Operator’s Console A - Auxiliary power outlet B - Utility tray (under armrest) C - Cigarette lighter D - Ashtray / cup holder E - Utility tray Figure 3.38: Console Window Shades (Optional) Retractable window shades (A) can be installed for the front and rear windows.
Page 77 OPERATOR’S STATION Manual Storage A manual storage case (A) is located under the training seat. Figure 3.41: Operator’s Manual Storage Coat Hook A coat hook (A) is located above the training seat, left of the Operator. Figure 3.42: Coat Hook 147649 Revision A...
Page 78: Radio
Dealer. Two pre-wired speakers (A) have been factory-installed in the headliner. For radio installation procedures, refer to MD #169885 M155 and M205 Self-Propelled Windrower Unloading and Assembly Instructions (North America) or MD #169886 M-Series Self-Propelled...
Page 79 OPERATOR’S STATION The knockout (A) is located on the exterior right cab-forward rear corner post of the cab, under the roof, between the horn and the light. Figure 3.45: Knockout Location in Cab To make your own mount, refer to dimensions template. Use 11 GA.
Page 80: Horn
OPERATOR’S STATION 3.15 Horn The horn is activated by pushing button (A) located on the panel in the headliner. Sound the horn three times prior to starting the engine. Figure 3.47: Horn Button Location The horn (A) is located outside the cab on the rear right cab-forward corner of the cab, under the roof.
Page 81: Engine Controls And Gauges
OPERATOR’S STATION 3.16 Engine Controls and Gauges The following engine controls and gauges are conveniently located on the operator’s console. A – Ignition Switch • ACC: Fully counterclockwise • OFF: All electrical systems OFF • RUN: Clockwise • START: Fully clockwise to crank engine: Release and switch returns to RUN •...
Page 82: Windrower Controls
OPERATOR’S STATION 3.17 Windrower Controls Console Controls: A – TURN SIGNALS activate turn signals on windrower and header • Push-ON / Push-OFF B – GROUND SPEED LEVER (GSL) controls speed and direction of movement • F: Forward • N: NEUTRAL •...
Page 83 OPERATOR’S STATION The autosteer engagement switch harness end (A) is beneath the cab between the fuel tank and evaporator box. Figure 3.52: Autosteer Harness 147649 Revision A...
Page 84: Header Controls
OPERATOR’S STATION 3.18 Header Controls All header controls are conveniently located on the operator’s console and on the ground speed lever (GSL) handle. NOTE: Some controls are optional equipment and may not be present in your unit. Some controls may be installed but nonfunctional for certain headers.
Page 85: Ground Speed Lever (Gsl) Header Switches
OPERATOR’S STATION 3.18.3 Ground Speed Lever (GSL) Header Switches The switches on the GSL (A) control the most common header functions. NOTE: A decal (B) identifying switch functions is located on the cab post above the operator’s console. Figure 3.55: GSL Figure 3.56: GSL Function Groups A - Reel Speed B - Reel Position...
Page 86: Display Selector Switch
OPERATOR’S STATION Display Selector Switch Pressing the display selector switch (A) selects and displays the settings on the cab display module (CDM) top line read-out for each of the header controls. Press switch (A) to scroll through settings. Figure 3.57: GSL Reel Position Switches The functions performed by the reel position switches depend on which header is attached and the cab display...
Page 87: Header Position Switches
OPERATOR’S STATION Header Position Switches Use the header position switches on the ground speed lever (GSL) to adjust the position of the header, relative to the ground. • To lower the header down, press switch (A) • To raise the header up, press switch (C) •...
Page 88: Console Header Switches
OPERATOR’S STATION 3.18.4 Console Header Switches The operator’s console contains switches for the following header functions: Deck Shift/Float Preset Switch Draper Header with Deck Shift Option • Controls deck shifting and ﬂoat settings for double windrowing options with a draper header Figure 3.61: Header Switches A - Deck Shift/Float Preset Switch B - Left Side Delivery...
Page 89: Double Windrow Attachment (Dwa) / Swath Roller Switch (If Installed)
OPERATOR’S STATION Double Windrow Attachment (DWA) / Swath Roller Switch (if installed) With Double Windrow attachment • If switch (A) is installed in the console, the DWA deck is raised with switch in position (C) or lowered in position (B). The cab display module (CDM) must be programmed for this conﬁguration, refer to Activating the Double Windrower Attachment (DWA), page...
Page 90: Cab Display Module (Cdm)
OPERATOR’S STATION 3.19 Cab Display Module (CDM) 3.19.1 Engine and Windrower Functions Figure 3.64: Cab Display Module (CDM) Engine and Windrower Functions A – Engine rpm B – Ground Speed: mph or km/h C – DISPLAY: Engine/windrower functions D – HAZARD WARNING LIGHTS switch: Activates hazard warning lights, cancels turn signal E –...
Page 91: Header Functions
OPERATOR’S STATION 3.19.2 Header Functions Figure 3.65: Cab Display Module (CDM) • (A) DISPLAY: Header functions • (B) SELECT SWITCH: Allows Operator to select display item on lower line. Push to SELECT. • (C) FLOAT SWITCH – Header Right Side: Changes header ﬂoat. The system remembers setting with deck shift option if activated with ﬂoat setting switch.
Page 92: Operating Screens
OPERATOR’S STATION 3.19.3 Operating Screens The cab display module (CDM) and the windrower control module (WCM) provide information on several functions for the engine, header, and windrower. The information displayed in various operating modes is described in the following sections. Figure 3.66: CDM Operating Screen A - Display Selector for Upper Line B - Display...
Page 93: Engine-Forward, Engine Running
OPERATOR’S STATION Engine-Forward, Engine Running Display Description ROAD GEAR (Upper Line) Ground speed range switch in high range. #####.# ENGINE HRS (Upper or Lower Line) Total engine operating time. #####.# HEADER HRS (Upper or Lower Line) Total header operating time. ###### TOTAL ACRES (Upper or Lower Line) Total area cut by machine.
Page 94 OPERATOR’S STATION Display (Lower or Upper Line) Description ##.# ACRES/HOUR Actual cutting rate in acres (hectares)/hour. ##.# HECTARES/HOUR (If Metric) ###.# SUB ACRES Area cut since last reset. To reset, display SUB ACRES ###.# SUB HECTARES (If Metric) on lower line, and hold down program switch until display resets (5–7 seconds).
Page 95: Cab-Forward, Engine Running, Header Engaged, Auger Header Index Switch On
OPERATOR’S STATION Cab-Forward, Engine Running, Header Engaged, Auger Header Index Switch ON Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch. Display (Lower or Upper Line) Description #####.# ENGINE HRS Total engine operating time. #####.# HEADER HRS Total Header operating time.
Page 96: Engine Running, Header Engaged, Auger Header
OPERATOR’S STATION Display (Lower or Upper Line) Description ##.# VOLTS Engine electrical system operating voltage. SCROLL SUB-MENU (Lower Line Only) Displays sub-menu after 2–3 Seconds. Press SELECT to #### KNIFE SPEED cancel. Scroll through sub-menu display with CDM switch. ##.# HEADER HEIGHT LOAD|■■■■|■■■■| #### Engine Running, Header Engaged, Auger Header Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch.
Page 97: Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch Off
OPERATOR’S STATION Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch OFF Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch. Display (Lower or Upper Line) Description #####.# ENGINE HRS Total engine operating time. #####.# HEADER HRS Total header operating time.
Page 98: Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch On
OPERATOR’S STATION Cab-Forward, Engine Running, Header Engaged, Draper Header, Index Switch ON Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch. Display (Lower or Upper Line) Description #####.# ENGINE HRS Total engine operating time. #####.# HEADER HRS Total header operating time.
Page 99: Cab-Forward, Engine Running, Header Engaged, Rotary Header Installed
OPERATOR’S STATION Cab-Forward, Engine Running, Header Engaged, Rotary Header Installed Scroll through display with cab display module (CDM) switch or ground speed lever (GSL) switch. Display (Lower or Upper Line) Description #####.# ENGINE HRS Total engine operating time. #####.# HEADER HRS Total header operating time.
Page 100 OPERATOR’S STATION Display (Upper Line) Description IN PARK GSL in N-DETENT position. Indicates left turn when left arrow is pressed on CDM. Engine-forward < LEFT TURN ■ mode only Indicates right turn when right arrow is pressed on CDM. Engine ■...
Page 101: Cab Display Module (Cdm) Warning/Alarms
OPERATOR’S STATION 3.19.4 Cab Display Module (CDM) Warning/Alarms The CDM displays warnings and sounds alarms to notify of abnormal windrower status at startup when the ignition is turned ON, and at engine operating speeds above 500 rpm. Engine Warning Lights Figure 3.67: CDM Engine Warning Lights A - Engine Pre-Heat B - Water in Fuel...
Page 102: Display Warnings And Alarms
OPERATOR’S STATION Display Warnings and Alarms Informs Operator of abnormal windrower conditions. Figure 3.68: CDM Display Warnings and Alarms Display (A) Flashing Alarm Tone Description Engine running, brake solenoid BRAKE OFF Short beep with each ﬂash not activated Ground speed lever (GSL) out of BRAKE ON Short beep with each ﬂash N-DETENT, but interlock switch...
Page 103 OPERATOR’S STATION Display (A) Flashing Alarm Tone Description Ongoing intermittent moderate Engine temperature over 230°F ENGINE TEMPERATURE tone until temperature is below (110°C) 215°F (102°C) HEADER DISENGAGED None Normal Header switch is in the ON DISENGAGE HEADER None position when ignition switch is turned ON Low header charge oil pressure causes header to shut down:...
Page 104 OPERATOR’S STATION Display (A) Flashing Alarm Tone Description Operator not detected in seat with header engaged or out of NO OPERATOR Continuous tone N-DETENT: engine shutdown after 5 seconds Engine shutdown when Operator NO OPERATOR ENGINE Continuous tone not detected in seat with machine SHUT DOWN moving under 5 mph (8 km/h) GSL or interlock switches not...
Page 105: Cab Display Module (Cdm) Programming
OPERATOR’S STATION 3.19.5 Cab Display Module (CDM) Programming Figure 3.69: CDM A - Side Display B - Main Display C - Select Switch D - Menu Item Scroll Forward E - Menu Item Scroll Backward F - Program Switch Side Display: Displays software revision status. •...
Page 106: Cab Display Options
OPERATOR’S STATION NOTE: Contact your MacDon Dealer for information regarding software updates to the electronic modules. Your Dealer will have the necessary interface tools and access to the latest software upgrades. NOTE: The following menus are available when ignition key is set to RUN: •...
Page 107: Changing The Windrower Display Units
3. Press SELECT (B) until CAB DISPLAY SETUP? is displayed on the upper line. • NO/YES is displayed on the lower line. Figure 3.71: M155 Cab Display Setup 4. Press right (C) arrow select YES. Press SELECT (D). • DISPLAY LANGUAGE? is displayed on the upper line.
Page 108: Adjusting The Cab Display Buzzer Volume
4. Press right (A) arrow to select YES. Press SELECT (B). • DISPLAY LANGUAGE? is displayed on the upper line. Figure 3.74: M155 Cab Display Setup 5. Press SELECT (D) until DISPLAY UNITS? is displayed on the upper line. • Default setting is displayed on the lower line.
Page 109: Adjusting The Cab Display Backlighting
4. Press right (A) arrow to select YES. Press SELECT (B). • DISPLAY LANGUAGE? is displayed on the upper line. Figure 3.77: M155 Cab Display Setup 5. Press SELECT (D) until BUZZER VOLUME is displayed on the upper line. • Previous setting is displayed on the lower line.
Page 110: Adjusting The Cab Display Contrast
4. Press right (A) arrow to select YES. Press SELECT (B). • DISPLAY LANGUAGE? is displayed on the upper line. Figure 3.80: M155 Cab Display Setup 5. Press SELECT (D) until BACKLIGHTING is displayed on the upper line. • Default setting is displayed on the lower line.
Page 111: Calibrating The Header Sensors
4. Press right (A) arrow to select YES. Press SELECT (B). • DISPLAY LANGUAGE? is displayed on the upper line. Figure 3.83: M155 Cab Display Setup 5. Press SELECT (D) until DISPLAY CONTRAST is displayed on the upper line. • Default setting is displayed on the lower line.
Page 112 3. Press SELECT (C) until CALIBRATE SENSORS? is displayed on the upper line. • NO/YES is displayed on the lower line. Figure 3.85: M155 CDM Programming Buttons 4. Press right (B) arrow to select Yes. Press SELECT (C). • TO CALIBRATE SELECT is displayed in upper line.
Page 113 OPERATOR’S STATION CAUTION Check to be sure all bystanders have cleared the area. 6. Press and hold the HEADER UP (C) button on the ground speed lever (GSL). • CALIBRATING HEIGHT is displayed on the upper line. • RAISE HEADER HOLD is displayed on the lower line.
Page 114: Calibrating The Header Tilt Sensor
3. Press SELECT (C) until CALIBRATE SENSORS? is displayed on the upper line. • NO/YES is displayed on the lower line. Figure 3.89: M155 CDM Programming Buttons 4. Press right (B) arrow to select Yes. Press SELECT (C). • TO CALIBRATE SELECT is displayed in upper line 5.
Page 115 OPERATOR’S STATION CAUTION Check to be sure all bystanders have cleared the area. 6. Press and hold the HEADER TILT EXTEND (B) button on the ground speed lever (GSL). • CALIBRATING TILT is displayed on the upper line. • EXTEND TILT HOLD is displayed on the lower line. NOTE: The word HOLD will ﬂash during calibration.
Page 116: Calibrating The Header Float Sensors
3. Press SELECT (C) until CALIBRATE SENSORS? is displayed on the upper line. • NO/YES is displayed on the lower line. Figure 3.93: M155 CDM Programming Buttons 4. Press right (B) arrow to select Yes. Press SELECT (C). • TO CALIBRATE SELECT is displayed in upper line.
Page 117: Programming The Windrower
The windrower can be programmed to meet changing crop conditions, activate newly added options, indicate a change of header type, or increase the comfort level of the Operator. Activating the Hydraulic Center-Link on an M155 NOTE: • This procedure requires installation of the optional Hydraulic Center-Link (MD #B4650).
Page 118: Activating The Rotary Header Drive Hydraulics On An M155
SELECT (C) to proceed to next WINDROWER SETUP action. Figure 3.98: M155 Hydraulic Center-Link Activating the Rotary Header Drive Hydraulics on an M155 NOTE: This procedure requires installation of the optional Rotary Header Drive Hydraulics (MD #B5510). For more information, refer to 7.1.17 Rotary Header Drive Hydraulics (13-foot), page...
Page 119: Setting The Knife Overload Speed
• WINDROWER SETUP? is displayed on the upper line. • NO/YES is displayed on the lower line. 3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed. Figure 3.101: M155 CDM Programming Buttons 147649 Revision A...
Page 120: Setting The Rotary Disc Overload Speed
6. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.102: M155 Knife Overload Speed Setting the Rotary Disc Overload Speed NOTE: • The header MUST be attached to the windrower to perform this procedure. The cab display module (CDM) automatically adjusts its programming for each header.
Page 121: Setting The Header Knife Speed
6. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.104: M155 Disc Overload Speed Setting the Header Knife Speed NOTE: • The header MUST be attached to the windrower to perform this procedure. The cab display module (CDM) automatically adjusts its programming for each header.
Page 122: Setting The Hydraulic Overload Pressure
• WINDROWER SETUP? is displayed on the upper line. • NO/YES is displayed on the lower line. 3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed. Figure 3.107: M155 CDM Programming Buttons 147649 Revision A...
Page 123: Setting The Header Index Mode
• NO/YES is displayed on the lower line. 3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.109: M155 CDM Programming Buttons 147649 Revision A...
Page 124: Setting The Return To Cut Mode
6. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.110: M155 Header Index Mode Setting the Return to Cut Mode For more information on the Return to Cut feature, refer to 4.4.7 Return to Cut , page...
Page 125: Setting The Header Cut Width
6. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.112: M155 Return to Cut Mode Setting the Header Cut Width NOTE: • The header MUST be attached to the windrower to perform this procedure. The cab display module (CDM) automatically adjusts its programming for each header.
Page 126: Activating The Double Windrower Attachment (Dwa)
6. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.114: M155 Header Cut Width Activating the Double Windrower Attachment (DWA) NOTE: • Follow this procedure if installing the DWA; however, refer to the DWA manual if you require additional installation instructions.
Page 127 GSL Reel Fore-Aft button. 8. Press right (C) arrow to select YES. Press SELECT (D). Figure 3.118: M155 DWA Auto Up/Down 9. Press PROGRAM to exit Programming Mode or press SELECT to proceed to next WINDROWER SETUP action.
Page 128: Setting The Auto Raise Height
3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.119: M155 CDM Programming Buttons 4. Press SELECT (D) until AUTO RAISE HEIGHT? is displayed on the upper line.
Page 129: Displaying Reel Speed
5. Press right (B) arrow to select YES. Press SELECT (C). 6. Press PROGRAM (A) to exit Programming Mode or press SELECT (C) to proceed to next WINDROWER SETUP action. Figure 3.122: M155 Hay Conditioner Shown – M205 Similar Displaying Reel Speed NOTE: •...
Page 130: Setting The Windrower's Tire Size
3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.123: M155 CDM Programming Buttons 4. Press SELECT (D) until HEADER REEL SPEED? is displayed on the upper line.
Page 131: Setting The Engine Intermediate Speed Control (Isc) Rpm On An M155/M205
6. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Setting the Engine Intermediate Speed Control (ISC) RPM on an M155/M205 NOTE: The ISC sets the engine speed when the header is engaged. For more information, refer to Engine Intermediate 163.
Page 132: Clearing Sub-Acres
• ISC RPM #### is displayed on the lower line. NOTE: The previously selected ISC rpm will be ﬂashing. Figure 3.128: M155 Engine ISC RPM 6. Press right (C) arrow to cycle between rpm options. Press HAZARD (B) to set.
Page 133: Activating Cab Display Lock Outs
3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.131: M155 CDM Programming Buttons 4. Press SELECT (B) until SET CONTROL LOCKS? is displayed on the upper line.
Page 134: Activating Rotary Disc Speed Control Lock Out
8. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.133: M155 Knife Speed Control Lock Activating Rotary Disc Speed Control Lock Out NOTE: • This procedure is for rotary disc headers only.
Page 135: Activating The Header Float Control Lock Out
8. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.136: M155 Disc Speed Control Lock Activating the Header Float Control Lock Out NOTE: The header MUST be attached to the windrower to perform this procedure. The cab display module (CDM) automatically adjusts its programming for each header.
Page 136 (C) to lock HEADER FLOAT control switch. 8. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.139: M155 Header Float Control Lock 147649 Revision A...
Page 137: Activating The Draper Speed Control Lock Out
3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.140: M155 CDM Programming Buttons 4. Press SELECT (B) until SET CONTROL LOCKS? is displayed on the upper line.
Page 138: Activating The Auger Speed Control Lock Out
8. Press PROGRAM (A) to exit Programming Mode or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.142: M155 Draper Control Lock Activating the Auger Speed Control Lock Out NOTE: • This procedure is for A40-D Headers only.
Page 139: Activating The Reel Speed Control Lock Out
8. Press PROGRAM (A) to exit Programming Mode, or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.145: M155 Auger Control Lock Activating the Reel Speed Control Lock Out NOTE: The header MUST be attached to the windrower to perform this procedure. The cab display module (CDM) automatically adjusts its programming for each header.
Page 140 Press right (C) arrow to lock REEL SPEED control switch. 8. Press PROGRAM (A) to exit Programming Mode, or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.148: M155 Reel Speed Control Lock 147649 Revision A...
Page 141: Activating The Reel Fore-Aft Control Lock Out
3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.149: M155 CDM Programming Buttons 4. Press SELECT (B) until SET CONTROL LOCKS? is displayed on the upper line.
Page 142: Activating The Header Tilt Control Lock Out
8. Press PROGRAM (A) to exit Programming Mode, or press SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.151: M155 Reel Fore-Aft Control Lock Activating the Header Tilt Control Lock Out NOTE: • The header MUST be attached to the windrower to perform this procedure. The cab display module (CDM) automatically adjusts its programming for each header.
Page 143: Displaying Activated Cab Display Lock Outs
SELECT (D) to proceed to next WINDROWER SETUP action. Figure 3.154: M155 Header Tilt Control Lock 3.19.10 Displaying Activated Cab Display Lock Outs Displaying the activated control locks allows you to quickly determine which controls are locked on the cab display module (CDM).
Page 144 3. Press right (B) arrow to select YES. Press SELECT (C). • SET KNIFE SPEED? is displayed on the upper line. Figure 3.155: M155 CDM Programming Buttons 4. Press SELECT (B) until VIEW CONTROL LOCKS? is displayed on the upper line.
Page 145: Troubleshooting Windrower Problems
• DRAPER SPEED • AUGER SPEED • KNIFE SPEED • DISK SPEED • REEL SPEED Figure 3.157: M155 Control Locks NOTE: Not all control locks apply to every header. 7. Press SELECT. • EXIT VIEW LOCKOUTS? is displayed on the upper line.
Page 146 3. Press SELECT (C) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line. Figure 3.158: M155 CDM Programming Buttons 4. Press right (A) arrow to select Yes. Press SELECT (B). 5. VIEW ERROR CODES? is displayed on the upper line.
Page 147: Switching The Installed Header Sensors On Or Off
• NO/YES is displayed on the lower line. 4. Press right (B) arrow to select Yes. Press SELECT (C). • VIEW ERROR CODES? is displayed on the upper line. Figure 3.162: M155 CDM Programming Buttons 147649 Revision A...
Page 148: Displaying Header Sensors Input Signals
• KNIFE SPEED SENSOR is displayed on the lower line. • ENABLE/DISABLE is displayed on the lower line. Figure 3.163: M155 Diagnostic Functions 7. Press left (B) arrow to enable a sensor. Press right (C) arrow to disable sensor. Press SELECT (D) to conﬁrm selection and move on to next sensor.
Page 149 • WINDROWER SETUP? is displayed on the upper line. • NO/YES is displayed on the lower line. Figure 3.165: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed on the upper line. • NO/YES is displayed on the lower line.
Page 150: Forcing A Header Id
(CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.168: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 151: Troubleshooting Header Problems
• SELECT HEADER TYPE is displayed on the upper line. • DISK HEADER is displayed on the lower line. Figure 3.170: M155 Header Type 7. Press left (A) or right (B) arrow to cycle through list of header types. 8. When desired header type is displayed press SELECT (C).
Page 152 (CDM) to enter Programming Mode. Press SELECT (C). • WINDROWER SETUP? is displayed on the upper line. Figure 3.172: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 153: Testing The Reel Up/Down Activate Function Using The Cab Display Module (Cdm)
1. Turn ignition key to RUN, or start the engine. 2. Press PROGRAM (A) and SELECT (C) on cab display module (CDM) to enter Programming Mode. Press SELECT (C). • WINDROWER SETUP? is displayed on the upper line. Figure 3.176: M155 CDM Programming Buttons 147649 Revision A...
Page 154 • NO/YES is displayed on the lower line. 4. Press right (A) arrow to select Yes. Press SELECT (B). Figure 3.177: M155 Diagnostic Functions 5. Press SELECT (D) until ACTIVATE FUNCTIONS? is displayed on the upper line.
Page 155: Testing The Header Tilt Activate Function Using The Cab Display Module (Cdm)
(CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.180: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 156: Testing The Reel Fore-Aft Activate Function Using The Cab Display Module (Cdm)
Programming Mode or press SELECT (D) to proceed to next ACTIVATE FUNCTION. Figure 3.183: M155 Header Tilt Angle Testing the Reel Fore-Aft Activate Function Using the Cab Display Module (CDM) NOTE: • The header MUST be attached to windrower to perform this procedure. For more information, refer to Attaching and Detaching Headers, page 213.
Page 157 (CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.184: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 158: Activating The Hydraulic Purge Using The Cab Display Module (Cdm)
1. Turn ignition key to RUN, or start the engine. 2. Press PROGRAM (A) and SELECT (C) on cab display module (CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.188: M155 CDM Programming Buttons 147649 Revision A...
Page 159 • NO/YES is displayed on the lower line. 4. Press right (A) arrow to select Yes. Press SELECT (B). Figure 3.189: M155 Diagnostic Functions 5. Press SELECT (B) until ACTIVATE FUNCTIONS? is displayed on the upper line.
Page 160: Testing The Knife Drive Circuit Using The Cab Display Module (Cdm)
11. Press right arrow to select YES. Press SELECT. 12. Press PROGRAM to exit Programming Mode or press Figure 3.192: M155 Hydraulic Purge Cycle SELECT to proceed to next ACTIVATE FUNCTION. Testing the Knife Drive Circuit Using the Cab Display Module (CDM) IMPORTANT: Do not over-speed a drive for a signiﬁcant length of time.
Page 161 • NO/YES is displayed on the lower line. 4. Press right (A) arrow to select Yes. Press SELECT (B). Figure 3.194: M155 Diagnostic Functions 5. Press SELECT (B) until ACTIVATE FUNCTIONS? is displayed on the upper line.
Page 162: Testing The Draper Drive Circuit Activate Function Using The Cab Display Module (Cdm)
(CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.197: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 163: Testing The Reel Drive Circuit Activate Function Using The Cab Display Module (Cdm)
• Press left (B) arrow to decrease draper speed. • Press right (D) arrow to increase draper speed. Verify the draper drive is functioning properly. Figure 3.200: M155 Draper Drive 9. Release the HAZARD (C) button. The drapers will stop.
Page 164 (CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.201: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 165: Testing The Rotary Disc Drive Circuit Activate Function Using The Cab Display Module (Cdm)
1. Turn ignition key to RUN, or start the engine. 2. Press PROGRAM (A) and SELECT (C) on cab display module (CDM) to enter Programming Mode. • WINDROWER SETUP? is displayed on the upper line. Figure 3.205: M155 CDM Programming Buttons 147649 Revision A...
Page 166 • NO/YES is displayed on the lower line. 4. Press right (A) arrow to select Yes. Press SELECT (B). Figure 3.206: M155 Diagnostic Functions 5. Press SELECT (B) until ACTIVATE FUNCTIONS? is displayed on the upper line.
Page 167: Testing The Double Windrower Attachment (Dwa) Drive Activate Function Using The Cab Display Module (Cdm)
(CDM) to enter Programming Mode. Press SELECT (C). • WINDROWER SETUP? is displayed on the upper line. Figure 3.209: M155 CDM Programming Buttons 3. Press SELECT (B) until DIAGNOSTIC MODE? is displayed in upper line. • NO/YES is displayed on the lower line.
Page 168: Engine Error Codes
• Press left (B) arrow to decrease DWA drive speed. • Press right (D) arrow to increase DWA drive speed. Verify the DWA drive is functioning properly. Figure 3.212: M155 DWA Drive 9. Release the HAZARD (C) button. The DWA drive will stop.
Page 169: Operation
4 Operation 4.1 Owner/Operator Responsibilities CAUTION • It is your responsibility to read and understand this manual completely before operating the windrower. Contact your Dealer if an instruction is not clear to you. • Follow all safety messages in the manual and on safety signs on the machine. •...
Page 170: Symbol Deﬁnitions
OPERATION 4.2 Symbol Deﬁnitions The following symbols are used to depict functions or reactions at the various instruments and controls. Learn the meaning of these symbols before operating the windrower. 4.2.1 Engine Functions These are the symbols that are used on the console. Figure 4.1: Engine Function Symbols A - Electrical Power –...
Page 171: Windrower Operating Symbols
OPERATION 4.2.2 Windrower Operating Symbols These are the symbols used on the console for windrower operation. Figure 4.2: Windrower Operating Symbols A - Turn Signals B - Hazard Warning Lights C - Forward D - Neutral E - Reverse F - Headlights Low Beam G - Headlights High Beam H - Work Light J - Lighter...
Page 172: Header Functions
OPERATION 4.2.3 Header Functions Figure 4.3: Header Function Symbols A - Program B - Header Index C - Return to Cut D - Conveyor/Auger Speed E - Float Left F - Float Right G - Reel Speed H - Disc Speed J - Reel Down K - Reel Forward L - Reel Up...
Page 173: Operating The Windrower
OPERATION 4.3 Operating the Windrower 4.3.1 Operational Safety CAUTION Follow these safety precautions: • Wear close ﬁtting clothing and protective shoes with slip resistant soles. • Remove foreign objects from the machine and surrounding area. • Carry with you any protective clothing and personal safety devices that COULD be necessary through the day.
Page 174: Break-In Period
OPERATION 4.3.2 Break-In Period The windrower is ready for normal operation. However there are several items to check and watch out for during the ﬁrst 150 hours. In addition to the following, perform the items speciﬁed in Break-In Inspections, page 426.
Page 175: Air Conditioning Compressor Coolant Cycling
OPERATION d. Adjust tension on air conditioning (A/C) compressor belt. Refer to Tensioning Air Conditioner (A/C) Compressor Belt, page 367. e. Distribute A/C refrigerant by cycling A/C switch. Refer to Air Conditioning Compressor Coolant Cycling, page 159. Check the entire A/C system for leakage at the beginning of each season. 2.
Page 176: Engine Operation
OPERATION 4.3.5 Engine Operation Starting the Engine DANGER • Avoid possible injury or death from a runaway machine. • This machine has safety devices which allow the engine to start only when the ground speed lever is in N-DETENT, the steering wheel is locked in the NEUTRAL position, and the header drive switch is in the OFF position.
Page 177 OPERATION 2. Ensure lock (A) at the base of the steering column is engaged at cab-forward or engine-forward position. 3. Move ground speed lever (GSL) (B) into N-DETENT. 4. Turn steering wheel until it locks. It may be possible to move the steering wheel slightly in the locked position.
Page 178: Engine Warmup
OPERATION IMPORTANT: • Do NOT operate starter for longer than 15 seconds at a time. • If engine does not start, wait at least two minutes before trying again. • After the third 15 second crank attempt, allow solenoid to cool for 10 minutes before further cranking attempts. If engine still does not start, refer to Engine Troubleshooting.
Page 179: Engine Intermediate Speed Control (Isc)
2200 rpm or the last selected rpm. NOTE: Previous M-Series windrower models included an OFF (full throttle) option which is NOT available on the M155. Engine ISC is useful when operating loads are reduced such as in light crop conditions that do not require the maximum engine rpm.
Page 180: Engine Temperature
OPERATION WARNING • To avoid personal injury or death from explosion or ﬁre, do NOT smoke or allow ﬂame or sparks near fuel tank when refueling. • NEVER refuel the windrower when the engine is hot or running. CAUTION Do NOT allow tank to empty. Running out of fuel can cause air locks and/or contamination of the fuel system.
Page 181: Engine Oil Pressure
OPERATION Engine Oil Pressure The nominal engine oil pressure is 10 psi (69 kPa) at low idle and 55.1 psi (380 kPa) at maximum rated speed. If the oil pressure drops below the preset level of 7.5 psi (52 kPa), the cab display module (CDM) ﬂashes an error code and error message.
Page 182 OPERATION WARNING • Avoid driving the machine with header removed. Removing header decreases the weight on drive wheels, reducing steering control. • If necessary to drive machine with header removed, use transmission ﬁeld speed range, do NOT exceed 1500 rpm engine speed, and avoid loose gravel and slopes. •...
Page 183: Entering And Exiting The Windrower
OPERATION Entering and Exiting the Windrower CAUTION To provide more secure hand and foot mobility, preventing slipping and possible injury, ALWAYS face the windrower and use the hand rail when dismounting (or mounting). NEVER attempt to get on or off a moving windrower.
Page 184: Driving Forward In Cab-Forward Mode
OPERATION Driving Forward in Cab-Forward Mode CAUTION Operate both steering wheel and ground speed lever slowly for familiarization. Avoid the common tendency of new Operators to oversteer. WARNING Do NOT drive windrower on road in cab-forward conﬁguration, unless it is equipped with the proper lighting and markings for cab-forward road travel.
Page 185: Driving Reverse In Cab-Forward Mode
The windrower can be equipped with an automatic steering system for use in the ﬁeld. An automated steering system is available as an option and can be installed by a MacDon Dealer. The GSL has been pre-wired at the factory with a switch. Refer to 7.1.2 Automated Steering Systems, page...
Page 186: Driving Forward In Engine-Forward Mode
OPERATION Driving Forward in Engine-Forward Mode In the engine-forward mode, the Operator’s station is facing toward the engine. If necessary, swivel operator’s station to engine-forward position as follows: Figure 4.20: Engine-Forward – Seat Faces Engine 1. Place ground speed lever (GSL) (A) in N-DETENT and lock steering wheel.
Page 187: Driving In Reverse In Engine-Forward Mode
OPERATION CAUTION Operate both steering wheel and ground speed lever slowly while becoming familiar with the machine. Remember that steering is more sensitive when speed-range control is in road speed position. Avoid the common tendency of new Operators to oversteer. 8.
Page 188: Spin Turning
OPERATION CAUTION Check to be sure all bystanders have cleared the area. 3. Move the ground speed lever (GSL) (C) rearward to desired speed. 4. Steer as shown. Figure 4.25: Steering the Windrower Spin Turning Hydrostatic steering provides signiﬁcantly more manoeuvrability than mechanical steering. CAUTION Be sure area is clear before making turns.
Page 189: Adjusting Caster Tread Width
OPERATION 1. SLOWLY return the ground speed lever (GSL) (A) to NEUTRAL and into N-DETENT. 2. Turn steering wheel until it locks. 3. Move throttle lever (B) to low idle position. NOTE: Avoid unnecessary idling. Stop engine if it will be idling for longer than ﬁve minutes.
Page 190 OPERATION Adjust the caster tread width as follows: 1. Raise rear of windrower slightly so that most of the weight is off the casters, using a jack or other lifting device under the frame at (A). NOTE: Lifting device should have a lifting capacity of at least 5000 lb (2270 kg).
Page 191: Transporting
Driving on the Road The M155 Self-Propelled Windrower is designed to be driven on the road with the engine facing forward to provide better visibility for the Operator and improved stability for the machine. The windrower is also capable of being driven on the road in cab-forward mode, but at a reduced speed and under restricted conditions.
Page 192 OPERATION CAUTION Check local laws for width regulations and lighting and marking requirements before transporting on roads. Before driving windrower on a roadway: 1. Ensure HEADER DRIVE switch (A) is pushed to OFF position (down). 2. Clean ﬂashing amber lamps, red tail and head lamps, and check that they work properly.
Page 193 (SLOW DOWN) with an audible alert. Move GSL closer to NEUTRAL to reduce speed. With header removed, steering control is reduced if weight is not added to drive wheels. If you must drive the windrower without header or MacDon weight system: • Operate in low speed range.
Page 194: Towing Header With Windrower
Towing Header with Windrower The windrower can be used to tow a MacDon draper header that has the slow speed transport option installed. Ensure the optional weight box or an approved header transporter is installed on the windrower to transfer weight to the lift arms.
Page 195 OPERATION DANGER To avoid bodily injury from fall of raised header, always engage safety props when working on or around raised header, and before going under header for any reason. 1. Set header on the ground (ﬁeld position). 2. Disconnect the following hydraulic and electrical connections: a.
Page 196 OPERATION 7. Remove ﬂoat pin from engaged position (A) and insert in storage location (B). Secure with lynch pin. Figure 4.40: Lift Arms 8. Remove pins (A) from lower end of lift linkages. NOTE: Pins (A) are also used to secure weight box to windrower linkage.
Page 197 OPERATION Disconnect the center-link as follows: 13. To unlock the center-link, pull up on latch (A) and position latch into notch (B) on top of hook. 14. Lift center-link off header pin. NOTE: If center-link self-alignment kit is installed, start engine and raise center-link with the REEL UP switch on the ground speed lever (GSL).
Page 198 OPERATION 3. Disconnect wiring connector (A) at front wheel. Figure 4.46: Header Transport Wheel 4. Remove clevis pin (D). 5. Push latch (C) and lift tow-bar (A) from hook. Release latch and replace clevis pin. 6. Unhook tow-bar from weight box. Figure 4.47: Header Transport Wheel CAUTION Check to be sure all bystanders have cleared the area.
Page 199 OPERATION 12. Move ﬂoat pins from working hole location (A) to disengage the ﬂoat and store pins at storage hole location (B). IMPORTANT: To prevent damage to the lift system when lowering header lift linkages without a header or weight box attached to windrower, ensure that ﬂoat engagement pin is installed in storage hole location and NOT installed in working hole location.
Page 200 OPERATION Attaching Header Transport Hitch to Header Attach header transport hitch to header as follows: 1. Position end (A) of the aft section onto front wheel hook (B). 2. Push down until latch (C) captures the end (A). 3. Secure latch (C) with clevis pin (D). Figure 4.52: Transport Hitch 4.
Page 201 OPERATION 6. Fully insert L-pin (A) in upper hole and turn pin to lock it. Secure with ring pin (B). 7. Make electrical connection at the joint (C). Figure 4.55: Transport Hitch 8. Make the electrical connection at the header wheel (A). Figure 4.56: Header Transport Wheel IMPORTANT: To prevent damage to the lift system when lowering...
Page 202 OPERATION 9. Drive windrower so that windrower lift arms are positioned into the weight box pockets. 10. Raise lift arms slightly, install locking pins (A) into pockets, and through windrower header lift linkages. Secure with hairpin. NOTE: Pins (A) were previously removed from the header lift linkage lower end.
Page 203 OPERATION 14. Start engine and press HEADER DOWN switch (A) on ground speed lever (GSL) to lower lift arms until the lift arm lifts away from the linkage at the rear of the lift arm. Figure 4.61: GSL 15. Attach slow speed transport hitch to the weight box tongue with drawbar pin.
Page 204 OPERATION DANGER To avoid bodily injury from fall of raised header, always engage safety props when working on or around raised header, and before going under header for any reason. 1. Set header on the ground (ﬁeld position). 2. Disconnect the following hydraulic and electrical connections: a.
Page 205 OPERATION 7. Remove ﬂoat pin from engaged position (A) and insert in storage location (B). Secure with lynch pin. Figure 4.66: Lift Arms 8. Remove pins (A) from lower end of lift linkages. NOTE: Pins (A) are also used to secure weight box to windrower linkage.
Page 206: Towing The Windrower (Emergency)
OPERATION Disconnect the center-link as follows: 13. To unlock the center-link, pull up on latch (A) and position latch into notch (B) on top of hook. 14. Lift center-link off header pin. NOTE: If center-link self-alignment kit is installed, start engine and raise center-link with the REEL UP switch on the ground speed lever (GSL).
Page 207: Final Drives
OPERATION WARNING With ﬁnal drives disengaged, the windrower may roll on a sloped surface. Before disengaging ﬁnal drives, attach windrower to towing vehicle. After towing, engage drives and ensure ground speed lever (GSL) is in N-DETENT before detaching from towing vehicle. Figure 4.72: Correct Towing Procedure IMPORTANT: •...
Page 208 OPERATION CAUTION Never operate engine in a closed building. Proper ventilation is required to avoid exhaust gas hazards. CAUTION Remember when working around storage batteries that all of the exposed metal parts are live. Never lay a metal object across the terminals because a spark and short circuit will result. 1.
Page 209: Operating With A Header
OPERATION 4.4 Operating with a Header The M155 Self-Propelled Windrower is designed to operate with a MacDon A-Series Auger Header, R-Series Rotary Header, or D-Series Rigid Draper Header with or without a Hay Conditioner. This section describes the attachment and detachment procedures and operating instructions for these header types.
Page 210 OPERATION 3. Pull lever (A) and rotate toward header to lower safety prop (B) onto cylinder. Repeat for opposite cylinder. Figure 4.75: Safety Prop 4. Disengage safety props by turning lever (A) away from header to raise safety prop until lever locks into vertical position.
Page 211: Header Float
OPERATION 4.4.2 Header Float The header ﬂoat feature allows the header to closely follow ground contours and respond quickly to sudden changes or obstacles. The ﬂoat setting is ideal when the cutterbar is on the ground with minimal bouncing, scooping, or pushing soil. IMPORTANT: •...
Page 212 OPERATION Figure 4.77: Cab Display Module (CDM) Float Adjustment A - CDM Display B - Left Float Adjustment C - Right Float Adjustment D - Header Tilt Down E - Header Lower F - Header Tilt Up Check header ﬂoat as follows: DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 213 OPERATION Header Force Required to Lift Header at the Ends with Lift Cylinder Fully Retracted Auger 75–85 lbf (335–380 N) Rotary 95–105 lbf (426–471 N) Draper 75–85 lbf (335–380 N) with stabilizer/transport wheels raised (if equipped) Adjusting Float Using Drawbolts Coarse ﬂoat adjustment is done using the drawbolts located on either side of the windrower.
Page 214: Float Options
OPERATION Float Options For draper headers without the deck shift option, auger headers, and rotary headers, the ﬂoat can be preprogrammed for three types of windrowing conditions. Example: • Position 1: Border • Position 2: Normal • Position 3: Rocky Set ﬂoat presets as follows: 1.
Page 215: Levelling The Header
OPERATION 6. Select a second preset with the FLOAT PRESET 2 SWITCH (C). 7. Repeat Steps to set 1., page 198 2., page 198 the ﬂoat. 8. Select a third preset with the FLOAT PRESET 3 SWITCH (D). 9. Repeat steps to set 1., page 198 2., page 198...
Page 216 OPERATION 2. Park windrower on level ground. 3. Raise header fully and hold momentarily to allow lift cylinders to rephase. Figure 4.84: Ground Speed Lever (GSL) 4. Set header approximately 6 in. (150 mm) off ground and check that member (A) is against link (B). Stop engine and remove key from ignition.
Page 217 OPERATION 8. Start engine and lower header onto ground until member (A) lifts off link (B) on both sides. 9. Stop engine and remove key. Figure 4.87: Lift Linkage 10. On high side, remove nut, washer, and bolt (A) that attaches shims (B) to link.
Page 218: Header Drive
OPERATION 4.4.4 Header Drive All header controls are conveniently located on the operator’s console and on the ground speed lever (GSL) handle. NOTE: Some controls are optional equipment and may not be present in your unit. Some controls may be installed, but will be nonfunctional for certain headers.
Page 219: Reversing The Header
OPERATION Reversing the Header NOTE: The optional hydraulic reversing kit must be installed. IMPORTANT: Hose plumbing to the reverser block is speciﬁc to the header type. To prevent damage to the reel on D-Series headers, refer to the reverser kit installation instruction MD# 169213 when switching from an auger header to a draper header on the same windrower.
Page 220 OPERATION Figure 4.92: Operator Console A - Program Button B - Display C - Header Tilt Down D - Header Tilt Up E - Display Selector Hydraulic Link (Optional) Adjust the header angle as follows: • To decrease (ﬂatten) header angle, operate HEADER TILT UP switch (D) on ground speed lever (GSL) handle so that cylinder retracts.
Page 221: Checking Self-Locking Center-Link Hook
OPERATION Mechanical Link Adjust header angle as follows: 1. Lower header to ground, shut down windrower and remove key from ignition. 2. Loosen nut (A) on center-link. • To increase (steepen) angle, rotate barrel (B) to lengthen center-link. • To decrease (ﬂatten) angle, rotate barrel (B) to shorten center-link.
Page 222: Cutting Height
OPERATION 4. Push up on actuator rod and lock pin should lift with the handle. Figure 4.96: Center-Link Hook 4.4.6 Cutting Height Figure 4.97: Operator Console Cutting height is adjusted by raising or lowering the header with the HEADER UP (B) or HEADER DOWN (C) switches on the ground speed lever (GSL).
Page 223: Return To Cut
OPERATION 4.4.7 Return to Cut The M-Series monitoring system will assist you in maintaining the desired cutting height with the RETURN TO CUT feature. This feature can be turned OFF or ON with a switch on the cab display module (CDM). The return to cut (RTC) feature provides preset cutting height and tilt angle settings for the header.
Page 224: Using The Return To Cut Feature
OPERATION 4. Adjust the header angle with the HEADER TILT UP (E) or HEADER TILT DOWN (F) switches on the GSL. The CDM displays between 00.0 and 10.0. This step is not required when height only has been preselected. 5. Press the RETURN TO CUT switch (A) on the CDM. The indicator light will illuminate and the settings are now programmed into the windrower control module (WCM).
Page 225: Auto Raise Height
OPERATION NOTE: If the header cannot return to the preset height or angle within 30 seconds, the RETURN TO CUT feature will deactivate to prevent the hydraulic oil from overheating. Push the RETURN TO CUT switch (A) to reactivate. 4.4.8 Auto Raise Height The header can be automatically raised if programmed into the cab display module (CDM).
Page 226: Using The Auto Raise Height Feature
OPERATION 4. Press right arrow (D), then SELECT. SET KNIFE SPEED? is displayed. 5. Press SELECT (C) until AUTO RAISE HEIGHT is displayed. 6. Press left arrow (E) or right arrow (D) to change value on lower line. Working range is 4.0 to 9.5. At 10.0, the feature is disabled and “OFF”...
Page 227: Double Windrowing
Refer to MacDon M-Series Windrower Double Windrow Attachment Manual (MD #169216) for complete operating and maintenance instructions. The manual is shipped with the DWA kit.
Page 228: Double Windrow Attachment (Dwa) Draper Speed
OPERATION Double Windrow Attachment (DWA) Draper Speed The draper speed is controlled with the rotary switch (A) next to the rocker switch on the operator’s console. Figure 4.105: Operator’s Console 4.4.11 Swath Roller Operation The swath roller is raised and lowered with the DWA UP (A) and DWA DOWN (B) switches on the ground speed lever (GSL) or with the rocker switch on the operator’s console.
Page 229: Attaching And Detaching Headers
4.5 Attaching and Detaching Headers 4.5.1 Attaching a D-Series Header D50, D60, and D65 headers can be attached to an M155 or M205 Self-Propelled Windrower. For attachment procedure, refer to the section for your speciﬁc windrower model. Refer to the following instructions based on the type of center-link installed on your windrower: •...
Page 230: Attaching A D-Series Header: Hydraulic Center-Link With Optional Self-Alignment
OPERATION 2. Position boot (B) onto lift linkage (A) and reinstall pin (C). Pin may be installed from either side of boot. 3. Secure pin (C) with hairpin (D). 4. Repeat for opposite side. Figure 4.110: Header Boot Attaching a D-Series Header: Hydraulic Center-Link with Optional Self-Alignment NOTE: Draper header boots must be installed onto the windrower lift linkage before starting this procedure.
Page 231 OPERATION CAUTION Check to be sure all bystanders have cleared the area. IMPORTANT: Remove protective cover from exhaust stack prior to starting engine. 2. Start the engine and activate the header down button (A) on the ground speed lever (GSL) to fully retract header lift cylinders.
Page 232 OPERATION 6. Use the following GSL functions to position the center-link hook above the header attachment pin: • Reel up (A) to raise the center-link • Reel down (B) to lower the center-link • Header tilt up (C) to retract the center-link •...
Page 233 OPERATION 11. Engage safety props on both lift cylinders as follows: a. Stop engine and remove key from ignition. b. Pull lever (A) and rotate towards the header to release and lower safety prop (B) onto the lift cylinder. c. Repeat for opposite lift cylinder. Figure 4.118: Safety Prop 12.
Page 234 OPERATION 14. Remove clevis pin from storage position (B) in linkage and insert into hole (A) to engage ﬂoat springs. Secure with hairpin. Figure 4.120: Header Float Linkage 15. Disengage safety prop by turning lever (A) downwards to release and lower stop until lever locks into vertical position.
Page 235: Attaching A D-Series Header: Hydraulic Center-Link Without Self-Alignment
OPERATION 19. Connect header drive hoses (A) and electrical harness (B) to header. Refer to the draper header operator’s manual. Figure 4.123: Header Drive Hoses and Harness 20. Connect reel hydraulics (A) at right cab-forward side of windrower. Refer to the draper header operator’s manual.
Page 236 OPERATION 1. Remove hairpin (A) from pins (B), and remove pins from both header legs. Figure 4.125: Header Leg CAUTION Check to be sure all bystanders have cleared the area. IMPORTANT: Remove protective cover from exhaust stack prior to starting engine. 2.
Page 237 OPERATION 4. Drive the windrower slowly forward until the boots (A) enter the header legs (B). Continue driving slowly forward until lift linkages contact the support plates in the header legs and the header nudges forward. 5. Ensure the lift linkages are properly engaged in the header legs and are contacting the support plates.
Page 238 OPERATION CAUTION Check to be sure all bystanders have cleared the area. 10. Start the engine. 11. Press the header up switch (A) to raise header to maximum height. NOTE: If one end of the header does NOT fully raise, rephase the lift cylinders as follows: a.
Page 239 OPERATION 13. Install pin (B) through the header leg (engaging U-bracket in lift linkage) on both sides and secure with hairpin (A). 14. Raise header stand (D) to storage position by pulling spring pin (C) and lifting stand into uppermost position. Release spring pin.
Page 240 OPERATION CAUTION Check to be sure all bystanders have cleared the area. 18. Start the engine and activate the header down switch (A) on the GSL to fully lower the header. 19. Stop engine and remove key from ignition. Figure 4.136: GSL 20.
Page 241: Attaching A D-Series Header: Mechanical Center-Link
OPERATION Attaching a D-Series Header: Mechanical Center-Link NOTE: Draper header boots must be installed onto the windrower lift linkage before starting this procedure. Refer to Attaching Header Boots, page 213. DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 242 OPERATION 3. Drive the windrower slowly forward until the boots (A) enter the header legs (B). Continue driving slowly forward until lift linkages contact the support plates in the header legs and the header nudges forward. 4. Ensure the lift linkages are properly engaged in the header legs and are contacting the support plates.
Page 243 OPERATION 11. Engage safety props on both lift cylinders as follows: a. Stop engine and remove key from ignition. b. Pull lever (A) and rotate towards the header to release and lower safety prop (B) onto the lift cylinder. c. Repeat for opposite lift cylinder. Figure 4.144: Safety Prop 12.
Page 244 OPERATION 14. Remove clevis pin from storage position (B) in linkage and insert into hole (A) to engage ﬂoat springs. Secure with hairpin. Figure 4.146: Header Float Linkage 15. Disengage safety prop by turning lever (A) downwards to release and lower stop until lever locks into vertical position.
Page 245: Detaching A D-Series Header
OPERATION 19. Connect header drive hoses (A) and electrical harness (B) to header. Refer to the draper header operator’s manual. Figure 4.149: Header Drive Hoses and Harness 20. Connect reel hydraulics (A) at right cab-forward side of windrower. Refer to the draper header operator’s manual.
Page 246: Detaching A D-Series Header: Hydraulic Center-Link
OPERATION Detaching a D-Series Header: Hydraulic Center-Link DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. 1. Start engine and press header up (A) switch to raise header to maximum height.
Page 247 OPERATION 5. Remove the pin (B) by removing the hairpin (A) from header leg on both sides. 6. Lower header stand (D) by pulling spring loaded pin (C). Release spring pin to lock stand. Figure 4.153: Header Stand 7. Remove clevis pin from location (A) to disengage ﬂoat springs and insert in storage hole (B).
Page 248 OPERATION 10. Disconnect header drive hydraulics (A) and electrical harness (B) from header and store in support on windrower left cab-forward side. Refer to the draper header operator’s manual for further information. Figure 4.156: Header Drive Hydraulics 11. Disconnect reel hydraulics (A) from header and store on bracket at windrower left cab-forward side.
Page 249: Detaching A D-Series Header: Mechanical Center-Link
OPERATION 13. Disconnect center-link by lifting release (B) and lift hook (A) off header. NOTE: If optional center-link self-alignment kit is installed, lift release (B) and then operate the link lift cylinder with REEL UP switch on GSL to disengage the center-link from the header. NOTE: If hay conditioner is installed, watch clearances on both sides.
Page 250 OPERATION 4. To engage the safety props, pull lever (A) and rotate toward header to lower safety prop (B) onto cylinder. Repeat for the opposite cylinder. Figure 4.162: Safety Prop 5. Remove the clevis pin (B) by removing hairpin (A) from header leg on both sides.
Page 251 OPERATION 7. Remove the clevis pin from location (A) to disengage ﬂoat springs and insert in storage hole (B). Secure with lynchpin. CAUTION To prevent damage to the lift system when lowering header lift linkages without a header or weight box attached to the windrower, ensure the ﬂoat engagement pin is installed in storage position (B) and NOT in engaged position (A).
Page 252 OPERATION 11. Disconnect reel hydraulics (A) from header and store on bracket at windrower left cab-forward side. Refer to the draper header operator’s manual for further information. Figure 4.167: Reel Hydraulics 12. Loosen nut (A) and rotate barrel (B) to relieve load on link.
Page 253: Attaching An A-Series Header
OPERATION 4.5.3 Attaching an A-Series Header A30-D, A30-S, and A40-D headers can be attached to an M155 or M205 Self-Propelled Windrower. For attachment procedure, refer to the section for your speciﬁc windrower model. Refer to the following instructions based on the type of center-link installed on your windrower: •...
Page 254: Hydraulic Link With Optional Self-Alignment Kit
OPERATION Hydraulic Link with Optional Self-Alignment Kit 1. Adjust position of the center-link cylinder with the reel up (A), reel down (B), header tilt up (C), and header tilt down (D) switches on the ground speed lever (GSL) to position the hook above the header attachment pin. IMPORTANT: Hook release must be down to enable self-locking mechanism.
Page 255 OPERATION 1. Remove hairpin (A) from clevis pin (B) and remove clevis pin from the header boots (C) on both sides of the header. Figure 4.172: Header Boot CAUTION To prevent damage to the lift system when lowering header lift linkages without a header or weight box attached to the windrower, ensure the ﬂoat engagement pin is installed in storage position (B) and NOT in engaged position (A).
Page 256 OPERATION 3. Relocate pin (A) in frame linkage as required to raise the center-link (B) until the hook is above the attachment pin on the header. IMPORTANT: If the center-link is too low, it may contact the header as the windrower approaches the header for hookup.
Page 257 OPERATION 7. Push down on rod end of link cylinder (B) until hook engages and locks onto header pin. IMPORTANT: Hook release must be down to enable self-locking mechanism. If the release is open (up), manually push it down after hook engages header pin. 8.
Page 258 OPERATION 11. Engage safety props on both lift cylinders as follows: a. Stop engine and remove key from ignition. b. Pull lever (A) and rotate towards the header to release and lower safety prop (B) onto the lift cylinder. c. Repeat for opposite lift cylinder. Figure 4.180: Safety Prop 12.
Page 259 OPERATION 13. Remove lynch pin from clevis pin (A) in stand (B). 14. Hold stand (B) and remove pin (A). 15. Move stand (B) to storage position by inverting and relocating onto bracket as shown. Reinsert clevis pin (A) and secure with lynch pin. Figure 4.182: Header Stand 16.
Page 260 OPERATION CAUTION Check to be sure all bystanders have cleared the area. 19. Start the engine and activate the header down switch (A) on the GSL to fully lower the header. 20. Stop engine and remove key from ignition. Figure 4.185: GSL 21.
Page 261: Attaching An A-Series Header: Mechanical Center-Link
OPERATION Attaching an A-Series Header: Mechanical Center-Link DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. 1. Remove hairpin (A) from clevis pin (B) and remove clevis pin from the header boots (C) on both sides of the header.
Page 262 OPERATION 3. Drive the windrower slowly forward until the windrower feet (A) enter the header boots (B). Continue driving slowly forward until the feet engage the boots and the header nudges forward. Figure 4.190: Header Boot 4. Stop engine and remove key from ignition. 5.
Page 263 OPERATION 10. Engage safety props on both lift cylinders as follows: a. Stop engine and remove key from ignition. b. Pull lever (A) and rotate towards the header to release and lower safety prop (B) onto the lift cylinder. c. Repeat for opposite lift cylinder. Figure 4.193: Safety Prop 11.
Page 264 OPERATION 12. Remove lynch pin from clevis pin (A) in stand (B). 13. Hold stand (B) and remove pin (A). 14. Move stand (B) to storage position by inverting and relocating onto bracket as shown. Reinsert clevis pin (A) and secure with lynch pin. Figure 4.195: Header Stand 15.
Page 265: Detaching An A-Series Header
OPERATION CAUTION Check to be sure all bystanders have cleared the area. 18. Start the engine and activate the header down switch (A) on the GSL to fully lower the header. 19. Stop engine and remove key from ignition. Figure 4.198: GSL 20.
Page 266: Detaching An A-Series Header: Hydraulic Center-Link
OPERATION Detaching an A-Series Header: Hydraulic Center-Link WARNING To avoid bodily injury or death from unexpected startup of machine, always stop engine and remove key before making adjustments to the machine. 1. Start engine and press header up button (A) on ground speed lever (GSL) to raise header to maximum height.
Page 267 OPERATION 5. Remove hairpin from the clevis pin (A) and remove clevis pin from header boots (B) on both sides. Figure 4.202: Header Boot 6. Lower stand (A) by pulling clevis pin (B), inverting stand, and relocating on bracket. Reinsert pin (B) and secure with hairpin.
Page 268 OPERATION CAUTION Check to be sure all bystanders have cleared the area. 8. Disengage safety props by turning lever (A) away from header to raise safety prop until lever locks into vertical position. Repeat for opposite cylinder. 9. Start engine, choose a level area, and lower header to the ground.
Page 269: Detaching An A-Series Header: Mechanical Center-Link
OPERATION 13. Disconnect header drive hydraulics electrical harness (B). Refer to the auger header operator’s manual. 14. Back windrower slowly away from header. Figure 4.208: Header Drive Hydraulics 15. Reinstall clevis pin (B) into header boot (C) and secure with hairpin (A). Repeat for opposite side. Figure 4.209: Header Boots Detaching an A-Series Header: Mechanical Center-Link WARNING...
Page 270 OPERATION DANGER To avoid bodily injury from fall of raised header, always engage safety props when working on or around raised header, and before going under header for any reason. 4. Pull lever (A) and rotate toward header to lower safety prop (B) onto cylinder.
Page 271 OPERATION 6. Lower the header stand (A) by pulling clevis pin (B), inverting stand, and relocating on bracket. Reinsert clevis pin (B) and secure with hairpin. Figure 4.213: Header Stand 7. Remove clevis pin from linkage (A) to disengage ﬂoat springs and insert in storage hole (B).
Page 272 OPERATION 10. Loosen nut (A) and rotate barrel (B) to relieve load on link. 11. Remove cotter pin (D) on clevis pin (C) and remove pin to disconnect from header. 12. Reinstall clevis pin in header. Figure 4.216: Mechanical Center-Link 13.
Page 273: Attaching An R-Series Header
OPERATION 4.5.5 Attaching an R-Series Header R-Series Rotary Disc Headers (R80 and R85) can be attached to an M155 or M205 Self-Propelled Windrower. For attachment procedure, refer to the section for your speciﬁc windrower model. Refer to the following instructions based on the type of center-link installed on your windrower: •...
Page 274 OPERATION CAUTION Check to be sure all bystanders have cleared the area. IMPORTANT: Remove protective cover from exhaust stack prior to starting engine. 2. Start the engine and activate the header down button (A) on the ground speed lever (GSL) to fully retract header lift cylinders.
Page 275 OPERATION 5. Use the following GSL functions to position the center-link hook above the header attachment pin: • Reel up (A) to raise the center-link • Reel down (B) to lower the center-link • Header tilt up (C) to retract the center-link •...
Page 276 OPERATION 10. Engage safety props on both lift cylinders as follows: a. Stop engine and remove key from ignition. b. Pull lever (A) and rotate towards the header to release and lower safety prop (B) onto the lift cylinder. c. Repeat for opposite lift cylinder. Figure 4.227: Safety Prop 11.
Page 277 OPERATION 12. Remove clevis pin from storage position (B) in linkage and insert into hole (A) to engage ﬂoat springs. Secure with hairpin. Figure 4.229: Header Float Linkage 13. Disengage safety prop by turning lever (A) downwards to release and lower stop until lever locks into vertical position.
Page 278: Attaching An R-Series Header: Hydraulic Center-Link Without Self-Alignment
OPERATION 17. Connect header drive hoses (A) and electrical harness (B) to header. Refer to the rotary disc header operator’s manual. Figure 4.232: Header Drive Hoses and Harness Attaching an R-Series Header: Hydraulic Center-Link without Self-Alignment DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 279 OPERATION CAUTION Check to be sure all bystanders have cleared the area. IMPORTANT: Remove protective cover from exhaust stack prior to starting engine. 2. Start the engine and activate the header down button (A) on the ground speed lever (GSL) to fully retract header lift cylinders.
Page 280 OPERATION 5. Use the following GSL functions to position the center-link hook above the header attachment pin: • Header tilt up (A) to retract the center-link • Header tilt down (B) to extend the center-link 6. Stop engine and remove key from ignition. Figure 4.238: GSL 7.
Page 281 OPERATION 11. Engage safety props on both lift cylinders as follows: a. Stop engine and remove key from ignition. b. Pull lever (A) and rotate towards the header to release and lower safety prop (B) onto the lift cylinder. c. Repeat for opposite lift cylinder. Figure 4.241: Safety Prop 12.
Page 282 OPERATION 13. Remove clevis pin from storage position (B) in linkage and insert into hole (A) to engage ﬂoat springs. Secure with hairpin. Figure 4.243: Header Float Linkage 14. Disengage safety prop by turning lever (A) downwards to release and lower stop until lever locks into vertical position.
Page 283: Attaching An R-Series Header: Mechanical Center-Link
OPERATION 18. Connect header drive hoses (A) and electrical harness (B) to header. Refer to the rotary disc header operator’s manual. Figure 4.246: Header Drive Hoses and Harness Attaching an R-Series Header: Mechanical Center-Link DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 284 OPERATION CAUTION Check to be sure all bystanders have cleared the area. IMPORTANT: Remove protective cover from exhaust stack prior to starting engine. 2. Start the engine and activate the header down button (A) on the ground speed lever (GSL) to fully retract header lift cylinders.
Page 285 OPERATION CAUTION Check to be sure all bystanders have cleared the area. 8. Start the engine. 9. Press the header up switch (A) to raise header to maximum height. NOTE: If one end of the header does NOT fully raise, rephase the lift cylinders as follows: a.
Page 286 OPERATION 11. Install clevis pin (A) through boot and foot and secure with hairpin (B). Repeat for opposite side. IMPORTANT: Ensure clevis pin (A) is fully inserted and hairpin is installed behind bracket. Figure 4.254: Header Boot 12. Remove clevis pin from storage position (B) in linkage and insert into hole (A) to engage ﬂoat springs.
Page 287: Detaching An R-Series Header
OPERATION CAUTION Check to be sure all bystanders have cleared the area. 15. Start the engine and activate the header down switch (A) on the GSL to fully lower the header. 16. Stop engine and remove key from ignition. Figure 4.257: GSL 17.
Page 288: Detaching An R-Series Header: Hydraulic Center-Link
OPERATION Detaching an R-Series Header: Hydraulic Center-Link DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. 1. Start engine and press header up (A) switch to raise header to maximum height.
Page 289 OPERATION 5. Remove hairpin from clevis pin (A) and remove clevis pin from header boot (B) on both sides of header. Figure 4.261: Header Boots 6. Remove clevis pin from location (A) to disengage ﬂoat springs and insert into storage hole (B). Secure with hairpin.
Page 290 OPERATION 9. Activate header tilt up (A) and header tilt down (B) cylinder switches on GSL to release load on center-link cylinder. Figure 4.264: GSL 10. Stop engine and remove key from ignition. 11. Lift hook release (C) and lift hook (B) off header pin. NOTE: If optional center-link lift cylinder is installed, lift release (C) and then operate the link lift cylinder...
Page 291: Detaching An R-Series Header: Mechanical Center-Link
OPERATION 14. Reinstall clevis pin (A) through boot (C) and secure with hairpin (B). Repeat for opposite side. Figure 4.267: Header Boot Detaching an R-Series Header: Mechanical Center-Link DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 292 OPERATION 3. Stop engine and remove key from ignition. 4. Pull lever (A) and rotate toward header to lower safety prop (B) onto cylinder. Repeat for opposite cylinder. Figure 4.269: Safety Prop 5. Remove hairpin (B) from clevis pin (A) and remove pin from left and right header boots (C) on header.
Page 293 OPERATION 6. Remove clevis pin from location (A) to disengage ﬂoat springs and insert in storage hole (B). Secure with hairpin. CAUTION To prevent damage to the lift system when lowering header lift linkages without a header or weight box attached to the windrower, ensure the ﬂoat engagement pin is installed in storage position (B) and NOT in engaged position (A).
Page 294 OPERATION 10. Remove cotter pin on clevis pin (B) and remove pin to disconnect from header. Reinstall clevis pin in header. 11. Tighten nut against barrel (A). A slight tap with a hammer is sufﬁcient. Figure 4.274: Mechanical Center-Link 12. Disconnect header drive hydraulics...
Page 295: Operating With A D-Series Header
If installing a HC10 Hay Conditioner, Reverser kit #B4656 is recommended. If necessary, obtain the recommended kit from your MacDon Dealer and install it in accordance with the instructions supplied with the kit. Refer to the following procedures according to the center-link installed on the windrower: •...
Page 296: Attaching Header Boots
There are also up to ﬁve reel drive hoses on the right cab-forward side. If necessary, obtain the following kit from your MacDon Dealer. • Base Kit MD #B5577 (Installation instruction is supplied with the kit.) Figure 4.279: Draper Header Reel Hydraulics 4.6.2 Attaching Header Boots...
Page 297: Header Position
OPERATION 2. Position boot (B) onto lift linkage (A) and reinstall pin (C). Pin may be installed from either side of boot. 3. Secure pin (C) with hairpin (D). 4. Repeat for opposite side. Figure 4.282: Header Boot 4.6.3 Header Position Refer to for procedures for controlling header height, header tilt, and ﬂoat.
Page 298: Adjusting The Reel Height
OPERATION 4.6.5 Adjusting the Reel Height Press and hold the switch for the desired movement of the reel REEL UP (A) or REEL DOWN (B). IMPORTANT: Under certain conditions, with reel raised to full height, the reel tines may contact the cab roof. Exercise care to avoid damage to the machine.
Page 299 OPERATION Figure 4.285: Operator Console CAUTION Check to be sure all bystanders have cleared the area. 1. Set the minimum reel speed as follows: IMPORTANT: Set the minimum reel speed while stationary with the ground speed lever (GSL) in the N-DETENT position. a.
Page 300 OPERATION b. Press the DISPLAY SELECTOR button (E) on the GSL to display ##.## ##.# REEL IND or press FAST (C) or SLOW (D) switch. • The displayed value (##.##) = reel speed (rpm or mph or km/h • The displayed value (#.##) = reel index value c.
Page 301: Setting The Reel Only Speed
OPERATION Setting the Reel Only Speed Figure 4.286: Operator Console A - Display B - Header Index C - Reel Fast D - Reel Slow E - Display Selector CAUTION Check to be sure all bystanders have cleared the area. Set the speed of the reel independently of ground speed as follows while operating the windrower: NOTE: This procedure is similar to changing the draper speed “on the go”...
Page 302: Draper Speed
OPERATION 4.6.7 Draper Speed Draper speed affects the orientation of stalks in the windrow. For more information refer to your header operator’s manual for guidelines. The draper speed can be set to run independently, or relative to the ground speed of the windrower with the header index function.
Page 303: Setting Draper Index
OPERATION IMPORTANT: Set the minimum draper speed while stationary with the ground speed lever (GSL) in the N-DETENT position. 1. Engage header. 2. Set HEADER INDEX (B) switch to ON. 3. Press DISPLAY SELECTOR button (E) until display (A) shows ##.## DRAPER MIN. The displayed value (##.##) = draper speed (mph or km/h 4.
Page 304: Setting Draper Speed Independent Of Ground Speed
OPERATION 3. Press DISPLAY SELECTOR (E) on the ground speed lever (GSL) to display DRAPER INDX at (A) on the cab display module (CDM). 4. Press DRAPER FAST (C) or SLOW (D) on the CDM until display (A) shows ##.## ##.# DRAP IND with the desired index value.
Page 305: Knife Speed
OPERATION NOTE: This procedure can also be used to change the draper speed “on the go”. CAUTION Check to be sure all bystanders have cleared the area. 1. Engage header. 2. Set HEADER INDEX switch (B) to OFF. 3. Press DISPLAY SELECTOR button (E) to show ##.# DRAPER SPEED on the cab display module (CDM) (A). Displayed value (##.#) = draper speed (mph or km/h 4.
Page 306: Setting Knife Speed "On The Go
OPERATION NOTE: The knife speed can be adjusted without shutting down the machine, though it is recommended that the windrower be stopped before adjusting CDM settings. Setting Knife Speed “On the Go” Figure 4.290: Operator Console CAUTION Check to be sure all bystanders have cleared the area. Display and set knife speed “on the go”...
Page 307: Deck Shift Control
OPERATION 4.6.9 Deck Shift Control When connected to a draper header with the deck shift option, hydraulic deck shift control allows you to select the deck position and draper rotation of the header from the operator’s station. It selects crop delivery from the left side, center, or right side of the header.
Page 308 OPERATION 2. Using HEADER TILT SWITCHES (A) and (B) on the ground speed lever (GSL), set center-link to mid-range position (05.0 on Display [E]). Figure 4.292: Operator Console 3. Select a deck position with DECK SHIFT switch (A) from one of the following delivery options: •...
Page 309 OPERATION 7. Select a second deck position with the DECK SHIFT switch (A). 8. Repeat step and step to set 5., page 292 6., page 292 the ﬂoat for the second deck position. 9. Select a third deck position with the DECK SHIFT switch (A).
Page 310: Operating With An A-Series Header
OPERATION 4.7 Operating with an A-Series Header The M155 is factory-equipped to run an A-Series Auger Header. 4.7.1 Auger Speed Auger Speed on A30-D Headers On A30-D Auger Headers, the auger speed is ﬁxed to the knife speed. The auger speed is NOT monitored and cannot be displayed.
Page 311: Reel Speed
OPERATION NOTE: Changes to reel speed will affect the auger speed directly. However, when adjusting reel speed, the auger speed value displayed on the CDM will not change. 4. Press FAST (C) or SLOW (D) on the CDM until the desired auger speed is achieved. 4.7.2 Reel Speed Refer to your header operator’s manual for recommended reel speed settings for your particular crop.
Page 312 OPERATION Adjusting Reel Only Speed The A40 reel drive is hydraulically driven. Adjusting reel speed also changes auger speed, unless the auger speed is initially set at a predetermined value. The following procedure sets the auger speed so that subsequent reel speed adjustments will only affect the reel.
Page 313 OPERATION Adjusting Reel Speed “On The Go” Figure 4.298: Operator Console A - Display B - Header Index C - Auger Fast D - Auger Slow E - Reel Fast F - Reel Slow G - Display Selector The reel speed adjustment range is from 15 to 85 rpm. Adjust the reel speed while the machine is in operation as follows: 1.
Page 314 OPERATION Figure 4.299: Operator Console CAUTION Check to be sure all bystanders have cleared the area. 1. Set the minimum reel speed as follows: IMPORTANT: Set the minimum reel speed while stationary with the ground speed lever (GSL) in the N-DETENT position. a.
Page 315 OPERATION Figure 4.300: Operator Console a. Set the HEADER INDEX switch (B) to ON. b. Press the DISPLAY SELECTOR button (E) on the GSL to display ##.## ##.# REEL IND or press the FAST (C) or SLOW (D) switch. • The displayed value (##.##) = reel speed (mph or km/h or rpm •...
Page 316: Knife Speed
OPERATION 4.7.3 Knife Speed The ideal knife cutting speed should achieve a clean cut. Crop types and conditions usually inﬂuence the knife and forward speeds. When the header is ﬁrst attached to the windrower, the windrower control module (WCM) receives a code from the header that determines the knife speed range and the minimum speed.
Page 317 OPERATION Display and set knife speed “on the go” as follows: 1. Engage header. 2. Press PROGRAM (D) and SELECT (E) on cab display module (CDM) until display (A) shows #### KNIFE SPM. The displayed value (####) = strokes per minute. 3.
Page 318: Operating With An R-Series Header
If required, obtain kit MD #B5510 from your MacDon Dealer, and install it in accordance with the instructions supplied with the Kit.
Page 319: Setting Disc Speed
OPERATION Setting Disc Speed Figure 4.303: Operator Console A - Display B - Header Index C - Fast D - Slow E - Display Selector CAUTION Check to be sure all bystanders have cleared the area. Follow these steps to set the disc speed: 1.
Page 321: Maintenance And Servicing
5 Maintenance and Servicing The following section will guide you through some of the windrower’s basic maintenance and service requirements. More detailed maintenance, service, and parts information is available from your MacDon Dealer. 5.1 Preparation For Servicing WARNING To avoid personal injury, before servicing adapter/header or opening drive covers: •...
Page 322: Engine Compartment Hood
MAINTENANCE AND SERVICING 5.2 Engine Compartment Hood The engine hood has two open positions. The lowest is for general maintenance such as checking and adding ﬂuid, servicing the cooling box, etc. The highest position accommodates full access to the engine bay. 5.2.1 Opening Hood (Lower Position) DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove...
Page 323: Closing Hood (Lower Position)
MAINTENANCE AND SERVICING 5.2.2 Closing Hood (Lower Position) 1. Grasp the strap at (B) and loop under upper hook (C). IMPORTANT: Failure to hook strap may result in it becoming entangled with the screen cleaners or the latch. 2. Pull down on strap (B), grasp the hood when within reach and lower until hood engages latch (A).
Page 324: Closing Hood (Highest Position)
MAINTENANCE AND SERVICING 2. Locate latch (A) behind grill and lift to release hood. 3. Raise hood until strap (B) (which should be looped under hooks [C] and [(D]) stops it at approximately a 40° angle. 4. Remove strap from hook (C) and allow hood to rise slightly further.
Page 325: Maintenance Platforms
MAINTENANCE AND SERVICING 5.3 Maintenance Platforms Swingaway platform/stair units are provided on both sides of the windrower for access to the operator’s station and engine bay. The platforms can be swung away from the windrower to allow access to the hydraulics plumbing or battery. The maintenance platforms have three positions: •...
Page 326: Closing Platforms (Standard Position)
MAINTENANCE AND SERVICING 1. Push latch (A) and pull platform (B) toward walking beam until it stops and latch engages in open position. NOTE: Ensure the platform is latched before using. Figure 5.6: Platform Latch 5.3.2 Closing Platforms (Standard Position) CAUTION Do NOT stand on an unlocked side platform.
Page 327: Opening Platforms (Major Service Position)
MAINTENANCE AND SERVICING 1. If platform is latched in the open position, push latch (A) to unlock it. 2. Grasp handle (B) on platform and push forward until it stops and latch (A) engages. NOTE: Ensure the platform is latched properly before using. Figure 5.8: Platform Latch 5.3.3 Opening Platforms (Major Service Position) To improve access to the hydraulics plumbing or battery, the platforms can be swung away from the windrower.
Page 328: Closing Platforms (Major Service Position)
MAINTENANCE AND SERVICING 2. Unlock latch (A) and move platform (B) toward open position. Do NOT lock in full aft position. Figure 5.10: Platform Latch 3. Remove the nut and bolt that secure link (A) to the frame. Swing link (A) out of the way. 4.
Page 329 MAINTENANCE AND SERVICING 4. Move platform (B) forward (cab-forward) until it stops and latch (A) engages. 5. Close the hood. Refer to 5.2.2 Closing Hood (Lower Position), page 307. Figure 5.13: Platform Latch 147649 Revision A...
Page 330: Windrower Lubrication
MAINTENANCE AND SERVICING 5.4 Windrower Lubrication WARNING To avoid personal injury, before servicing windrower or opening drive covers, follow procedures in the SAFETY section. The greasing points are marked on the machine by decals showing a grease gun and grease interval in hours of operation.
Page 331: Lubrication Points
MAINTENANCE AND SERVICING 5.4.2 Lubrication Points Figure 5.15: Lubrication Points A - Forked Caster Wheel Bearing (2 Places) (Outer – Both Wheels) B - Top Link (2 Places) (Both Sides) C - Lubrication Decal (MD #183411) D - Caster Pivot (Both Sides) E - Forked/Formed Caster Wheel Bearing (2 Places) (Inner –...
Page 332: Operator's Station
Swivel and lock the operator’s station and the display should return to normal. d. If the engine does NOT shut down, the seat position switches require adjustment. See your MacDon Dealer. 4. With the windrower moving at less than 5 mph (8 km/h): a.
Page 333: Checking Engine Interlock
ﬂash and the engine should NOT turn over. If the engine turns over, the system requires adjustment. See your MacDon Dealer. A properly functioning system should operate as follows. If not, see your MacDon Dealer. • The starter should engage ONLY when the GSL is in N-DETENT, steering wheel locked in the CENTER position and the header drive switch is in the OFF position.
Page 334: Adjusting Ground Speed Lever (Gsl) Fore-Aft Movement
MAINTENANCE AND SERVICING 1. Remove the ﬁve screws (A) securing control panel (B) to console, remove panel, and store in the tray. Figure 5.16: Header Control Panel 2. Back off the jam nut (A) and turn nut (B) to either tighten or loosen the pivot.
Page 335: Steering Adjustments
MAINTENANCE AND SERVICING 1. Pull handle (A) toward the operator’s seat and move the console fully forward to ease accessibility from the underside of the console. Figure 5.19: Seat Adjustment Handle 2. Set spring dimension (B) to 1-1/4 in. (32 mm). 3.
Page 336 MAINTENANCE AND SERVICING 1. Place ground speed lever (GSL) (A) in N-DETENT, shut down engine, and remove key. Figure 5.21: Operator Console 2. Check steering rod bolts (A) for looseness and ball joints (B) for any perceptible movement. Figure 5.22: Steering Rods Figure 5.23: Steering Rods (Pump End) 147649 Revision A...
Page 337: Checking Steering Chain Tension
Hold inside nut (B) and tighten jam nut (A) to 60–70 ft·lbf (81–95 N·m). Figure 5.25: Steering Link 5. See your MacDon Dealer to replaced any loose steering link ball joints or steering rod ball joints. 6. After replacing parts or making adjustments, perform checks for Neutral Interlock and steering lock.
Page 338: Park Brake
MAINTENANCE AND SERVICING 3. At the base of the steering column, check dimension (C) at spring. It should be 5/8 in. (16 mm). Adjust dimension as follows: a. Loosen nut (A) and turn nut (B) to achieve 5/8 in. (16 mm) dimension (C). b.
Page 339 MAINTENANCE AND SERVICING 2. Remove the ﬁve screws (A) securing the control panel (B) to the console. 3. Remove the control panel (B) and store in the tray. Figure 5.28: Header Control Panel 4. Remove the three rubber nuts (A) securing the switch support plate (B) to the console.
Page 340 MAINTENANCE AND SERVICING 6. Adjust switch (A) as follows: a. Loosen nuts (B) and rotate switch on support sufﬁciently so that GSL will contact switch lever (C) and push in the plunger (D). b. Tighten nuts (B). Figure 5.31: Interlock Switch 7.
Page 341: Heating, Ventilating, And Air Conditioning (Hvac) System
MAINTENANCE AND SERVICING 10. Reinstall control panel (B) with ﬁve screws (A). Figure 5.34: Header Control Panel 5.5.6 Heating, Ventilating, and Air Conditioning (HVAC) System Fresh Air Intake Filter The fresh air ﬁlter is located outside the right rear of the cab and should be serviced every 50 hours under normal conditions and more frequently in severe conditions.
Page 342 MAINTENANCE AND SERVICING 3. Remove ﬁlter (A) from tray (B). Figure 5.36: Fresh Air Filter Inspecting And Cleaning Fresh Air Filter Element 1. Tap the sides of the ﬁlter element gently to loosen dirt. Do NOT tap element against a hard surface. 2.
Page 343: Return Air Cleaner/Filter
MAINTENANCE AND SERVICING 3. Slide ﬁlter tray (B) into housing. 4. Close and latch housing door (A). Figure 5.38: Cab Fresh Air Filter Access Return Air Cleaner/Filter The return air cleaner/ﬁlter is located behind the operator’s seat on the cab wall and should be serviced every 100 hours.
Page 344 MAINTENANCE AND SERVICING 2. Separate the ﬁlter (B) from the cover (A). 3. Clean or replace the ﬁlter. If cleaning ﬁlter, refer to Cleaning Return Air Cleaner, page 328. 4. Assemble the cleaner (B) and cover (A), and position on cab wall over opening. Figure 5.40: Return Air Filter 5.
Page 345: Air Conditioning Condenser
MAINTENANCE AND SERVICING Air Conditioning Condenser The air conditioning condenser should be cleaned daily with compressed air. More frequent cleaning may be necessary in severe conditions. Cleaning the condenser can be done at the same time as the radiator, oil cooler, and charge air cooler. Refer to Maintaining Engine Cooling Box, page 358.
Page 346 MAINTENANCE AND SERVICING 1. Use a vacuum cleaner or compressed air to remove dirt from inside the unit. 2. Blow compressed air through the evaporator ﬁns from the blower side (A) ﬁrst as shown. Direct the air straight into the evaporator to prevent ﬁn damage. A nozzle extension makes this procedure easier.
Page 347: Air Conditioning (A/C) Compressor
These switches do not require regular servicing or maintenance. Contact your MacDon Dealer if you suspect a problem with the switches. • The low pressure switch is normally closed when there is sufﬁcient refrigerant in the system and the pressure is above 34 psi (234 kPa).
Page 348: Engine
Refer to for belt replacement procedure. Replacing Air Conditioner (A/C) Compressor Belt, page 367 See your MacDon Dealer for all other servicing procedures. 5.5.7 Engine CAUTION • NEVER operate engine in a closed building. Proper ventilation is required to avoid exhaust gas hazards.
Page 349: Turning The Engine Manually
MAINTENANCE AND SERVICING Turning the Engine Manually To manually turn the engine with the ﬂywheel, an access hole is provided on the left cab-forward side for a barring tool that is available from Cummins. DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 350 MAINTENANCE AND SERVICING IMPORTANT: Clean the area around the plastic cap to ensure nothing falls into gearbox oil reservoir. 5. Clean the area around the plastic cap on access hole (A). Remove the cap. 6. Insert the barring tool (B) into the ﬂywheel housing until it engages the ring gear.
Page 351: Engine Oil
MAINTENANCE AND SERVICING Engine Oil Checking Engine Oil Level Check engine oil level daily (evey 10 hours) and watch for any signs of leakage. DANGER To avoid bodily injury or death from unexpected startup of machine, always stop engine and remove key from ignition before leaving operator's seat for any reason.
Page 352 MAINTENANCE AND SERVICING Changing Engine Oil Refer to the following procedures: • Checking Engine Oil Level, page 335 • Draining Engine Oil, page 336 • Replacing Engine Oil Filter, page 336 • Adding Engine Oil, page 337 Draining Engine Oil DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 353: Air Intake System
MAINTENANCE AND SERVICING 2. Clean around the ﬁlter head (A). 3. Remove ﬁlter (B). 4. Clean gasket mating surface. 5. Apply a thin ﬁlm of clean oil to the gasket on the new ﬁlter. Refer to 8.2.4 Filter Part Numbers, page 467 recommended oil ﬁlter to use.
Page 354 MAINTENANCE AND SERVICING Engine intake air is drawn through a duct (A) from the cooling box that precleans the air and then through a dual element ﬁlter (B). cleaner canister equipped with aspirator (C) that removes dust continuously from the air cleaner housing.
Page 355 MAINTENANCE AND SERVICING Air Filter Restriction Indicator During engine operation, the indicator shows the vacuum in inches of H O and kPa. As dirt accumulates in the ﬁlter, the restriction increases. When the indicator gauge reaches the CHANGE FILTER mark (A), 25 inches of H O (6.20 kPa), a warning tone will sound and the cab display module (CDM) will indicate the ﬁlter requires servicing.
Page 356 MAINTENANCE AND SERVICING 4. Make sure arrow (A) lines up with UNLOCK symbol on end cap. 5. Pull off the end cap. Figure 5.62: Engine Air Cleaner 6. Check the aspirator duct opening (A) for obstructions or damage. Clean if necessary. Figure 5.63: Engine Air Cleaner 7.
Page 357 MAINTENANCE AND SERVICING Replace the secondary air ﬁlter (A) every year or after every third primary ﬁlter change (even if it appears clean). If the secondary air ﬁlter is dirty, inspect the primary ﬁlter and the ﬁlter canister to determine the reason for contamination.
Page 358 MAINTENANCE AND SERVICING Installing Primary Air Filter NOTE: If replacing air ﬁlter, refer to 8.2.4 Filter Part Numbers, page 467. 1. Insert new primary ﬁlter element (A) into canister over secondary element, and push into place, ensuring that element is ﬁrmly seated in canister. Figure 5.66: Engine Air Cleaner 2.
Page 359 MAINTENANCE AND SERVICING 6. After servicing the ﬁlter, reset the restriction switch (A) by pushing the button on the end. 7. Close the hood, refer to 5.2.2 Closing Hood (Lower Position), page 307. 8. Close the maintenance platform, refer to 5.3.1 Opening Platforms (Standard Position), page 309.
Page 360 MAINTENANCE AND SERVICING Removing and Installing Secondary Air Filter Replace the secondary air ﬁlter (A) every year or after every third primary ﬁlter change (even if it appears clean). If the secondary air ﬁlter is dirty, inspect the primary ﬁlter and the ﬁlter canister to determine the reason for contamination.
Page 361: Fuel System
MAINTENANCE AND SERVICING Fuel System Replacing Fuel Tank Vent Filter The fuel tank is vented by a hose that is connected to the ﬁller tube. The hose is connected to a ﬁlter that should be changed every year. Replace the ﬁlter as follows: DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 362 MAINTENANCE AND SERVICING Maintaining Fuel Filters The windrower fuel system is equipped with primary (A) and secondary (B) screw-on cartridge type ﬁlters. The primary ﬁlter (A) is equipped with a separator that separates sediment and water from the fuel. Refer to the following procedures: •...
Page 363 MAINTENANCE AND SERVICING 4. Locate the primary fuel ﬁlter (A) on the right cab-forward side of the windrower. NOTE: Bottom part of the image made transparent to show location of the primary ﬁlter. Figure 5.75: Fuel Filter Locations 5. Clean around the primary ﬁlter (A) head. 6.
Page 364 MAINTENANCE AND SERVICING 1. Screw the new ﬁlter (A) onto the ﬁlter mount until the gasket contacts the ﬁlter head. 2. Reconnect water in fuel (WIF) sensor (B). 3. Tighten the ﬁlter an additional 1/2 to 3/4 turn by hand. IMPORTANT: Do NOT use a ﬁlter wrench to install the ﬁlter.
Page 365 MAINTENANCE AND SERVICING 1. Screw the new secondary ﬁlter (A) onto the ﬁlter mount until the gasket contacts the ﬁlter head. 2. Tighten the ﬁlter an additional 1/2 to 3/4 turn by hand. IMPORTANT: Do NOT use a ﬁlter wrench to install the ﬁlter. Overtightening can damage the gasket and ﬁlter.
Page 366 MAINTENANCE AND SERVICING 3. Close fuel supply valve (A). Located on the bottom of the fuel tank. Figure 5.81: Bottom of Fuel Tank 4. Place a 5 US gallon (20 liter) drain pan under the fuel supply hose (A) at primary ﬁlter. 5.
Page 367 MAINTENANCE AND SERVICING 7. Add some clean fuel to tank to ﬂush out any remaining contaminants. 8. Reattach fuel supply hose (A) to ﬁtting. Install clamp (B) and tighten. NOTE: Do NOT reﬁll the fuel tank if performing additional maintenance on fuel system. Reﬁll it once work is completed.
Page 368 MAINTENANCE AND SERVICING System Priming Controlled venting of air is provided at the injection pump through the fuel drain manifold. Small amounts of air introduced by changing ﬁlters or injection pump supply line will be vented automatically, if the fuel ﬁlters are changed in accordance with instructions.
Page 369: Engine Cooling System
MAINTENANCE AND SERVICING Engine Cooling System The engine cooling system is designed to maintain the engine operating temperature within the speciﬁed operating range. NOTE: Antifreeze is essential in any climate. It broadens the operating temperature range by lowering the coolant freezing point, AND by raising its boiling point.
Page 370 MAINTENANCE AND SERVICING 3. Remove the radiator cap (A). IMPORTANT: Turn the cap (A) counterclockwise to the ﬁrst notch to relieve pressure before removing cap completely. 4. Check the coolant in the radiator using an antifreeze tester. Tester should indicate protection temperatures of -30°F (-34°C).
Page 371 MAINTENANCE AND SERVICING Draining Coolant DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. CAUTION To avoid personal injury from hot coolant, do NOT turn radiator cap until engine cools. 1.
Page 372 MAINTENANCE AND SERVICING 6. Close the heater shut-off valve (A) and disconnect hose on heater side of valve. 7. Open valve to drain the block. 8. When system is drained, reattach hose on valve (A). Figure 5.92: Heater Shut-Off Valve 9.
Page 373 MAINTENANCE AND SERVICING Adding Coolant Check the coolant level in the coolant recovery tank daily, the tank should be at least one-half full. If less, add coolant. CAUTION To avoid personal injury from hot coolant, do NOT turn radiator cap until engine cools. NOTE: Do NOT add coolant to radiator except when changing coolant.
Page 374 MAINTENANCE AND SERVICING Maintaining Engine Cooling Box Refer to the following procedures: • Opening Cooler Box Screen, page 358 • Charge Air Cooling, page 359 • Cleaning Screens and Coolers, page 359 • Cleaning Cooler Box Components, page 360 • Adjusting Screen Cleaner Rotor to Screen Clearance, page 362 •...
Page 375 MAINTENANCE AND SERVICING Charge Air Cooling Charge air is routed through a cooler that is located in the cooling box (C), prior to entering the engine intake. The cooler should be cleaned daily with compressed air. Refer Maintaining Engine Cooling Box, page 358 Figure 5.97: Engine Air Intake System Cleaning Screens and Coolers The cooling box screen is cleaned using two electrically driven rotors and suction from the engine’s cooling fan...
Page 376 MAINTENANCE AND SERVICING 6. Blow debris out of ducts (A) with compressed air. 7. Clean screen with compressed air. Figure 5.99: Engine Cooling System 8. Move the screen cleaner assembly (C) back into position and secure with bolts and nuts (B). 9.
Page 377 MAINTENANCE AND SERVICING 3. Slide out the oil cooler / air conditioning condenser assembly (A). Figure 5.102: Engine Cooling System 4. Lift latch (A) and open the left-hand access door (B). Figure 5.103: LH Cooler Access Door 5. Remove wing nut (A) and open access door (B) at top of cooling box.
Page 378 MAINTENANCE AND SERVICING 6. Clean radiator (D) through access holes in cooling box with compressed air. 7. Clean oil cooler / air conditioning condenser (A), charge air cooler (E), fuel cooler (B), and cooling box (C) with compressed air. 8. Inspect all lines and coolers for evidence of leaks and damage.
Page 379: Gearbox
MAINTENANCE AND SERVICING Closing Cooler Box Screen 1. Unhook the support rod and store it in the screen door. Close screen access door (B) and engage latch (A). 2. Close the hood. Refer to 5.2.4 Closing Hood (Highest Position), page 308.
Page 380: Exhaust System
MAINTENANCE AND SERVICING 2. Add lubricant as follows: a. Remove breather cap (A) and add lubricant until it runs out the check port. If reﬁlling, add approximately 2.2 US quarts (2.1 liters). b. Replace check plug and breather cap and tighten. c.
Page 381: Belts
MAINTENANCE AND SERVICING The exhaust system requires no regular maintenance, but it should be inspected periodically as follows: 1. Open the hood to its highest position. For instructions, refer to 5.2.3 Opening Hood (Highest Position), page 307. 2. Inspect the area around clamps (A) for breakage, cracks, and rust-through.
Page 382 MAINTENANCE AND SERVICING 4. Loosen compressor mounting hardware (B) and push compressor towards engine to release tension. 5. Remove belt (A) from compressor. Figure 5.112: A/C Compressor 6. Insert the drive end of a 1/2 in. drive ratchet wrench into the belt tensioner (B). 7.
Page 383 MAINTENANCE AND SERVICING Tensioning Air Conditioner (A/C) Compressor Belt DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. 1.
Page 384: Engine Speed
The throttle lever in the cab should move the throttle sensor the full range between slow speed stop and full rpm stop without contacting the console at either position. If the throttle lever is contacting the console and interferes with speciﬁed engine speeds, the sensor position may need adjustment. See your MacDon Dealer. 5.5.8 Electrical System Preventing Electrical System Damage...
Page 385: Battery
MAINTENANCE AND SERVICING Battery Maintaining the Battery CAUTION Do NOT attempt to service battery unless you have the proper equipment and experience to perform the job. Have it done by a qualiﬁed Dealer. • Check battery charge once a year, more often if operating in cold weather. Hydrometer readings should be 1.260 to 1.300.
Page 386 MAINTENANCE AND SERVICING Charging the Battery CAUTION • Ventilate area where batteries being charged. • Do NOT charge a frozen battery. Warm to 60°F (16°C) before charging. • Do NOT connect or disconnect live circuits. To prevent sparks, turn off charger and connect positive cable ﬁrst.
Page 387 MAINTENANCE AND SERVICING CAUTION Follow all instructions and precautions furnished by the battery charger manufacturer, including the following: • Charge at recommended rates and times. • Turn off charger prior to hook up to avoid dangerous sparks. Wear proper eye protection. •...
Page 388 MAINTENANCE AND SERVICING Boosting the Battery A 12 volt battery can be connected in parallel (+ to +) with the windrower battery. Use heavy-duty battery cables. CAUTION • Gas given off by batteries is explosive. Keep sparks and ﬂames away from batteries. •...
Page 389 MAINTENANCE AND SERVICING WARNING • If electrolyte is spilled or splashed on clothing or on the body, neutralize it immediately with a solution of baking soda and water, then rinse with clean water. • Electrolyte splashed into the eyes is extremely dangerous.
Page 390 MAINTENANCE AND SERVICING 3. The battery main disconnect switch (A) is located on the right cab-forward frame rail beside the batteries. Ensure battery switch (A) is switched to POWER OFF position. Figure 5.125: Battery Switch 4. Remove the bolt (A) that secures the platform arm to the platform.
Page 391 MAINTENANCE AND SERVICING 1. The battery main disconnect switch (A) is located on the right cab-forward frame rail beside the batteries. Ensure battery switch (A) is switched to POWER OFF position. 2. Open the right cab-forward platform to expose the batteries.
Page 392: Headlights: Engine-Forward
MAINTENANCE AND SERVICING 1. Stop engine and remove key from ignition. 2. Open the right-hand (cab-forward) maintenance platform. Refer to 5.3.1 Opening Platforms (Standard Position), page 309. 3. Ensure the battery switch (A) is turned to the POWER OFF position (the battery switch is located on the right-hand frame rail beside the batteries).
Page 393 MAINTENANCE AND SERVICING 1. Position windrower on level ground in front of a vertical surface in accordance with the illustration. 2. Shut down engine and remove key. Figure 5.131: Headlight Beam Positioning A - 49.75 in. (1263 mm) Maximum B - 25 ft (7.5 m) C - Top Edge of Beam D - Beam Centered on Direction E - Ground...
Page 394 MAINTENANCE AND SERVICING • Upper limit of the beam NOT higher than 49-3/4 in. (1263 mm) above ground at a distance of 25 ft. (7.5 m) from the headlight. Figure 5.134: Headlight Beam Positioning A - 49.75 in. (1263 mm) Maximum B - 25 ft (7.5 m) C - Top Edge of Beam D - Beam Centered on Direction E - Ground...
Page 395 MAINTENANCE AND SERVICING 3. Pinch the wire retainer (A) and lift away from hooks. 4. Remove bulb (B) from body. IMPORTANT: Do NOT touch the glass of the halogen bulb as the oils or other chemicals from your skin will cause the bulb to fail prematurely.
Page 396: Field Lights: Cab-Forward
MAINTENANCE AND SERVICING 7. Replace rubber insulator boot (A). 8. Push connector onto light bulb. Figure 5.139: Headlight Assembly 9. Position headlight into light receptacle, ensuring top is up, and secure with screws (A). NOTE: Aligning of light should not be necessary. Figure 5.140: Headlight Assembly Field Lights: Cab-Forward Adjusting Field Lights...
Page 397: Flood Lights: Forward
MAINTENANCE AND SERVICING 2. Adjust lights with screws (A). Figure 5.142: Field Lights Replacing Field Light Bulb 1. Remove two screws (A), and remove light assembly. 2. Replace bulb as described in Replacing Field Light Bulb, page 381. Figure 5.143: Field Lights Flood Lights: Forward Adjusting Forward Flood Lights The forward ﬂood lights are NOT adjustable.
Page 398 MAINTENANCE AND SERVICING 2. Hold onto the handholds (A) on the cab front corners and stand on the header anti-slip strips when removing the forward ﬁeld lights. 3. Remove two screws (B) and remove light bezel (C). 4. Remove light from receptacle. Figure 5.144: Forward Flood Lights 5.
Page 399: High-Intensity Discharge (Hid) Auxiliary Lighting (Optional - Md #B5596)
MAINTENANCE AND SERVICING 7. Match slots on new bulb (B) with lugs (D) in optical unit and insert bulb into unit. 8. Secure bulb with wire retainer (A). 9. Push wire into connector (C). Figure 5.146: Flood Light Assembly 10. Position light into light receptacle, ensuring top is up and secure with bezel (C) and screws (B).
Page 400 MAINTENANCE AND SERVICING 1. Shut down engine and remove key. Turn lights ON. 2. Loosen bolt (A) and nut (B) (located inside light / mirror support). 3. Position light to desired position. 4. Tighten bolt (A) and nut (B). Figure 5.148: HID Auxiliary Lights Replacing High-Intensity Discharge (HID) Lamp (if Installed) DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove...
Page 401 MAINTENANCE AND SERVICING To remove and replace the HID lamp assembly, follow these steps: 1. Disconnect lamp connector (A) from electrical harness (B). Figure 5.151: HID Auxiliary Light Harness 2. Remove grommet (A) from light support (B). 3. Remove nut (C) and spring washer from inside light support (B).
Page 402: Flood Lights: Rear
MAINTENANCE AND SERVICING 9. Connect lamp plug (A) to main harness connector (B). Figure 5.154: HID Auxiliary Light Harness Flood Lights: Rear Adjusting Rear Flood Lights The rear ﬂood lights are best adjusted with the machine in the ﬁeld (or equivalent) to suit Operator preference. DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 403 MAINTENANCE AND SERVICING 1. Shut down engine and remove key. Turn lights OFF. 2. Remove two screws (A) and remove light bezel (B). 3. Remove light from receptacle. Figure 5.156: Rear Flood Light Assembly IMPORTANT: Do NOT touch the glass of the halogen bulb as the oils or other chemicals from your skin will cause the bulb to fail prematurely.
Page 404: Replacing Bulbs In Red And Amber Lights
MAINTENANCE AND SERVICING Replacing Bulbs in Red and Amber Lights To replace bulbs in red and amber lights, follow these steps: DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 405: Replacing The Bulbs In Beacon Lights (If Installed)
MAINTENANCE AND SERVICING 2. In the grill of the hood, remove two screws (A) from light (B), and remove light. 3. Remove connector from light. 4. Connect wiring harness to new light (B) and install light with screws (A). Figure 5.161: Red Tail Lights Replacing the Bulbs in Beacon Lights (if installed) Beacon warning lights are available as an optional Dealer-installed attachment (MD #B5582).
Page 406 MAINTENANCE AND SERVICING 2. Turn lens (A) counterclockwise to unlock lens from base and remove lens. Figure 5.163: Warning Beacons 3. Pinch retainer (A) and remove it from lamp socket. 4. Pull lamp out of socket. Figure 5.164: Beacon Lamp Assembly 147649 Revision A...
Page 407 MAINTENANCE AND SERVICING 5. Disconnect harness from lamp. IMPORTANT: Do NOT touch the glass of the halogen bulb as the oils or other chemicals from your skin will cause the bulb to fail prematurely. Figure 5.165: Beacon Lamp Assembly 6. Connect harness to new lamp, place lamp in socket, and line up the ﬂat side on lamp with recess in socket.
Page 408 MAINTENANCE AND SERVICING 7. Place retainer (A) over lamp and pinch tabs to secure retainer to socket. Figure 5.167: Beacon Lamp Assembly 8. Line up the three lugs (one is longer) in the base with slots in lens, and seat the lens against the rubber seal. Figure 5.168: Beacon Lamp Assembly 147649 Revision A...
Page 409 MAINTENANCE AND SERVICING 9. Turn the lens clockwise to lock it in place. Figure 5.169: Warning Beacons 147649 Revision A...
Page 410: Replacing A Console Gauge Light
MAINTENANCE AND SERVICING Replacing a Console Gauge Light To replace a light inside one of the console gauges, follow these steps: 1. Shut down engine and remove key. Turn lights OFF. 2. Remove the appropriate gauge access hole decal (A) behind the operator’s console.
Page 411: Replacing The Cabin Dome Light
MAINTENANCE AND SERVICING Replacing the Cabin Dome Light To replace a cabin dome light, follow these steps: 1. Shut down engine. 2. Remove two screws (A) from the dome light assembly and remove the assembly. 3. Disconnect the old dome light assembly from the wiring harness.
Page 412: Turn Signal Indicators
MAINTENANCE AND SERVICING Turn Signal Indicators If the turn signal indicators on the cab display module (CDM) do not function, contact your MacDon Dealer. Accessing Circuit Breakers and Fuses The circuit breakers and fuses are located inside a fuse box mounted on the right (cab-forward) side of the frame under the platform.
Page 413 MAINTENANCE AND SERVICING Replacing Circuit Breakers and Relays DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. Replace breakers and relays as follows: 1.
Page 414 MAINTENANCE AND SERVICING Fuse Box Decal Figure 5.178: Fuse Decal 147649 Revision A...
Page 415 MAINTENANCE AND SERVICING Inspecting and Replacing 125A Main Fuses The 125A main fuse holders are located on the frame under the right cab-forward side platform beside the battery. Access the 125A main fuses as follows: DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 416: Hydraulic System
Ensure lock engages. Figure 5.181: 125A Main Fuses 5.5.9 Hydraulic System The M155 windrower hydraulic system provides oil pressure for the windrower drive system, the header lift, and header drive systems. WARNING • Avoid high pressure ﬂuids. Escaping ﬂuid can penetrate the skin causing serious injury.
Page 417: Checking And Filling Hydraulic Oil
NOT attempt to service these components except to maintain proper oil level, change oil and ﬁlters, and to adjust relief pressures as described in this manual. See your MacDon Dealer for all other service. Checking and Filling Hydraulic Oil DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason.
Page 418 5. Clean cap (A) and surrounding area. 6. Turn ﬁller cap (A) counterclockwise to unlock cap and remove dipstick. Figure 5.185: M155/M205 Engine Hood 7. If necessary, add oil to maintain a level between the low (L) and full (H) marks. Refer to 8.2.3 Lubricants,...
Page 419: Hydraulic Oil Cooler
MAINTENANCE AND SERVICING Hydraulic Oil Cooler The hydraulic oil cooler is located inside the cooling box behind the radiator. It should be cleaned daily with compressed air. Refer to Cleaning Cooler Box Components, page 360. Draining Hydraulic Oil To drain hydraulic oil, follow these steps: Hydraulic oil should be changed every 1500 hours or every 2 years.
Page 420: Changing Hydraulic Oil Filters
MAINTENANCE AND SERVICING Changing Hydraulic Oil Filters The charge ﬁlter (A) and return ﬁlter (B) are located just inside the frame on the left side and are accessible from under the windrower. Change as follows: NOTE: Change hydraulic oil ﬁlters after the ﬁrst 50 hours of operation, and every 500 hours thereafter.
Page 421 MAINTENANCE AND SERVICING Installing Charge Filter NOTE: For charge ﬁlter replacement part number, refer to 8.2.4 Filter Part Numbers, page 467. 1. Clean the gasket surface of the ﬁlter head. 2. Apply a thin ﬁlm of clean oil to the ﬁlter gasket. 3.
Page 422 MAINTENANCE AND SERVICING NOTE: Image showing ﬁlter head removed to show component clarity. 6. Remove gasket (C) from groove (B) in ﬁlter head (A). Filter (D) shown for context. Figure 5.192: Return Filter Installing Return Filter NOTE: For ﬁlter speciﬁcations, refer to 8.2.4 Filter Part Numbers, page 467.
Page 423: Header And Reel Hydraulics
4000 (27,579) If lift and drive capacity problems develop, the pressure compensator valve may require adjusting. Contact your MacDon Dealer or refer to the technical service manual for your windrower. Flow Control Blocks Two hydraulic valve blocks with multiple cartridges are...
Page 424 MAINTENANCE AND SERVICING Adjusting Header Drop Rate The header should lower gradually when the lower header switch is pressed. From fully raised to ground should take approximately 3–4 seconds. NOTE: Drop rate should NOT be less than 3 to 4 seconds as structural damage may result. NOTE: If drop rate is too slow (over 30 seconds), return to cut height or tilt or ﬂoat presets will deactivate to prevent overheating the hydraulic system.
Page 425: Traction Drive Hydraulics
2. Check the hoses and lines for leakage. 3. Check the charge pressure relief valve. Refer to Checking Charge Pump Pressure, page 410. 4. If charge pressure still cannot be maintained, do NOT operate the windrower. Contact your MacDon Dealer. 147649 Revision A...
Page 426 100°F (40°C) minimum. 5. Note reading and shut down windrower. 6. If pressure is NOT within this range, contact your MacDon Dealer. 7. Otherwise, remove hose from test port and close the hood. Refer to 5.2.4 Closing Hood (Highest Position), page 308.
Page 427: Hoses And Lines
MAINTENANCE AND SERVICING Hoses and Lines Check hydraulic hoses and lines daily for signs of leaks. WARNING • Avoid high-pressure ﬂuids. Escaping ﬂuid can penetrate the skin causing serious injury. • Relieve pressure before disconnecting hydraulic lines. Tighten all connections before applying pressure.
Page 428 MAINTENANCE AND SERVICING DANGER • NEVER use force on an inﬂated or partially inﬂated tire. Make sure the tire is correctly seated before inﬂating to operating pressure. • Do NOT remove, install, or make repairs to a tire on a rim unless you have the proper equipment and experience to perform the job.
Page 429 MAINTENANCE AND SERVICING 1. Tighten drive wheel nuts (A). Ensure nuts and studs ® are dry with no lubricant or Never-Seez compound. Torque each to 375 lbf ft (510 N·m) using the tightening sequence shown at right. 2. Repeat tightening sequence two additional times at speciﬁed torque.
Page 430 MAINTENANCE AND SERVICING Adding Wheel Drive Lubricant NOTE: Do NOT mix lubricants of different brands or characteristics. DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. 1.
Page 431 MAINTENANCE AND SERVICING 1. Park windrower on level ground and position windrower so drain plug (B) is at the lowest point. 2. Shut down windrower remove from ignition. 3. Place a large enough container (about 2 quarts [2 liters]) under the lower drain plug (B). 4.
Page 432 MAINTENANCE AND SERVICING DANGER To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key from the ignition before leaving the operator’s seat for any reason. 3. Place ground speed lever (GSL) in N-DETENT (A), shut down engine, and remove key.
Page 433 MAINTENANCE AND SERVICING Installing Drive Wheel NOTE: Windrower must be supported off the ground with stands. Refer to Raising Drive Wheel, page 415. 1. Position drive wheel (A) against the wheel drive hub (B) so the air valve (C) is on the outside and the tire tread (D) points forward with the windrower in cab-forward orientation.
Page 434: Caster Wheel
MAINTENANCE AND SERVICING 1. Place a jack under the leg jack point (A) and raise the drive wheel slightly off the jack stand. 2. Remove the jack stand from under the cylinder lift mount (B) and lower the drive wheel to the ground. 3.
Page 435 MAINTENANCE AND SERVICING Check tire pressure every year. Caster tire pressure should be 10 psi (69 kPa). To maintain pressure, visually check daily that tires have not lost pressure, and adjust pressure as needed. Under-inﬂation of tires can cause sidewall cracks. NOTE: If caster wheels shimmy, a possible cause is over-inﬂation.
Page 436 MAINTENANCE AND SERVICING Figure 5.214: Formed Caster Wheel Tightening Sequence Servicing Caster Wheels Refer to the following procedures: • Raising Caster Wheel (Formed and Forked), page 420 • Lowering Caster Wheel (Formed and Forked), page 421 • Removing Forked Caster Wheel, page 422 •...
Page 437 MAINTENANCE AND SERVICING 1. Park windrower on level ground and block the drive wheels. 2. Place the ground speed lever (GSL) in N-DETENT (A), stop the engine and remove the key. Figure 5.215: GSL Position 3. Raise the end of walking beam (A) until the caster wheel assembly (B) is slightly off the ground.
Page 438 MAINTENANCE AND SERVICING Removing Forked Caster Wheel CAUTION Wheel assemblies are heavy. Support wheel assembly before removing axle bolts. 1. Raise caster wheel, refer to Raising Caster Wheel (Formed and Forked), page 420. 2. Remove the eight bolts (A) (four on each side of caster) attaching axle (B) and cover (C) to forked caster (E), and remove wheel assembly (D) from caster (E).
Page 439 MAINTENANCE AND SERVICING 3. Position wheel assembly (D) in forked caster (E). 4. Position cover plates (C) and install eight bolts (A) (four on each side of caster) to secure axle (B) to caster (E). Torque bolts to 75–79 ft·lbf (97–107 N·m). 5.
Page 440 MAINTENANCE AND SERVICING Tightening Caster Wheel Anti-Shimmy Dampeners Each caster is equipped with a ﬂuid-ﬁlled anti-shimmy dampener (A). The mounting bolts (B) need to be checked periodically for security. Refer to 5.5.11 Maintenance Schedule, page 425. • Inboard bolt should be tightened to 100 ft·lbf (135 N·m) •...
Page 441: Maintenance Schedule
MAINTENANCE AND SERVICING Ballast Requirements Fluid ballasting of rear caster tires is recommended to provide adequate machine stability when using large headers on the windrower. Also, the stability of the machine varies with different attachments, windrower options, terrain, and the operator’s driving technique. Ballast capability per tire is at a maximum ﬁll of 75%, or when ﬂuid is level with valve stem when the stem is positioned at 12 o’clock.
Page 442: Break-In Inspections
MAINTENANCE AND SERVICING IMPORTANT: Recommended intervals are for average conditions. Service the machine more often if operated under adverse conditions (severe dust, extra heavy loads, etc.). CAUTION Carefully follow safety messages given in 1 Safety, page Break-In Inspections Break-in Inspections Hours Item Check...
Page 443: Maintenance Schedule/Record
MAINTENANCE AND SERVICING Maintenance Schedule/Record WINDROWER SERIAL NUMBER: ___________________ Combine this record with the record in the header operator’s manual. Make copies of this page to continue the record. Refer to for details on each maintenance procedure. 5 Maintenance and Servicing, page 305 Maintenance ...
Page 444 MAINTENANCE AND SERVICING Maintenance  - Lubricate  - Change  - Clean  - Check  - Add Action: Record Forked Caster Spindle  Bearings  Gearbox Oil Level  Top Lift Link Pivots 100 HOURS OR ANNUALLY  Cab Air Return Filter 250 HOURS OR ANNUALLY ...
Page 445: Troubleshooting
6 Troubleshooting 6.1 Engine Troubleshooting Problem Symptom Solution Section Move GSL to NEUTRAL. Starting the Move steering wheel to locked Engine, page 160 Controls not in NEUTRAL position. 4.4.4 Header Disengage header drive switch. Drive, page 202 NEUTRAL Interlock Contact Dealer. Contact Dealer misadjusted Filling the Fuel...
Page 446 TROUBLESHOOTING Symptom Problem Solution Section Engine out of time Contact Dealer. Contact Dealer Adding Engine Oil, Insufﬁcient oil Add oil. page 337 Low or high coolant Engine knocks Contact Dealer. Contact Dealer temperature 8.2.2 Fuel Improper fuel Use proper fuel. Speciﬁcations, page 465 Adding Engine Oil,...
Page 447 TROUBLESHOOTING Symptom Problem Solution Section Incorrect timing Contact Dealer. Contact Dealer 8.2.3 Lubricants, Fluids, and System Engine oil viscosity too high Use recommended oil. Capacities, page Air Intake System, Intake air restriction Service air cleaner. page 337 Replace primary fuel ﬁlter, and Maintaining Fuel Clogged fuel ﬁlter if necessary, replace secondary...
Page 448 TROUBLESHOOTING Symptom Problem Solution Section Fill reserve tank to proper level. Low coolant level Engine Cooling Check system for leaks. System, page 353 Water only for coolant Replace with antifreeze. Driving Forward Engine overloaded Reduce ground speed. in Cab-Forward Mode, page 168 Inspecting Defective radiator cap Replace cap.
Page 449 TROUBLESHOOTING Symptom Problem Solution Section 8.2.2 Fuel Consult your fuel supplier, and use Improper type of fuel Speciﬁcations, proper type fuel for conditions. page 465 Driving Forward Reduce ground speed. Engine overloaded in Cab-Forward Mode, page 168 Engine emits black Air Intake System, Clogged or dirty air cleaner Service air cleaner.
Page 450 TROUBLESHOOTING Symptom Problem Solution Section Low battery output Check battery charge. Maintaining the Loose or corroded battery Battery, page 369 Clean and tighten loose connections. connections Driving Forward Move GSL to NEUTRAL. in Cab-Forward Mode, page 168 Driving Reverse Move steering wheel to CENTER Controls not in NEUTRAL in Cab-Forward position.
Page 451: Electrical Troubleshooting
TROUBLESHOOTING 6.2 Electrical Troubleshooting Symptom Problem Solution Section Defective battery Have battery tested. Battery, page 369 Loose or corroded Maintaining the Clean and tighten battery connections. connections Battery, page 369 Replacing Fan Belt, page 365 Low voltage and/or Defective alternator belt Replace worn belt.
Page 452: Hydraulics Troubleshooting
TROUBLESHOOTING 6.3 Hydraulics Troubleshooting Symptom Problem Solution Section Appropriate solenoids not being Contact Dealer. Contact Dealer energized by activating switch Header or reel not lifting Clean relief valve at cylinder Contaminant in relief valve control valve. Contact Dealer Header or reel lifts Relief pressure too low or Check/adjust/clean relief valve at contaminant in relief valve...
Page 453: Header Drive Troubleshooting
TROUBLESHOOTING 6.4 Header Drive Troubleshooting Symptom Problem Solution Section Engaging and Header DRIVE switch in cab Engage HEADER DRIVE switch. Disengaging the not engaged Header, page 202 Header drive not Operator Presence switch not Occupy operator’s seat or replace engaging closed or faulty switch.
Page 454: Traction Drive Troubleshooting
TROUBLESHOOTING 6.5 Traction Drive Troubleshooting Symptom Problem Solution Section Checking and Stop engine, and add oil to hydraulic Low hydraulic oil level Filling Hydraulic system. Oil, page 401 Warning alarm Low hydraulic pressure sounds and transmission oil Foreign material shorting light is on sender Short in alarm wiring...
Page 455 TROUBLESHOOTING Symptom Problem Solution Section Pump arms have broken shaft Repair or tighten. or loose hardware Contact Dealer Brakes binding or not Check pressure on brake release releasing fully valve (min. 200 psi [1379 kPa]). Checking and Low oil level Check oil reservoir level.
Page 456 TROUBLESHOOTING Symptom Problem Solution Section Broken pump arm or shaft Contact Dealer. Contact Dealer Final Drives, page One ﬁnal drive disengaged Engage ﬁnal drive. 5.5.3 Ground Speed Lever (GSL) Check GSL and steering for loose, Steering controls worn or Adjustments, worn or damaged ball joints and defective page 317...
Page 457: Steering And Ground Speed Control Troubleshooting
TROUBLESHOOTING 6.6 Steering and Ground Speed Control Troubleshooting Problem Symptom Solution Section 5.5.4 Steering Machine will not Adjust steering chain tension. Linkage worn or loose Adjustments, page steer straight Replace worn parts. Adjust linkage. Neutral interlock misadjusted Machine moves Parking brake not functioning on ﬂat ground with GSL servo misadjusted controls in neutral...
Page 458: Cab Air Troubleshooting
TROUBLESHOOTING 6.7 Cab Air Troubleshooting Problem Symptom Solution Section Burned out motor Burned out switch Motor shaft tight or bearings Blower fan will not worn Contact Dealer. Contact Dealer Faulty wiring—loose or broken Blower rotors in contact with housing Cleaning Engine Dirty fresh air ﬁlter Clean fresh air ﬁlter.
Page 459 TROUBLESHOOTING Symptom Problem Solution Section Low refrigerant level Add refrigerant. Contact Dealer. Clutch coil burned out or disconnected Contact Dealer. Blower motor disconnected or burned out Contact Dealer Switch contacts in thermostat burned excessively, or sensing Replace thermostat. element defective Compressor partially or Remove compressor for service or completely seized...
Page 460 TROUBLESHOOTING Symptom Problem Solution Section Remove clutch assembly for service Compressor clutch slipping or replacement. Contact Dealer Thermostat defective or Replace thermostat. improperly adjusted Cleaning Engine Air Filter Primary Remove air ﬁlters, and clean or Element, page Clogged air ﬁlters replace as necessary.
Page 461 TROUBLESHOOTING Defective winding or improper connection in compressor clutch coil or relay Contact Dealer. Contact Dealer Excessive charge in system Low charge in system Excessive moisture in system Tensioning Air Conditioner (A/C) Compressor Belt, Loose or excessively worn page 367 Tighten or replace as required.
Page 462: Operator's Station Troubleshooting
TROUBLESHOOTING 6.8 Operator’s Station Troubleshooting Problem Symptom Solution Section 3.3 Operator’s Seat suspension not adjusted for Rough ride Adjust seat suspension. Seat Adjustments, operator’s weight page 42 Inﬂating Drive Wheel Tire, page Rough ride High air pressure in tires Deﬂate to proper pressure. Inﬂating Caster Tire, page Rough ride...
Page 463: Options And Attachments
7.1.5 Draper Header Case Drain Kit The Draper Header Case Drain kit must be installed when attaching a MacDon D50, D60, or D65 draper header with an upper cross auger (UCA), but without double draper drive. Case Drain Kit (MD #B5842) is NOT required for double draper drive headers equipped with kits (MD #B5606) and (MD #B5653).
Page 464: Double Windrow Attachment (Dwa)
OPTIONS AND ATTACHMENTS 7.1.6 Double Windrow Attachment (DWA) Allows auger and rotary headers when installed on a windrower to lay a double windrow. The kit includes a draper deck, linkage assembly, hydraulics, and installation instructions. MD #C1987 consists of: • MD #B4655 Deck •...
Page 465: Hid Auxiliary Lighting
OPTIONS AND ATTACHMENTS 7.1.11 HID Auxiliary Lighting Provides additional ﬁeld lighting. The kit includes two cab-mounted high intensity discharge (HID) lamps and installation instructions. MD #B5596 Instruction MD #169621 is included in the bundle. 7.1.12 Hydraulic Center-Link Allows remote adjustment of the header angle using a hydraulic cylinder between the header and the windrower. MD #B4650 (hydraulic center-link) Instruction MD #169236 is included in the bundle.
Page 466: Rotary Header Drive Hydraulics (13-Foot)
MD #B5510 Instructions are included in the bundle. • MD #169544 13-foot R80 and R85 attached to M150 or M155 MD #B5511 Instructions are included in the bundle. • MD #169545 13-foot R80 and R85 attached to M200 7.1.18 Self-Aligning Center-Link...
Page 467: Weight Box
OPTIONS AND ATTACHMENTS 7.1.22 Weight Box To move the windrower without an attached header, attach the weight box to the header lift system. The weight box allows transporting a header behind the windrower by providing additional weight on the drive wheels. MD #B5238 -Weight box without harness MD #B5240 - Weight box without harness and concrete.
Page 469: Reference
8 Reference 8.1 Recommended Torques 8.1.1 Torque Speciﬁcations The following tables provide the correct torque values for various bolts, cap screws, and hydraulic ﬁttings. • Tighten all bolts to the torque values speciﬁed in the charts (unless otherwise noted throughout this manual). •...
Page 470 REFERENCE Table 8.2 SAE Grade 5 Bolt and Grade F Distorted Thread Nut Torque (ft·lbf) Torque (N·m) Nominal (*in·lbf) Size (A) Min. Max. Min. Max. 1/4-20 5/16-18 *149 *164 16.7 18.5 3/8-16 7/16-14 1/2-13 9/16-12 Figure 8.2: Bolt Grades 5/8-11 A - Nominal Size B - SAE-8 C - SAE-5...
Page 471: Metric Bolt Speciﬁcations
REFERENCE Table 8.4 SAE Grade 8 Bolt and Grade 8 Free Spinning Nut Torque (ft·lbf) Torque (N·m) Nominal (*in·lbf) Size (A) Min. Max. Min. Max. 1/4-20 *150 *165 16.8 18.6 5/16-18 3/8-16 7/16-14 1/2-13 9/16-12 Figure 8.4: Bolt Grades 5/8-11 A - Nominal Size B - SAE-8 C - SAE-5...
Page 472 REFERENCE Table 8.6 Metric Class 8.8 Bolts and Class 9 Distorted Thread Nut Torque (ft·lbf) Torque (N·m) Nominal (*in·lbf) Size (A) Min. Max. Min. Max. 3-0.5 3.5-0.6 4-0.7 5-0.8 6-1.0 8-1.25 *167 *185 18.8 20.8 Figure 8.6: Bolt Grades 10-1.5 12-1.75 14-2.0 16-2.0...
Page 473 REFERENCE Table 8.8 Metric Class 10.9 Bolts and Class 10 Distorted Thread Nut Torque (ft·lbf) Torque (N·m) Nominal (*in·lbf) Size (A) Min. Max. Min. Max. 3-0.5 3.5-0.6 4-0.7 5-0.8 6-1.0 10.7 11.8 *105 8-1.25 Figure 8.8: Bolt Grades 10-1.5 12-1.75 14-2.0 16-2.0 20-2.5...
Page 474: Metric Bolt Speciﬁcations Bolting Into Cast Aluminum
REFERENCE Metric Bolt Speciﬁcations Bolting into Cast Aluminum Table 8.9 Metric Bolt Bolting into Cast Aluminum Bolt Torque Nominal 10.9 Size (A) (Cast Aluminum) (Cast Aluminum) ft·lbf N·m ft·lbf N·m – – – – – – – Figure 8.9: Bolt Grades –...
Page 475 REFERENCE Table 8.10 Flare-Type Hydraulic Tube Fittings Torque Value Flats from Finger Tight (FFFT) SAE Dash Size Thread Size (in.) Swivel Nut or ft·lbf N·m Tube Hose — — 5/16–24 3–4 4–5 5–6 7–8 — — 3/8–24 7/16–20 13–14 18–19 2-1/2 1/2–20 14–15...
Page 476: O-Ring Boss (Orb) Hydraulic Fittings (Adjustable)
REFERENCE O-Ring Boss (ORB) Hydraulic Fittings (Adjustable) 1. Inspect O-ring (A) and seat (B) for dirt or obvious defects. 2. Back off the lock nut (C) as far as possible. Ensure that washer (D) is loose and is pushed toward the lock nut (C) as far as possible.
Page 477 REFERENCE Table 8.11 O-Ring Boss (ORB) Hydraulic Fittings (Adjustable) Torque Value SAE Dash Size Thread Size (in.) ft·lbf (*in·lbf) N·m 5/16–24 *53–62 6–7 3/8–24 *106–115 12–13 7/16–20 14–15 19–21 1/2–20 15–24 21–33 9/16–18 19–21 26–29 3/4–16 34–37 46–50 7/8–14 55–60 75–82 1-1/16–12 88–97...
Page 478: O-Ring Boss (Orb) Hydraulic Fittings (Non-Adjustable)
REFERENCE O-Ring Boss (ORB) Hydraulic Fittings (Non-Adjustable) 1. Inspect O-ring (A) and seat (B) for dirt or obvious defects. 2. Check that O-ring (A) is NOT on the threads and adjust if necessary. 3. Apply hydraulic system oil to the O-ring. 4.
Page 479: O-Ring Face Seal (Orfs) Hydraulic Fittings
REFERENCE O-Ring Face Seal (ORFS) Hydraulic Fittings 1. Check components to ensure that the sealing surfaces and ﬁtting threads are free of burrs, nicks, scratches, or any foreign material. Figure 8.14: Hydraulic Fitting 2. Apply hydraulic system oil to the O-ring (B). 3.
Page 480 REFERENCE Table 8.13 O-Ring Face Seal (ORFS) Hydraulic Fittings Torque Value SAE Dash Size Thread Size (in.) Tube O.D. (in.) ft·lbf N·m – – Note 3/16 9/16 18–21 25–28 Note 5/16 – – 11/16 29–32 40–44 13/16 41–45 55–61 59–65 80–88 1-3/16 85–94...
Page 481: Recommended Fuel, Fluids, And Lubricants
REFERENCE 8.2 Recommended Fuel, Fluids, and Lubricants 8.2.1 Storing Lubricants and Fluids Your machine can only operate at top efﬁciency if clean fuel and lubricants are used. • Buy good quality, clean fuel from a reputable dealer. • Use clean containers to handle fuel and lubricants. •...
Page 482: Lubricants, Fluids, And System Capacities
REFERENCE 8.2.3 Lubricants, Fluids, and System Capacities CAUTION To avoid injury or death, do not allow ANY machine ﬂuids to enter the body. Table 8.15 System Capacities Lubricant/Fluid Location Description Capacity SAE multi-purpose.high temperature As required unless extreme pressure (EP2) performance Grease otherwise speciﬁed with 1% max Molybdenum Disulphide...
Page 483: Filter Part Numbers
IMPORTANT: Do NOT use cooling system sealing additives or antifreeze that contains sealing additives. 8.2.4 Filter Part Numbers Table 8.16 M155 Filter Part Numbers Filter Part Number Engine oil ﬁlter MD #111974 Charge oil ﬁlter...
Page 484: Conversion Chart
REFERENCE 8.3 Conversion Chart Table 8.17 Conversion Chart Inch-Pound Units SI Units (Metric) Factor Quantity Unit Name Abbreviation Unit Name Abbreviation Area Acres acres x 0.4047 = Hectares US gallons Flow x 3.7854 = Liters per minute L/min per minute Force Pounds force x 4.4482 =...
Page 485: Engine Error Codes
REFERENCE 8.4 Engine Error Codes Example: cab display module (CDM) displays the Error Code 629S 16F 28C 1. 629S - S represents the J1939 SPN column. Locate code 629 in that column. 2. 12F - F represents the FMI column. Locate code 12 in that column. 3.
Page 486 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Amber Engine Coolant Coolant Temperature Sensor Circuit – Voltage Temperature Above Normal, or Shorted to High Source Amber Engine Coolant Coolant Temperature Sensor Circuit – Voltage Temperature Below Normal, or Shorted to Low Source Coolant Temperature High - Data Valid but Above Engine Coolant Amber...
Page 487 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Amber Barometric Barometric Pressure Sensor Circuit – Voltage Pressure Above Normal, or Shorted to High Source Amber Barometric Barometric Pressure Sensor Circuit – Voltage Pressure Below Normal, or Shorted to Low Source 3510 Amber 5 Volts DC Supply...
Page 488 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Amber Fuel Delivery Fuel Pressure Sensor Circuit - Data Erratic, Pressure Intermittent, or Incorrect Fuel Pump High Fuel Pressure Solenoid Valve Circuit – 1347 Amber Pressurizing Voltage Below Normal, or Shorted to Low Source Assembly #1 Fuel Pump High Fuel Pressure Solenoid Valve Circuit –...
Page 489 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Amber Injector Cylinder Injector Solenoid Cylinder #5 Circuit – Current Below Normal, or Open Circuit Amber Injector Cylinder Injector Solenoid Cylinder #3 Circuit – Current Below Normal, or Open Circuit Amber Injector Cylinder Injector Solenoid Cylinder #6 Circuit –...
Page 490 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Amber Water in Fuel Water in Fuel Sensor Circuit - Voltage Above Indicator Normal, or Shorted to High Source Water in Fuel Water in Fuel Sensor Circuit - Voltage Below Amber Indicator Normal, or Shorted to Low Source...
Page 491 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Accelerator Pedal Accelerator Pedal or Lever Idle Validation Circuit - Amber Low Idle Switch Voltage Below Normal, or Shorted to Low Source Injector Metering Rail #1 Pressure High – Data Injector Metering Amber Valid but Above Normal Operational Range -...
Page 492 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description Sensor Circuit - ECM Internal Temperature Sensor Circuit - 1136 Amber Voltage Voltage Above Normal, or Shorted to High Source Sensor Circuit - ECM Internal Temperature Sensor Circuit - 1136 Amber Voltage...
Page 493 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description 1242 Accelerator Pedal Accelerator Pedal or Lever Position Sensor 1 and Position 2 - Data Erratic, Intermittent, or Incorrect 1256 1563 Amber Control Module Control Module Identiﬁcation Input State Error - Identiﬁcation Input Data Erratic, Intermittent, or Incorrect State...
Page 494 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description 2216 Fuel Pump Delivery Pressure - Data Valid but Fuel Delivery Amber Above Normal Operational Range – Moderately Pressure Severe Level 2217 Amber Calibration Memory ECM Program Memory (RAM) Corruption - Condition Exists 2249 Injector Metering Rail 1 Pressure - Data Valid but...
Page 495 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description 2363 1073 Amber Engine Engine Brake Actuator Circuit #2 – Voltage Below Compression Brake Normal, or Shorted to Low Source Output # 2 2365 Engine Brake Engine Brake Actuator Driver Output 3 Circuit - 1112 Amber Output # 3...
Page 496 REFERENCE Fault J1939 J1939 Lamp J1939 SPN Code Color Description Cummins Description 2963 Engine Coolant Temperature High - Data Valid but Engine Coolant None Above Normal Operational Range - Least Severe Temperature Level 2973 Amber Boost Pressure Intake Manifold Pressure Sensor Circuit - Data Erratic, Intermittent, or Incorrect 147649 Revision A...
Page 497: Cab Display Module (Cdm) Error Codes
REFERENCE 8.5 Cab Display Module (CDM) Error Codes NOTE: In the case of dual codes being shown for an item (primarily the solenoid valves), the ﬁrst code indicates a SHORT CIRCUIT condition, while the second code indicates an OPEN CIRCUIT condition. That is, E41 would be a SHORT in the Reel Aft solenoids (P55, P59), while E141 would indicate an OPEN circuit.
Page 498 REFERENCE Codes CDM Display Description E131 BYPASS VALVE P52 Bypass valve solenoid P52 fault detected E132 HEADER UP/DOWN P57 Header up / down solenoid P57, fault detected E133 SCREEN CLEANERS Screen cleaner output fault detected Right stop lamp output fault detected E134 RIGHT STOP LAMP E135...
Page 499 REFERENCE Codes CDM Display Description Error codes E73 to E100 not allocated E101 SPI ERROR J1939 Can error E102 CAN ERROR J1939 Can error E103 EEPROM READ ERROR Internal error E104 EEPROM WRITE ERROR Internal error E105 TEMP SENSOR ERROR Internal temperature sensor error 147649 Revision A...
Page 500: Cab Display Module (Cdm) And Windrower Control Module (Wcm) Fault Codes
REFERENCE 8.6 Cab Display Module (CDM) and Windrower Control Module (WCM) Fault Codes The CDM displays fault codes when there is a fault with one of the sensors that monitor and control windrower operation, to assist the Operator or Technician in locating a speciﬁc problem with the windrower. Refer to 8.5 Cab Display Module (CDM) Error Codes, page 481.
Page 501: Index
Index main disconnect switch ........369 maintaining ............ 369 A-Series headers removing ............373 A30-D belts auger speed ..........294 A/C compressor belt knife speed “on the go”........ 300 replacing ............ 367 reel speed ..........295 tensioning........... 367 A40-D alternator/fan belt auger speed ..........
Page 502 INDEX hay conditioner ..........112 header cut width ......... 109 D-Series headers header index mode ........107 attaching............213 hydraulic center-link ........101 header boots ........213, 280 hydraulic overload pressure ......106 deck shift ............291 knife overload speed ........103 setting ﬂoat options ........
Page 503 INDEX checking coolant strength ......353 draining coolant .......... 355 electrical radiator cap battery inspecting radiator cap ........ 353 adding electrolyte........372 engine error codes..........469 battery main disconnect switch ....369 engine operation boosting the battery........372 adjusting the throttle ........368 charging the battery ........
Page 504 INDEX installing secondary fuel ﬁlter ....... 348 levelling the header ........199 removing primary fuel ﬁlter......346 operating with a header removing secondary fuel ﬁlter ...... 348 A-Series header.......... 294 fuel speciﬁcations ........... 465 D-Series header.......... 279 fuel tank R-Series header.......... 302 draining the fuel tank ........
Page 505 INDEX air distribution ..........56 cab-forward mode controls ............57 ﬁeld.............. 49 fresh air ﬁlter element cleaning......326 road (optional) ..........51 fresh air intake ﬁlter ........325 engine-forward mode installing ﬁlter..........326 ﬁeld.............. 50 removing ﬁlter ..........325 ﬁeld lights heater shut-off valve .........
Page 506 INDEX checking ..........335 draper speed ..........212 general engine inspection ......332 driving the windrower........165 manually turning the engine ......333 operating with a header ........193 engine belt ............. 365 A-Series header.......... 294 engine compartment D-Series header.......... 279 opening and closing hood ......
Page 507 INDEX training seat ............. 46 D-Series header ..........282 windrower controls ........... 66 reel index ............282 windshield wiper..........54 reel minimum speed .......... 282 options and attachments ........447 reel speed AM/FM radio ..........447 A30-D header ..........295 automated steering.........
Page 508 INDEX electrical ............435 deﬁnitions ............29 engine ............429 starting the engine ..........160 header drive........... 437 cold start............162 hydraulics ............436 engine warm-up ..........162 operator’s station..........446 normal start............ 161 steering and ground speed control....441 steering.............
Page 510 10708 N. Pomona Avenue Kansas City, Missouri United States 64153-1924 t. (816) 891-7313 f. (816) 891-7323 MacDon Australia Pty. Ltd. A.C.N. 079 393 721 P.O. Box 243, Suite 3, 143 Main Street Greensborough, Victoria, Australia 3088 t. 03 9432 9982 f.
