HWAM Figaro Installation, Commissioning And Maintenance Instructions

Hide thumbs Also See for Figaro:

Operating instructions manual (23 pages)

User manual (36 pages)

Installation and user manual (52 pages)

Table Of Contents

See also: User Manual , Installer and User Manual

This manual must be used in conjunction with document

IN1173 The Wood and Mutlifuel Chimney and Installation Guide,

This Manual Must Always Be Available To The Stove Operator

IN1140

Installation, Commissioning and

Maintenance Instructions

Figaro

Vivaldi

Monet

Mozart

Hwam 30

Hwam 60

Beethoven

Ravel

Wood Models

Dali

Part No.

Model Name

Serial Number

E & OE

Instructions Part number IN1140 Ed A

Table of Contents

Need help?

Do you have a question about the Figaro and is the answer not in the manual?

Questions and answers

Summary of Contents for HWAM Figaro

Page 1 IN1140 Installation, Commissioning and Maintenance Instructions Figaro Vivaldi Monet Mozart Hwam 30 Hwam 60 Beethoven Ravel Dali Wood Models This manual must be used in conjunction with document IN1173 The Wood and Mutlifuel Chimney and Installation Guide, This Manual Must Always Be Available To The Stove Operator Part No.
Page 2: Technical Details
6” (153mm) * The Hwam models Beethoven, Vivaldi, Mozart, Ravel and Hwam 30 are considered as exempt for use in smoke control areas if they have been modified to ensure the air wash/secondary air control cannot be fully closed. If this modification has not been carried out the appliance is not considered exempt under the Clean Air Act.
Page 3 IMPORTANT  The installation of this appliance must comply with all local regulations, including those referring to national and European Standards before it can be operated. The stove is not suitable for a shared flue. However, for England and Wales, only, the coming into force on 1st April 2002 of SI 2002 No 440 exempts the householder from this legal requirement for the installation of solid fuel fired appliance whose rated heat output is 50kW or less in a building having no more than 3 storeys (excluding any basement) if a Competent Engineer is employed who is registered under the Registration Scheme for Companies and Engineers involved...
Page 4: The Model Range Explained
Our aims are to produce stoves with the latest innovations, user friendly operation and high efficiency for lower cost operation. This operation manual offers user information for the range of Figaro, Vivaldi, Monet, Mozart, Hwam 30, Hwam 60, Beethoven, Ravel and Dali.
Page 5 Grate Cover Plate Your HWAM stove is supplied with a loose cover plate for the riddling grate. This is a 3 mm thick steel plate. It is placed on top of the riddling grate and prevents the embers from falling into the ash pan. The cover plate is raised approx.
Page 6: Top To Rear Flue Conversion
Top to Rear Flue Conversion Top Flue Blanking Kit (Part No. AC004 for black finish, AC005 for grey finish) Middle Securing Plate Inner Blanking Plate Outer Blanking Plate Removal of the Rear Outlet Blanking Plate 1) Take off the rear back panel of the stove. 2) Take out the back vermicultie fire plate, to expose the nut on the inside of the rear blanking plate.
Page 7 Top to Rear Flue Conversion Fitting of the Top Flue Blanking Kit. 1) Place the inner blanking plate in the neck of the top flue outlet Inner blanking plate 2) Insert the middle securing plate so it sits directly above the inner blanking plate with either end underneath the top plate of the stove.
Page 8 Vertical cross-section of the Beethoven, Beethoven H, Monet, Monet H, Mozart, Ravel, Vivaldi, Hwam 30 & Hwam B1: Stoves without cooking section B2: Stoves with cooking section B3: Ravel Part Description and fitting Mica board back plate. Must be placed on the rear edge of the inside holders.
Page 9 Mounting of the cooking section. Before mounting the cooking section, the covers and the rings for the cooking holes should be removed, and the smoke outlet to the rear is closed. After this a new 5 mm rope seal gasket (8) is placed down into the flue outlet socket (drawing D1).
Page 10 Vertical cross-section of the Figaro Part Description and fitting Mica board fire box top baffle. Should rest on the back plate and the angled side plates. It should slot into the groove on the back plate. Upper secondary combustion baffle plate. Should rest on the air channel for secondary combustion, on the angled sides and against the front plate, and it should be pushed in as far back as possible.To reach the upper secondary combustion baffle plate, the lower secondary...
Page 11: Combustible Material
150mm to each side measuring from the closed door of the combustion chamber. The Hwam range of wood and multifuel stoves have been tested and conform to standards DIN18891 and DIN 18891-A1 where the hearth temperature does not exceed 100°C For further information on hearths of either glass, granite or slate visit our web site www.euroheat.co.uk...
Page 12: Installation Clearances
Installation Clearances Beethoven, Dali, Monet, Mozart, Ravel, Vivaldi, Hwam 30 & 60 and Figaro If the stove is to be installed into a fireplace recess the installation must comply to BS8303 1 to 3: 1994 Monet Beethoven, Beethoven H, Free Standing Installation...
Page 13: Fireplace Design
Fireplace Design Do not be tempted to fit the stove into an unsuitable fireplace. Beyond the requirements of Building Regulations and access to facilitate servicing the stove, providing a setting which will compliment a stove is not a luxury, it is the practicality of making the most of an investment. A good builder or fireplace specialist will be able to transform even the most utilitarian of fireplaces.
Page 14 Fresh Air System Instead of letting the air from the room into the stove for combustion, it is possible to take in fresh air from outside and introduce this directly via a duct into the back of the stove. Today, many modern dwellings are so airtight to conform with building regulations that it is an advantage to attach a fresh air intake to the stove.
Page 15: Flue Draught Measurement
Flue Draught Measurement A flue draught which is too low will result in the stove being difficult to light, responding only slowly to demands for increased output and unable to reach its full heating output. If this is the case rectification work of the chimney construction should be under taken.
Page 16: Water Heating
Water Heating It is the responsibility of the installer to ensure that the installation meets all the relevant regulations, requirements and recommendations. The following information is given for interest only and should not be used as a guide for installation. Pipe Work The primary circuit must be a gravity system, the domestic hot water storage cylinder and heat leak radiator should be positioned so as to provide a gravity circuit, with the flow and return pipes to be installed as...
Page 17: Maintenance Instructions
Maintenance Instructions Monet, Mozart, Dali, Beethoven, Vivaldi, Ravel, Hwam 30 and Hwam 60 Service inspection Your stove should be given a thorough service inspection once a year. This includes: • Thorough cleaning of the stove. • Adjusting handles and door.• Lubricating the hinges with copper grease.
Page 18 Loose Handles The handle on the door may loosen slightly after being used for some time. If this happens it can be easily tightened again. Loosen the Allen key screw (1) on the lower side of the handle with a 2.5 mm Allen key. Then tighten the central screw (2) on the handle with a 4 mm Allen key through the little hole inside the door.
Page 19 Maintenance Instructions Figaro Service inspection Your stove should be given a thorough service inspection once a year. This includes: • Thorough cleaning of the stove. • Adjusting handles and door. • Lubricating the hinges with copper grease. • Replacing springs in the automatic combustion system, where necessary.
Page 20: Hinge Adjustment
Hinge Adjustment All HWAM stoves are fitted with a Bauart 1 hinge system (self closing door). A self closing door is an option in the UK. The system can be adjusted for automatic or non automatic closing. List of items: 1.
Page 21: Commissioning Check List
Complete the Stoves Registration Form and Pass to User for Registration Euroheat and Hwam have a policy of continual research and development and reserve the right to modify its appliances without prior notice. We make every effort to ensure that the information provided in this document is correct and accurate at the time of printing.
