MeiTrack MT90 User Manual

Hide thumbs Also See for MT90:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
File Name
MEITRACK MT90 User Guide
Project
MT90
Sub Project

User Guide

Revision
V1.00
MEITRACK® MT90
User Guide
Creator
Cavana Cheung
Creation Date
Update Date
Page
Confidential
External Documentation
2011-05-16
2011-08-01
1 of 15

Advertisement

Table of Contents
loading

Related Manuals for MeiTrack MT90

Summary of Contents for MeiTrack MT90

  • Page 1: User Guide

    File Name MEITRACK MT90 User Guide Creator Cavana Cheung Project MT90 Creation Date 2011-05-16 Update Date 2011-08-01 Sub Project User Guide Page 1 of 15 Revision V1.00 Confidential External Documentation MEITRACK® MT90 User Guide...

  • Page 2: Table Of Contents

    Applications ..............................3 Product Function and Specifications ......................... 3 3.1 Product Function ............................3 3.2 Specifications ............................... 4 MT90 and Accessories ............................4 View .................................. 5 First Use ................................6 6.1 Install SIM Card ............................6 6.2 Charging ............................... 6 6.3 LED Indications .............................

  • Page 3: Copyright And Disclaimer

    Meiligao (MEITRACK), or transmitted in any form, either electronically or mechanically, including photocopying and recording. In no event shall Meiligao (MEITRACK) be liable for direct, indirect, special, incidental, or consequential damages (including but not limited to economic loss, personal injury, and loss of asset and property) arising out of the use or inability or illegality to use the product or documentation.

  • Page 4: Specifications

    File Name MEITRACK MT90 User Guide Creator Cavana Cheung Project MT90 Creation Date 2011-05-16 Update Date 2011-08-01 Sub Project User Guide Page 4 of 15 Revision V1.00 Confidential External Documentation  Low Battery Alarm  Speeding Alarm  Mileage Report 3.2 Specifications...

  • Page 5: View

    Long press for 2 seconds to turn on MT90. Button Long press for 2 seconds to turn off MT90. Press to wake MT90 up from sleep mode, power LED will slowly flash for 10 seconds. Mini USB Mini USB is used for charging, connecting to computer for setting up parameters, updating software and so on.

  • Page 6: First Use

    Make sure the SIM card has enough balance (it’s available to phone and SMS test). Make sure the SIM coded lock is turned off If you need to use the authorized number to call MT90, please make sure the SIM has the caller ID display function.

  • Page 7: Track By Calling

    No signal off) MT90 is connected to the GSM network 6.4 Track by Calling Make a call to MT90 and it will report with one SMS. For example, Now,110727 02:48,V,16,23Km/h,61%,http://maps.google.com/maps?f=q&hl=en&q=22.540103,114.082329 &ie=UTF8&z=16&iwloc=addr&om=1 Click on the link then the location can be shown directly on Google Maps on your mobile phone.

  • Page 8: Multiple Phone Numbers- A71

    If no preset phone number, it is empty (default is empty). Send command “0000, A71” to delete all phone numbers. When the SOS button is pressed, MT90 will make a call to phone number 1, 2 and 3. It will stop calling when one number answers.

  • Page 9: Sleep Mode- A73

    For more details regarding SMS commands, please refer to MEITRACK SMS Protocol. 6.5 Configure by Computer This part mainly shows you how to use the MEITRACK Parameter Editor. Please refer to the MEITRACK Parameter Editor User Guide for more information regarding configuration and...
  • Page 10 ‘Prolific USB-to-Serial Comm Port’ as the following picture shows. Note: Remember this Com number. It needs to be input into the MEITRACK Parameter Editor. It is COM3 in this example and it would be COM4 or COM5 in your computer.

  • Page 11: Sms Tracking

    Click ‘Read Settings’ button to show the default or previous settings of the tracker. Note: MEITRACK Parameter Editor is in the CD. The language will be automatically adjusted to be the same as your PC operation system’s language. Please use “Ctrl+L” to change the language.

  • Page 12: Sms Report

    A phone number to receive selected event’s SMS reports. Event Selected event’s SMS reports will be sent to authorize phone number. For more details, please refer to MEITRACK GPRS/SMS Protocol. For description of events from SOS/Input 1 Active to Tow Alarm, please refer to tap II GPRS Tracking.

  • Page 13: Gprs Tracking

    Report when MT90 exits Geo-fence. Geo-fence can be changed on tap III Main Settings. No GPS Signal Report when MT90 enters GPS fake zone or no GPS signal. Get GPS Signal Report when MT90 exits GPS fake zone or get GPS signal.
  • Page 14 Interval = 0, stop tracking by time interval. Max time interval = 65535*10 seconds GPRS Report Times = 0, report without limit. = [1,65535], set report times, MT90 will stop reporting when reaching the preset times. IP & Port Input server’s IP address and port number.
  • Page 15 Report when MT90 exits Geo-fence. Geo-fence can be changed on tap III Main Settings. No GPS Signal Report when MT90 enters GPS blind area or no GPS signal. Get GPS Signal Report when MT90 exits GPS blind area or get GPS signal.
