Summary of Contents for MeiTrack MT90
- Page 1 SHENZHEN MEILIGAO ELECTRONICS CO.,LTD. Address: 6/F, Cafu Plaza, No.5 Guihua Road, Futian Free Trade Area, Shenzhen +86(755) 8346 2818 Tel: +86(755) 8346 2061 Fax: Email:info@meitrack.com Revision: V1.8 Website: www.meitrack.net...
- Page 3 Choose a rate plan wisely: Your MT90 can use up Internet bandwidth quickly. Before you use your MT90, we strongly recommend that you talk to your mobile operator about data rates. If you’re on a standard data plan, the costs could really...
-
Page 4: Table Of Contents
Contents MT90 Applications MT90 Features MT90 Main Functions MT90 Specifications Inside the Box Your MT90 Getting Started Quick Operation Instruction Configuration by Computer Log on GPS Platform Safety Usage and Information Correct Disposal of Batteries of MT90 Copyright and Disclaimer... -
Page 5: Mt90 Applications
SiRF IV GPS and Quad Band GSM 850 / 900 / 1800 / 1900Mhz Small in Size (77x47x20mm) and Light in Weight (65g) Waterproof IP65 Low Power Consumption and Long Standby Time GPS and GSM Base Station of Bi-module Positioning Track by SMS / GPRS (MEITRACK Protocol) Inbuilt Accelerometer Sensor Inbuilt Battery... -
Page 6: Mt90 Main Functions
MT90 Main Functions Track on Demand Track by Time Interval Track by Distance Interval Two-way Audio Data Logger SOS Alarm Geo-fence Alarm GPS Blind Area Alarm Low Battery Alarm Speeding Alarm Mileage Report Listen-in (Voice Monitoring) MT90 Specifications Item Specifications... - Page 7 Item Specifications Operating Temperature C~55 Humidity 5%~95% Work Time 45 hours in power-saving mode and 14 hours in normal mode 2 LED lights to show power, GPS, GSM and other status Button 5 Buttons for making phone call and sending SMS Microphone/Speaker Internal microphone and speaker Memory...
-
Page 8: Inside The Box
Travel Adapter (Charger) Mini Screwdriver Lanyard User Manual, Warranty Manual and CD Soft Reminder: Use only Meitrack-approved software. Pirated or illeagal software may cause damage or malfunctions that are not covered by Meitrack’s warranty. The supplied accessories perform best for your device. -
Page 9: Your Mt90
Your MT90 Item Description GPS LED Flashlight Indicates GPS and battery status, please refer to (Blue) below LED Indications. GSM LED Flashlight Indicates GSM status, please refer to below LED (Green) Indications. - Page 10 SMS to the preauthorized phone number SOS Button and send GPRS message to the ser ver if GPRS function is enabled. Press to wake up if MT90 is in sleep mode. It will run automatically when using listen-in and call Microphone functions.
- Page 11 Item Description Long press for 2 seconds to turn on MT90. Power On / Off Long press for 2 seconds to turn off MT90. Button Press to wake MT90 up from sleep mode, power LED will slowly flash for 10 seconds.
- Page 12 L o n g p r e s s f o r 2 s e c o n d s a g a i n , w h e n t h e buzzer “BI” twice, GPRS function will be disabled automatically. Note: you can disable GPRS button through Meitrack Manager to avoid operating failure (default: valid). Lanyard Loop For connecting lanyard.
-
Page 13: Led Indications
LED Indications Long press the switch for 2 seconds to turn on / off MT90. GPS LED Flashlight (Blue) GSM LED Flashlight(Green) Charging A call is coming in or busy Flashing Sleeping (every 5 seconds) Flashing (every 5 Sleeping seconds) -
Page 14: Getting Started
Getting Started 1. Remove the Battery Cover With the device turned off, place your MT90 with the front facing down. Use the mini screwdriver to remove the two screws to release the back cover. Lift up the back cover from the notch at the bottom of the device. - Page 15 3. Insert the Micro SD Card Insert the Micro SD card into the slot with its gold contacts facing down and push it until it clicks into place. 4. Insert the Battery Insert the contacts side of the battery first and then gently push the battery cover into place.
- Page 16 5. Charge the Battery The battery is partially charged when shipped. Before using the device for the first time, it is recommended that you charge the battery for 8 hours. Connect one end of the USB cable to the device, and the other end of the USB cable to the USB port of the AC adapter.Please charge the battery for 8 hours for the first time by turning off the device.
- Page 17 7.Attach A lanyard Slide the lanyard through the slot and hook it over the small projection. Once you’ve installed your battery, SIM card and Micro SD card, you can turn on your device and start using it. When you turn on the device for the first time, you will be promoted to set up your device.
-
Page 18: Quick Operation Instruction
This location-tracking for knowing the current location of MT90, to ensure normal function of the GPS signal. Call the SIM card number embedded in MT90, hang up till the dial sound 2-3 times, as follows: If your phone does not support direct... - Page 19 IMEI, A71, OK Prompts successful, successfully set up SOS emergency communications number. When you press the SOS emergency button, MT90 will dial 3 function phone numbers. It will stop dialing when one number answers. Note: The default value is empty,if the function numbers are less than three while setting, it must be add ","to avoid setting failure.
- Page 20 Sent to the embedded SIM card numbers. IMEI, A72, OK Successfully set up monitor number. When the pre-set monitor number calls the MT90, the device will answer automatically and enter into the listening state. It will not emit any sound.
-
Page 21: Sleep Mode
The Content of Mobile Phone SMS: 0000, A73, sleep levels Sent to the embedded SIM card numbers. MT90 automatic reply SMS: IMEI, A73, OK Prompt successfully. To restart the Log or regular position, you must first cancel the sleep mode. - Page 22 After that, it will repeat above processes. MT9 0 c an enter sleep mode under movement , and movement c an' t wake MT90 from sleep mode. In any condition, the device will directly quit the sleep mode and back to nor mal wor king mode by SMS or G PRS c ommand to tur n of f the sleep mode.
-
Page 23: More Settings
IMEI, B35, OK Set up the time zone successfully. Note: This value is your MT90’s IMEI number. The device will send this data automatically and these numbers do not represent anything significant to the functionality of the tracker. Below the same applies. -
Page 24: Configuration By Computer
Protocol. Configuration by Computer This part mainly shows you how to use the Meitrack Manager. Please refer to the Meitrack Manager User Guide for more information regarding configuration and functions. Install the MT90 software of Meitrack Manager Find the software of Meitrack Manager from the CD. - Page 25 Connect MT90 with computer, and sync the setting of Meitrack Manager. Connect USB cable with the USB port in the computer, and connect the other end to the MT90 device.
- Page 26 Run ‘Meitrack Manager.exe’, it will detect Comm por t and read all MT90’s parameters automatically:...
- Page 27 SMS Tracking...
- Page 28 Items Descriptions The defaulted value 0000 of SMS password for sending SMS SMS Password commands by mobile phones. Default time of the tracker is GMT 480, you can use this to correct the trackers time to your local time for SMS report. minute = 0, GMT 0 (default);...
- Page 29 Report when backup battery’s voltage is below 3.5V. Low Battery Alarm SMS header defaulted as “Low Battery”. Report when MT90 speeds higher than the pre-set value. SMS Speeding Alarm header defaulted as “Speeding”. Enter Alarm: report when MT90 enters GPS Blind Area. SMS header defaulted as “No Fix”.
- Page 30 Enter Alarm: report when MT90 enters sleep mode. SMS header defaulted as “Enter Sleep”. Sleep Alarm Exit Alarm: report when MT90 exits sleep mode. SMS header defaulted as “Exit Sleep”. Distance Interval Report when MT90’s journey reaches pre-set distance. Distance is Alarm in meters.
- Page 31 Items Descriptions Authorize a phone number to make a silent call to the tracker. The tracker will answer the call automatically which allows the caller to listen to what is happening around the tracker. There is Monitor Phone No. no voice indication that the call is in progress. Phone Number: Max 2, 16 characters.
- Page 32 GPRS Tracking...
- Page 33 Items Descriptions Select TCP / UDP to enable GPRS communication. Close: Close GPRS upload time. TCP: TCP is a stable connection, it is recommended to use GPRS this model. UDP: UDP can save traffic and less stable. Note: GPRS connection is default as turn off. Input main server’s IP address and port number.
- Page 34 GPRS report. GPRS Time Zone minute = 0, GMT 0 (default); minute = [-32768,32767], set time difference in minutes to GMT. For more details on SMS or GPRS settings, please refer to MEITRACK SMS / GPRS Protocol.
-
Page 35: Log On Gps Platform
Geo-fence Control Receive and Display Alarms Report and Statistics Online Configuration For more information about our GPS platform, please refer to Meitrack Family Personal Edition User Guide. Please do not hesitate to email us at info@meitrack.com if you have any questions. -
Page 36: Safety Usage And Information
Safety and Usage Information Handle and dispose of batteries and chargers with care Use only Meitrack-approved accessories specially designed for your device. Incompatible accessories can cause serious injuries or damage to your device. Never place batteries or devices on or in heating devices, such as microwave ovens, stoves, or radiators. -
Page 37: Copyright And Disclaimer
The user manual may be changed without prior notification. This user manual, or any part thereof, may not be reproduced for any purpose whatsoever without the written authorization of Meiligao (MEITRACK), or transmitted in any form, either electronically or mechanically, including photocopying and recording.
