F TRIO NEBULIZER HANDSET ASSEMBLY
WARNING
The Trio Nebulizer Handset is not sterile. Clean and Disinfect the Trio
Nebulizer Handset before the first use. (see Section H for Cleaning and
Section I for Disinfecting). Inspect all parts to ensure they are clean and
are not visibly damaged. Do not use dirty or damaged parts.
1. The Medication Reservoir and the Aerosol Chamber are attached using
a "hinge". First, gently pull up on the tab of the Medication Reservoir
(Figure 5a). This will release the Aerosol Chamber so that you may open
it (Figure 5b). Ensure that the Inspiratory Valve is placed correctly in the
Aerosol Chamber (Figure 6a). If not, re-insert as shown (Figure 6b).
5
Figure
6a
Figure
6b
Figure
a
TAB
b
INSPIRATORY VALVE
INSPIRATORY VALVE
QUESTIONS ABOUT TRIO? 1-888-335-6946
2. Ensure that the Trio Electronic Nebulizer Aerosol Head is marked as
follows: Trio (Figure 7, blowout). Do not use other eFlow
®
Aerosol Heads in this device. Being careful to touch ONLY the plastic
outer ring of the Aerosol Head (Figure 7), press the two flexible plastic
tabs on the side of the Aerosol Head while firmly inserting it into the
Medication Reservoir (Figures 7a-7b). You should feel the plastic tabs
"grab" as you insert it. It is best to avoid touching the metal part of
the Aerosol Head with your fingers (Figure 8).
7
Figure
AEROSOL HEAD NAME
7a
Figure
7b
Figure
8
Figure
| 5
Technology
®
TABS
