4
USING A DMX512 CONTROLLER
4.1

BASIC ADDRESSING

Connect all of the units in series using standard DMX512 signal cable or the IP65 rated cable
provided.
Set the DMX512 address in the DMX menu.
It is possible to have the same DMX address or independent addresses for each fixture.
4.2

CHANNEL ASSIGNMENT

Note: This product have four DMX512 channel configuration:
STUDIO 1
CW
CW+D
STUDIO 1
4 USING A DMX512 CONTROLLER
and STUDIO 2
CHANNEL VALUE
1
0 255
2
0 255
CHANNEL VALUE
1
0 255
2
0 255
3
0 255
CHANNEL VALUE
1
0 255
2
0 255
CW , CW+D ,
FUNCTION
COOL WHITE
WARM WHITE
FUNCTION
MASTER DIMMER
COOL WHITE
WARM WHITE
FUNCTION
MASTER DIMMER
SAME AS STUDIO 2 CH4
10 2008.9.19
