Lutron Electronics Caseta Quick Start Manual

Wireless
quick-start guide
Plug-in lamp dimmer
Welcome—and thank you for purchasing a CasétaT
Wireless plug-in lamp dimmer.
Before you install the plug-in lamp dimmer,
please watch the installation video at
www.casetawireless.com/support
We hope you enjoy the convenience of CasétaT
Wireless!
Double your warranty
Love CasétaT Wireless dimmers? Have ideas
for making them better? Tell us what you think
and we'll extend your warranty by 1 year.
www.casetawireless.com/register
Contents supplied
Plug-in lamp dimmer
(PD-3PCL)
P/N 0301731 REV B
Works with energy efficient
dimmable light bulbs:
LED—up to 100 W
CFL—up to 100 W
Halogen—up to 300 W
Incandescent—up to 300 W
NOTE: You can mix and match dimmable LED
and CFLs as well as halogen and incandescent
light bulbs with CasétaT Wireless dimmers.
Dimmable LED and CFL light bulbs vary in
their dimming performance. If you're using these
bulbs and they flicker or turn off, please visit
www.casetawireless.com/lowend
for information on adjusting the dimmer for
best bulb performance.
For a complete list of compatible dimmable CFLs
and LEDs, please visit
www.casetawireless.com/bulblist
Compatible light bulbs include:
CreeR
BA19-08027OMF-12DE26-1U100
FeitR
A19/OM800/LED
PhilipsR
9290002268
9290002267
SylvaniaR
LED8A/DIM/F/827
Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg, PA 18036-1299, U.S.A.
Installing your lamp dimmer
1
Turn on the lamp
Turn on the lamp you want to control and unplug it.
2
Connect the lamp(s)
Plug the lamp cord into either side of the CasétaT
Wireless plug-in lamp dimmer.
If you want to control a second lamp turn it on
and plug it into the other side.
For advanced features, tips for using CasétaT Wireless
dimmers with CFLs and LEDs, the complete CasétaT
Wireless product line, and more, please visit
www.casetawireless.com/features
Using your CasétaT Wireless plug-in lamp dimmer
With a smartphone or tablet (Bridge required, sold separately)
The CasétaT Wireless plug-in lamp dimmer can be controlled from a smartphone
when used with the LutronR Smart BridgeT.
If you are using the dimmer and remote control with the LutronR Smart BridgeT
follow the instructions below.
Note: If you are using the dimmer and remote control with another
manufacturer's bridge, please refer to that manufacturer's instructions
for set-up.
1
Download the Lutron app
®
Search for "Lutron Caseta"
www.casetawireless.com/LutronApp
Apple is a trademark of Apple Inc., registered in the U.S. and other countries. AppStore is a service mark of Apple Inc.
2
Launch the Lutron app
® ®
The Lutron app will walk you through
®
setting up your devices.
Lutron
3
ALL
Use the Lutron app to complete remaining steps
®
Control
Add devices
three ways
• PicoR remotes
• Dimmers
• Shades
3
Plug in the lamp dimmer
Important note:
Use only with dimmable LED, dimmable CFL,
halogen, or incandescent lamps.
Do not exceed the total maximum wattage shown below:
Bulb Maximum Wattage
LED & CFL 100 W
or
Incandescent & Halogen 300 W
Important notes:
1. For indoor use only.
2. Operate between 32 ˚F (0 ˚C) and 104 ˚F (40 ˚C).
Warranty
For warranty information, please visit
www.casetawireless.com/warranty
Lutron
LutronR App
LutronR Smart BridgeT
Lutron
Schedule Connect
your lights while away
Using your controls
On
Brighter
Darker
Off
Plug-in lamp dimmer
On
Brighter
Favorite
Darker
Off
Pico remote control
®
(sold separately)
Device Ratings
Plug-in lamp dimmer
PD-3PCL
120 V~ 50/60 Hz
CAUTION
To avoid overheating and possible damage to other
equipment, do not use to control motor-driven appliances,
or transformer-supplied appliances.
Codes
Install in accordance with all national and local electrical codes.
FCC/IC Information
This device complies with part 15 of the FCC Rules and Industry Canada license-
exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation.
Modifications not expressly approved by Lutron Electronics Co., Inc. could void the
user's authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
Without a smartphone or tablet (Bridge not required)
Pairing the lamp dimmer and
PicoR remote control
(sold separately)
1
Press and hold "off" button on dimmer
Hold for 6 seconds
until LED
starts blinking.
2
Press and hold "off" button on remote
Hold for 6 seconds until
lights flash 3 times.
x3
Repeat steps to pair other PicoR remote
controls.
Troubleshooting
Symptoms Probable cause and action
Lamp does • Light bulb(s) burned out.
not turn on or
• Lamp is turned off.
lamp dimmer LED
• Lamp is not plugged in.
does not light up.
• Outlet is switched off.
Light does • The dimmer failed to pair
not respond with PicoR remote control;
to PicoR remote see Pairing the lamp dimmer
control. and PicoR remote control.
• The dimmer is already at the
light level the PicoR remote
control is sending.
• The PicoR remote control
is outside the 30 ft (9 m)
operating range.
• The PicoR remote control
battery is low.
• The PicoR remote control
battery is installed incorrectly.
• Bulbs turn off Verify bulbs are marked
while being dimmable and visit
dimmed. www.casetawireless.com/
lowend
• Bulbs turn on at
for information on adjusting
high light level
the dimmer for best
but do not turn
bulb performance.
on at a low
light level.
• Bulbs flicker
or flash when
dimmed to a low
light level.
Go to www.casetawireless.com/support for
additional troubleshooting suggestions.
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Changing the favorite light level
on the PicoR remote control
(optional, sold separately)
You can use the round "favorite"
button on the PicoR remote
control to recall a favorite light
Favorite
level. We've set it to 50%, but you
can change it to any level you like.
3
Set desired light level on dimmer
4
Press and hold "favorite" button on remote
Hold for 6 seconds until the
plug-in lamp dimmer LED
blinks twice. New favorite
level is now saved.
x2
Lutron, , and Pico are registered trademarks and Caséta and Smart Bridge
are trademarks of Lutron Electronics Co., Inc. Google and the Google logo are
registered trademarks of Google Inc., used with permission.
© 2014 Lutron Electronics Co., Inc.
P/N 0301731 REV B
