DIP Switch 7,8 are for Baud Rate (DEFAULT 2400)
9600
4800
2400
1200
DIP Switch 9 is for Protocol (DEFAULT Pelcod)
Pelco P
Pleco D
Setup Address, Protocol and Baud rate
for Remote Controller
Via remote controller you can control several cameras with
different address , protocol and baudrate (like address 1 is
Pelco P baudrate 9600 ,address 2 can be Pelco D baudrate 2400)
To setup remote controller protocol and baudrate for each
address you please use the following steps:
-connect cameras to the remote controller plug RS-485
-chose channel number by pressing the desire number on the
remote control
-press setup key for 3-5 seconds –screen will display number
and letter, for example D=24 ,this is display protocol and
baudrate of this address.
Letter refers to protocol:
D- Pelco D , P- Pelco P ,
Number means baudrate:
12 means baud rate 1200
24 means baud rate 2400
48 means baud rate 4800
96 means baud rate 9600
- to modify use Left & Right key for baudrate and Up & Down key
for protocol on the remote control
-press ENTER key to save it
For clean all setup and default setup remote controller press
C key.
Default setup- all address Pelco –D baudrate 2400
9
OFF ON
ON ON
OFF OFF
ON OFF
ON
OFF

Mechanical Specifications

Dome Type:
Effective Pixels:
Protocol:
Baudrate:
Address:
Pan Rotation:
Tilt Rotation:
Max Pan Speed:
Max Tilt Speed:
Preset speed:
Preset accuracy:
Preset points:
Pattern Tours:
Auto Scan:
Power-off memory:
Home position:
Zoom:
Communication:
Protection:
Operating:
Power:
EN EN
PA-Models
PI-Models
Indoor IR Indoor Anti-Vandal
PAL:500x582
Pelco-P/D
1200/2400/4800/9600 bps
0-255
360° Continues rotation
0°~90°
60°/Sec
30°/Sec
60°/Sec
±3°
32 Points
Programable 16 preset point
Programable preset number and dwell time / speed
Yes (Programable speed and left right limited point)
Current setting and state
(Include Pattern, Not include auto scan)
Yes (Programable auto come back home position)
Optical 3X
RS485 (+/-)
Indoor use
0°C ~ 60°C
12VDC 500mA
PZ-Models
Indoor/Outdoor Plastic Case
(M For Metal case)
100°/Sec
IP66 for outdoor use
(Wall Mount)
-5°C ~ 60°C
