EUROSTER 3000 – USER MANUAL
This thermostat has been designed to provide you with years of troublefree service. Proper
understanding of any product is the key to successfully using it. By spending only a few
moments reading through this manual, you will become acquainted with the many features
built into this thermostat.
Following the procedures listed within this manual will minimize the chance of damaging the
thermostat or any of the equipment it controls.
Take special notice of all as these contain important information and safety tips.
THERMOSTAT LOCATION
Proper location of the thermostat is very important to insure a comfortable temperature. Observe the
following general rules for best results.
1. The thermostat should be on the inside wall of a room that is often used, approx. 5 ft.
(1.5m) above the floor.
2. Avoid areas that exhibit unusual heating or cooling conditions such as in direct sunlight,
near a fireplace, stove, register, door, window, or stair well.
3. Be aware of furnishings which may block airflow or alter temperature such as: sofas,
chairs, bookcases, track lighting, lamps, stereo components, television sets.
4. Hot water pipes in the wall, a stove, refrigerator, or fireplace on the other side of a
prospective wall may affect the accuracy of your thermostat.
5. Locating any control in a damp area will cause corrosion, and shorten the life of the
control.
6. Do not install where air circulation is poor (ie. in a corner, or an alcove, or behind an
open door).
7. All construction work and painting should be complete before installing unit.
8. This thermostat does not require leveling.
To avoid electrical shock and to prevent damage to the furnace, air conditioner, and
thermostat, disconnect the power supply before beginning work. This can be done at
the fuse box, at the circuit breaker, or at the appliance.
While holding the thermostat face in the palm of your hand, press in on release button with
your thumb. Hold the base plate firmly with your other hand by placing your fingers in the
holes on the back of the thermostat. Keeping release button pressed in, swing thermostat
away from base.
Be careful not to drop the booy or to distub electronic parts. Leave the cover closed
or removed whole the booy from the base.
EUROSTER 3000
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROSTER 3000

Summary of Contents for EUROSTER 3000

  • Page 1 EUROSTER 3000 – USER MANUAL EUROSTER 3000 This thermostat has been designed to provide you with years of troublefree service. Proper understanding of any product is the key to successfully using it. By spending only a few moments reading through this manual, you will become acquainted with the many features built into this thermostat.
  • Page 2 EUROSTER 3000 – USER MANUAL You will need to remove the Base Plate to gain access to the Battery Compartment and jumper Section. While holding the thermostat face in the palm of your hand, press in on release button with you thumb.
  • Page 3 EUROSTER 3000 – USER MANUAL FEATURE The thermostat you have purchased is programmable type, which simply means it has a built in clock and can change it's temperature settings automatically throughout the day. This may be confusing at a glance, but there are some very good reasons why this may be desirable.
  • Page 4 EUROSTER 3000 – USER MANUAL chosen. Mode "5:2d" indicates to set up week days and weekends (Saturday and Sunday). Mode "7d" indicates to set up the day of the week and the programs for each day can be set up separately.
  • Page 5 EUROSTER 3000 – USER MANUAL After selecting the mode, you can press  key or wait for 10 seconds, then the thermostat automatically set, the day and time to SUDAY, 0:00, shows the current room temperature. APPLICATION This thermostat can be used for "Floor Heating System". This device should be installed and serviced by a qualified technician, and make sure that power has been disconnected before installation.
  • Page 6 EUROSTER 3000 – USER MANUAL Air temperature is higher than air sensor setting. ● (Either one of a.m. condition will turn off the heating immediately) Press and hold "NEXT" button 5 seconds, the LCD display will change to current floor heating 1.

  • Page 7: Clock Setting

    EUROSTER 3000 – USER MANUAL the floor temperature. Warning! Do not set thermostat at "Floor temperature mode" if the floor sensor cable is not installed. Under this circumstance, pressing the FLOOR SET button will not display any temperature reading; floor temperature will remain the factory default setting.
  • Page 8 EUROSTER 3000 – USER MANUAL Each subsequent press of the i button steps the display to the next period (P1, P2, P3,...) Each period contains a time and a temperature. The thermostat will change to that temperature at this time.

  • Page 9: Manual Operation Mode

    EUROSTER 3000 – USER MANUAL a balance between energy savings and comfort for most average people. For example: It's winter, the heating unit is running and has just brought the room temperature up to 21ºC. You have your new thermostat set to 21ºC and have not altered the preset differential.
  • Page 10 EUROSTER 3000 – USER MANUAL The  and  buttons are used to adjust the temperature. If no key is pressed for 10 seconds the Thermostat will change into HOLD MODE and display the current temperature. At any time you can return to the Program controlled mode by pressing HOLD or .

  • Page 11: Temporary Override

    EUROSTER 3000 – USER MANUAL TEMPORARY OVERRIDE A Temporary Override has been provided to allow you to temporarily change the temperature without altering the thermostat's program. The thermostat will use the new temperature setting during the duration of this program period. At the start of the next program period, the override will be cancelled and the thermostat will return to the temperatures stored within the program.

  • Page 12: Low Battery Indicator

    EUROSTER 3000 – USER MANUAL temperatures stored within the program. To activate Comfort Override press COMF button. Simply adjust the set temperature (Temp Set) using the  and  buttons. Press NEXT button the COMF. indicator will light up just as it does with comfort hours.
  • Page 13 EUROSTER 3000 – USER MANUAL As the batteries within your thermostat begin to weaken, you will notice the LCD display begin to dim. The thermostat will continue to function properly, however the display will become increasingly harder to see. The time, programs, and all modifications you have made to the differential, etc are saved by the batteries.
