DW megapix DWC-MB950TIR Instruction Manual page 52

WEBVIEWER*
S e t u p > E v e n t H a n d l e > E v e n t R u l e
T h e E v e n t R u l e p a g e i s u s e d t o d e f i n e a c t i o n s ( e . g . r e c o r d t o S D c a r d ) i n
r e s p o n s e t o t h e t r i g g e r i n g o f a n e v e n t ( e . g . m o t i o n d e t e c t i o n ) .
Action determines what action you would like the camera to perform once the selected trigger has
been detected. Select from the following options:
Digital Output – The camera will activate the digital output when the trigger set is detected. The
Digital Output option has a Duration parameter which relates to the length of time the digital
output should be triggered.
E-mail Notifications – The camera will send an e-mail notification to a set destination when the
trigger set is detected. See page 53 for more information on setting up e-mail notifications.
TCP Notification and HTTP Notification – The camera will send a TCP or HTTP Notification to a
determined server when a selected trigger is detected. These notification options have a
Message Text box where you can enter what text you would like to be sent with the notification
(Max 32 characters).
Snapshot – The camera will send a
snapshot image to a network storage
when the trigger selected has been
detected. The Snapshot will include a
total of three images: a Pre-Alarm
snapshot (3 seconds before the
alarm), the alarm snapshot, and a
post-alarm snapshot (3 seconds after
the alarm). See page 36 for
information on the snapshot settings.
Please note that available actions
depend on the trigger type. For example,
you will not be able to select to send an
e-mail notification on network loss.
Click SAVE in the main Event Rule
screen to save any changes.
5 2
