DW megapix DWC-MB950TIR Instruction Manual page 13

INSTALLATION*
12. You may also use the 2nd Video output located near the camera's lens for easy adjustment
during installation.
13. After adjusting the lens, remove a drying agent pack from one of the silver packages
stored inside the accessories package*.
14. Remove the sticker from the drying agent pack and insert it in the front under the lens as
shown in the image*.
15. Screw the front cover back on to the camera.
16. If using wide angle, shift the camera's hood back to avoid blocking the view. Loosen
screws and shift back or forward as necessary.
* The drying agent pack should be replaced each time the camera is opened (front or back).
Be sure to complete all work before inserting drying agent pack & replacing the cover.
Drying agent packs will become ineffective if exposed to open air for more than 10 minutes.
1 3
