WEBVIEWER*
F i r s t S t r e a m & S e c o n d S t r e a m
T h e M B 9 5 0 T I R s u p p o r t s m u l t i p l e s i m u l t a n e o u s s t r e a m s ( 4 p r o f i l e s )
The Streams can be switched from the camera's web viewer by selecting the corresponding
stream from the drop down menu in the Steam Control option.
The stream's current resolution and framerate information will be displayed in the information
section.
To setup the different streams:
a. Go to 'Setup' at the top right-hand corner of the screen. The setup menu will appear.
b. Go to Video/Audio > Video Settings
c. Select the number of profiles you would like to assign the camera.
d. All selected profiles will appear under the Quality Setting Section. Here you can modify each
steams' resolution, codec, bitrate, and max framerate.
e. Press 'Save' to save all settings.
See page 43 for more information.
* Option not available on DW
