DW megapix DWC-MB950TIR Instruction Manual page 35

WEBVIEWER*
S e t u p > S y s t e m > R e c o r d i n g / S n a p s h o t
T h e r e a r e 2 m e t h o d s o f r e c o r d i n g : E v e n t - T r i g g e r e d a n d C o n t i n u o u s
R e c o r d i n g . B o t h c a n b e u s e d s i m u l t a n e o u s l y . C y c l i c R e c o r d i n g o f f e r s
o p t i o n s f o r w h e t h e r t o o v e r w r i t e o l d r e c o r d i n g s w h e n s p a c e o n t h e s t o r a g e
r e a c h e s c a p a c i t y .
Event Triggered Recording- When recording is done via event triggers, Record Setting will define
how the recording is performed. Stream Source will only display currently enabled video profile
streams.
The pre-alarm and post-alarm buffer are defined in terms of size (MB). The min/max for the
settings are based on the stream's resolution & bit rate. So, if the stream source is a small
resolution size, then the pre-alarm and post-alarm min/max settings will be less than min/max
values for a high resolution stream.
Continuous Recording- Currently continuous recording only records to SD card. Checking
Recording Schedule will display the
scheduling settings which can be used
to define when continuous recording
should occur.
3 5
