User Guide
XX271-10-00
V9360-1 Series
Network Hemispheric Camera
Vicon Industries Inc.
Tel: 631-952-2288 Fax: 631-951-2288 Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
www.vicon-security.com
Document Number: 8009-8271-10-00
Issued: 215
Product specifications subject to change without notice.
Copyright © 2015 Vicon Industries Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V9360-1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon V9360-1 Series

Summary of Contents for Vicon V9360-1 Series

  • Page 1 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.

  • Page 2: Table Of Contents

    Table of Contents Overview ..........................2 Features ........................2 Package Contents ....................... 3 Dimensions ........................5 Connectors (Indoor Only)..................... 7 All-in-One Cable (Optional) ..................8 Function Cables (Outdoor Only) .................. 9 Camera Cabling ........................10 Power Connection ..................... 10 Ethernet Cable Connection ..................10 Waterproof Cable Connector ..................

  • Page 3: Overview

    Overview The V9360-1 Series Fisheye IP Camera is a high resolution surveillance solution that features 180° panoramic view (wall mount) or 360° panoramic view (ceiling mount) without blind spots. The camera supports 1080P streaming at 60 fps, which allows the videos to be viewed smoothly. Moreover, the Edge Dewarping function of the camera can dewarp the fisheye source images.

  • Page 4: Package Contents

    Package Contents Please check that the package contains the following items listed below. Indoor V9360-1 Fisheye IP Self-Tapping Screw Plastic Anchor Security Screw Camera (x3) (x3) (x1) Security Torx Power Terminal Quick Guide Block (x1) Function Cable (Optional) NOTE: The supplied self-tapping screws are for soft substance/material installation, such as wood.
  • Page 5 Outdoor V9360W-1 Fisheye Self-Tapping Screw Plastic Anchor Security Screw IP Camera (x3) (x3) (x1) Security Torx Power Terminal Quick Guide Block (x1) NOTE: The supplied self-tapping screws are for soft substance/material installation, such as wood. For other installation environments, such as cement wall, it is required to pre-drill and use plastic anchors before fastening the supplied self-tapping screws on the wall.

  • Page 6: Dimensions

    Dimensions The dimensions of the camera are shown below. Indoor...
  • Page 7 Outdoor...

  • Page 8: Connectors (Indoor Only)

    Connectors (Indoor Only) Loosen the security screws and open the cover to access the connectors. The diagram below shows the connectors on the camera. Definition for each connector follows. Connector Definition Remarks DC 12V DC 12V Reserved Power Power connection AC 24V 1 AC 24V AC 24V 2...

  • Page 9: All-In-One Cable (Optional)

    All-in-One Cable (Optional) Connector Definition Remarks Alarm Out + Alarm Out – Alarm In + Alarm In – Alarm connection/Two-way Alarm & Audio I/O audio transmission Audio Out Audio In Pink Audio In Audio I/O Two-way audio transmission Green Audio Out Alarm In –...

  • Page 10: Function Cables (Outdoor Only)

    Function Cables (Outdoor Only) Connector Definition Remarks Pink Audio In Audio I/O Two-way audio transmission Green Audio Out AC 24V – Black DC 12V – Power (DC 12V / AC 24V) Power connection (2-Pin Terminal Block) AC 24V + DC 12V + Alarm In –...

  • Page 11: Camera Cabling

    Camera Cabling Follow the instructions below to complete the cable connections. Power Connection For power connection, refer to section Connectors (Indoor Only) for the indoor models and section All in One Cable (Outdoor Only) for the outdoor models. Alternatively, users can power the camera by PoE if a Power Sourcing Equipment (PSE) switch is available.

  • Page 12: Waterproof Cable Connector

    Waterproof Cable Connector Follow the instructions below to waterproof the connectors of different types of cables. The supported cables are as shown below. All-in-One Cable All-in-One Cable IP66 RJ-45 Cable for the Indoor Models for the Outdoor Models (Outdoor Models Only) All-in-One Cable of the Indoor Models/Outdoor Models Follow the steps below to waterproof the connectors of the All-in-One cable.
  • Page 13 Step 2: Seal the end of the rubber coating of the All-in-One cable as indicated in the figure on the right. Be sure to use enough silicone gel to fill in the hose and wrap around each wire to guarantee waterproof function. IP66 RJ-45 Cable (Outdoor Models Only) For IP66 RJ-45 cable, use an RJ-45 IP66 plug for connection to prevent water damage.

  • Page 14: System Requirements

    System Requirements To configure and operate the IP camera via web browser, ensure the PC has a good network connection and meets system requirements as described below. Items System Requirement Minimum : ® 1. Intel Core™ i5-2430M @ 2.4 GHz 2.

  • Page 15: Access Camera

    Access Camera For initial access to the IP camera, users can search for the camera through the installer program, DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2: After its window appears, click on the <Device Search>...
  • Page 16 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password ADMIN 1234 NOTE: ID and password are case sensitive. NOTE: It is strongly advised that administrator’s password be altered for the security concerns.
  • Page 17 Once the DC Viewer is successfully installed, the Home page of the IP camera will be shown as in the figure below. Ceiling Mount Installed Camera...
  • Page 18 Wall Mount Installed Camera NOTE: For more details about the function buttons on the Home page, refer to the Software Guide (Menu Tree) manual in the supplied CD.

  • Page 19: Setup Video Resolution

    Setup Video Resolution Users can setup video resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under the path: Streaming> Video Format. The default video resolution of 5M and 6M models are shown as below. The default resolution varies with different Fisheye Correction types, Front End Correction (Edge Dewarping) and Back End Correction (Software Dewarping).

  • Page 20: Configuration Files Export/Import

    Configuration Files Export/Import To export/import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under the path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera.

  • Page 21: Tech Support Information

    Tech Support Information This chapter will introduce how to delete previously-installed DC Viewer in the PC and how to setup the Internet security. Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, it is necessary to remove the existing DC Viewer from the PC before accessing the IP camera.

  • Page 22: Setup Internet Security

    Setup Internet Security If ActiveX control installation is blocked, either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.

  • Page 23: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.

  • Page 24: Vicon Standard Equipment Warranty

    The warranty does not apply (a) to faulty and improper installation, maintenance, service, repair and/or alteration in any way that is not contemplated in the documentation for the product or carried out with Vicon consent in writing, operation adjustments covered in the operating manual for the product or normal...
  • Page 25 Except as provided in this written warranty and to the extent permitted by law, neither VIcon nor any affiliated shall be liable for any loss, (including loss of data and information), inconvenience, or damage, including, but not limited to, direct, special, incidental or consequential damages, resulting from the use or inability to use the Vicon product, whether resulting from breach of warranty or any other legal theory.
  • Page 26 Vicon Industries Inc. For office locations, visit the website: www.vicon-security.com...
