Maintain the Amigo II
Maintenance schedule
Task

Clean the Amigo II

Note: For information on cleaning and maintaining your printer, refer to your Everest Printer User Guide
or PrismPlus! Printer User Guide.

Everest Printer

To align your Everest Printer, refer to the following instructions.
Required tools:
T 25 Torx screwdriver
5/32" Allen wrench
1.
To power on the Amigo II, press the Amigo II power switch.
2.
Wait until the unit completes the initialization.
Tip: The Everest II Printer takes 1 to 2 minutes to complete the initialization.
3.
Prepare the unit for alignment.
a.
Manually move the lift arm to the top of the
Amigo II.
b.
To place a disc in the lift arm, press the
disc up into the Lift Arm while pressing the
disc release button.
c.
To open the print drawer, press the printer
button.
d.
Close and re-open the door of the Amigo II.
This releases the lift arm so you can
manually move it.
110654_G
Frequency
Once a week. Remove dust from Amigo II and surrounding work
area using a lint-free cloth.
Upon installation and again if the discs are not picked correctly from
the printer tray. Refer to the procedures below for more information.
Gripper
Disc Release Button
Amigo II
Lift
Arm
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMIGO II EVEREST and is the answer not in the manual?

Questions and answers

Related Manuals for Rimage AMIGO II EVEREST

Summary of Contents for Rimage AMIGO II EVEREST

  • Page 1 Amigo II Maintain the Amigo II Maintenance schedule Task Frequency Once a week. Remove dust from Amigo II and surrounding work Clean the Amigo II area using a lint-free cloth. Upon installation and again if the discs are not picked correctly from Align the printer the printer tray.
  • Page 2 Amigo II Align the printer. Slowly move the lift arm down until the disc just touches the print pad. Printer Button Lift Side to Side Alignment Print Holding Pins If the disc is not centered side to side on the print pad, align the printer side to side. Loosen the side to side screws.
  • Page 3 Amigo II PrismPlus printer To align your PrismPlus printer, refer to the following instructions. Required tools: T 25 Torx screwdriver 5/32” Allen wrench To power on the Amigo II, press the PrismPlus power switch and the Amigo II power switch. Wait for the unit to complete the initialization.
  • Page 4 Amigo II If the disc is not centered side-to-side on Side to Side Screws the print pad, align the printer side to side. Loosen the side to side screws. Slide the printer, not the drawer, until the side edges of the disc and printer pad are aligned.
