IEXT224-4PH-L
IEXT224-4PH-R
Long Reach POE Extenders
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IEXT224-4PH-L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CTC Union IEXT224-4PH-L

Summary of Contents for CTC Union IEXT224-4PH-L

  • Page 1 IEXT224-4PH-L IEXT224-4PH-R Long Reach POE Extenders...
  • Page 2 CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its products for any particular purpose, nor does CTC Union assume any liability arising out of the application or use of any product and specifically disclaims any and all liability, including without limitation any consequential or incidental damages.
  • Page 3 This document is the current official release manual. Contents are subject to change without prior notice. Please check CTC Union's website for any updated manual or contact us by E-mail at sales@ctcu.com. Please address any comments for improving this manual or to point out omissions or errors to marketing@ctcu.com.

  • Page 4: Table Of Contents

    Table of Contents 1. PRODUCT INTRODUCTION ......................5 1.1 D ............................5 ESCRIPTION 1.2 F ............................5 EATURES 1.3 S ..........................6 PECIFICATIONS 1.4 A ............................ 7 PPLICATIONS 1.5 R ......................8 EFERENCE ERFORMANCE 2. HW DESCRIPTION ........................... 9 2.1 O ............................

  • Page 5: Product Introduction

    IEXT224-4PH-R can supply power budget of 30W to each one of the four POE ports. IEXT224-4PH-L & IEXT224-4PH-R Long Reach PoE Extenders are an ideal POE extension solution for service providers to deploy networking applications in public areas that requires Wireless AP, IP Phones and IP Cameras.

  • Page 6: Specifications

    1.3 Specifications Standards Support: Hardware Interfaces:  VDSL2 ITU-T G.993.2  Terminal Block for Copper Port   BNC Female for Coaxial Port VDSL2 Profiles: 17a and 30a  4 x RJ-45 10/100Base-TX IEEE 802.3at POE Protocol Support Port  Transparent bridging to higher layer protocols 3 Position Dip Switch Operating Environment ...

  • Page 7: Applications

    1.4 Applications The solution works in pairs for point to point connectivity. It features IEXT224-4PH-L Long Reach PoE Extender (CO), the master unit at the central site that can transmit data and power over a single pair of telephone grade UTP wire up to 1,200m or coaxial cable up to 1,800 m.

  • Page 8: Reference Performance Data

    1.5 Reference Performance Data UTP – 24AWG Copper Wire Profile Asymmetrical Symmetrical Upstream Downstream Upstream Downstream Distance Line Rate Line Rate Line Rate Line Rate POE output power (Mbps) (Mbps) (Mbps) (Mbps) 300 m 30 W 400 m 20 W 600 m 15 W 800 m...

  • Page 9: Hw Description

    2. HW Description 2.1 Overview devices are Long Reach POE Extenders with four IEXT224-4PH-L & IEXT224-4PH-R 10/100Base-TX IEEE 802.3at POE Ports. This chapter shows the product outlook and Hardware interfaces. 2.2 Product Outlook CO Faceplate CPE Faceplate...

  • Page 10: Led Definition

    2.3 LED Definition The LED indicators could provide instant feedback to users; the behaviors of the LED are given in below table: LED Name Indicator/Color Condition Green-off No local input power Local PWR Green-on Local input power received Green-off No power is transmitted over VDSL interface Remote PWR Green-on Power is transmitted over VDSL interface...

  • Page 11: Power

    48VDC to 57VDC, terminal Block.  Output: - IEXT224-4PH-L (CO): Provide 96VDC output to VDSL Line (Remote Power Feeding) to support remote power to CPE. - IEXT224-4PH-R (CPE): Ethernet port provide 4-port POE PSE function to 802.3at (30W).

  • Page 12: 3-Position Dip Switch

    2.5 3-Position DIP Switch IEXT224-4PH-L & IEXT224-4PH-R are equipped with DIP Switch selection, which can allow users to select the parameters in order to meet the needs of different applications. The parameter options should be set identically on both CO and CPE sides.

  • Page 13: Regulatory Compliance

    3. Regulatory Compliance IEXT224-4PH-L & IEXT224-4PH-R are designed to comply with the following standards  CE  FCC Part 15 Class A  EN60950...
  • Page 14 This page is intentionally left blank.
