Introduction
VDTU2A‐104‐4PH are a pair of devices that support remote
power feeding to a non‐managed Fast Ethernet PoE (Power over
Ethernet) switch and provides Ethernet LAN extension up to
1.2km. Housed in a rugged metal chassis, the LAN extender
provides an excellent solution in IP surveillance networks to
extend both Ethernet and power over a simple single pair
telephone wire. Up to 4 remote IP cameras (or other PoE PD
devices) may be powered, with a maximum budget of 40 watts
PoE available, without the requirement to run any extra electrical
power lines. Standard operating temperature range is ‐20 to 50°C.
Features
• Local unit accepts universal AC power
• Remote power feeding eliminates the need for power service
at remote unit
• IP30 rugged metal housing
• 4 port with IEEE 802.3af/at PSE at remote (40W budget)
• Remote power feeding and data operate over one twisted
pair over up to 1200 meters
• Simple DIP switch setting to set and forget
• Twisted pair with auto polarity detection for easy installation
• Twisted pair connects with terminal block or RJ‐11.
Specifications
Ethernet Interface
• Connector: RJ‐45 (shielded)
• 4‐ports
• Auto MDI/MDI‐X
• Speed: 10/100Base‐TX (Auto)
• Duplex: Full/Half (Auto‐negotiation per IEEE802.3u)
• Supports IEEE802.3x Flow Control
• Store & Forward Switch
• Packet buffer: 1mb
• Standards: IEEE802.3, 802.3u, 802.3x, 802.3af, 802.3at
• MTU: 64~1522 bytes
sales@ctcu.com w w w . c t c u . c o m
Quick Installation Guide
VDTU2A‐104L‐4PH
VDTU2A‐104R‐4PH
Ethernet Extender with Remote Power Feeding PoE Switch
sales@ctcu.com
Specifications (cont.)
Power over Ethernet
• 4 PoE enabled ports, Alternate B Mode
• Supports IEEE802.3af 15.4watts PoE per port (40W budget)
• Supports IEEE802.3at 30watts PoE per port (40W budget)
• Positive (VCC+) pins 4,5 (54VDC ±1V)
• Negative (VCC‐) pins 7,8
Power
• Absolute input range: 90~264VAC (local unit only)
• Dual power inputs: No
• Connector: IEC ‐320 type C13
• Consumption: 74Watts maximum (with 40W for PoE)
Mechanical
• Water & Dust Proof : IP30 Protection
• Dimensions : 200 x 190 x 48mm (D x W x H) local unit
170 x 170 x 44mm (D x W x H) remote unit
• Mounting : Wall Mount (kits included)
• Weight : 1.3kg (local) and 1.01kg (remote)
Environmental
• Operating Temperature :
•
‐20°C ~ 50°C
• Storage Temperature: ‐20°C ~ 70°C
• Humidity : 5 ~ 95% (non‐condensing)
Certifications
• EMI: FCC Part 15 sub B class B, EN55022 Class B
• EMS: (Electromagnetic Susceptibility)
•
EN61000‐4‐5 (Surge) Level 3,Criteria B
