Summary of Contents for CTC Union VDTU2A-304
- Page 1 VDTU2A-304 VDSL2 Bridge LAN Extender with 4-Port Switch...
- Page 2 The information in this document has been checked carefully and is believed to be correct as of the date of publication. CTC Union reserves the right to make changes in the product of specification, or both, presented in this publication at any time without CTC Union assumes no responsibility or liability arising from the specification listed herein.
-
Page 3: Table Of Contents
Tables of Contents CHAPTER 1 INTRODUCTION..........................7 ..............................7 EATURES ............................... 8 PECIFICATION ..............................9 PPLICATIONS CHAPTER 2 HARDWARE INSTALLATION ......................10 2.1 F ............................... 10 RONT ANEL 2.2 R ................................. 11 ANEL 2.3 I ............................... 11 NSTALLATION CHAPTER 3 CONFIGURATION VIA WEB BROWSER ....................12 3.1 5 P ..................... - Page 4 3.6 S ..............................26 ECURITY ILTER 3.6.1 MAC ID Filter ..............................26 3.6.2 Firewall ................................26 3.7 VDSL S ..............................28 ETTING 3.7.1 Port Setting ..............................28 3.7.2 Mode Select ..............................28 APPENDIX I ............................... 29 Connector Architecture ............................29 APPENDIX II ..............................
-
Page 5: Chapter 1 Introduction
Chapter 1 Introduction CTC Union VDSL2 LAN Extender is a long reach Ethernet extender with four Ethernet ports and two phone jacks, in which one is for VDSL2 connection and the other is for POTS (Plain Old Telephone Service) connection. It has built-in POTS splitter to share the existing phone line with POTS eliminating the need for replacing the existing copper wiring. -
Page 6: Specification
Selectable target SNR margin: It has the ability to select fixed SNR margin value on 9 dB or 6db. The systems will maintain the SNR margin at their value across all usable loop length. The higher SNR value gets better line quality, but lower performance. 1.2 Specification VDSL2 standards ... -
Page 7: Applications
1.3 Applications VDSL2 LAN Extender Application... -
Page 8: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation This chapter shows the front panel and how to install the hardware. 2.1 Front Panel Please see the graphic below for the front panel: Front panel can be separated into six parts from left to right: (1) Power (2) System (3) Central Office... -
Page 9: Rear Panel
2.2 Rear Panel The rear panel of VDSL2 LAN Extender is where all of the connections are made. LAN Extender Connectors Description of VDSL2 DC-IN Power adaptor inlet: Input voltage 12VDC Ethernet (1,2,3,4) Four Ethernet10/100BaseT auto-sensing and auto-MDI/MDIX for Ethernet ports(RJ-45) PHONE This interface is for connecting phone line (RJ-11). -
Page 10: Chapter 3 Configuration Via Web Browser
Chapter 3 Configuration via Web Browser 3.1 5 Ports Smart Switch Web Controller Login There is no software required to install in order to access your web controller, and all you need is a browser. To login your management system, please open any browser, such as, Internet Explore, Firefox, etc., and go to “http://192.168.1.1”... - Page 11 After you complete the login process, a main page will be shown as the following photograph. In this page, there are five square icons on the top-right side to show current port status. In addition, you can explore more management options on the left-hand side.
-
Page 12: System
3.2 System 3.2.1 Authentication Configuration You can change login name and password in this page. After accomplish your modification, please press “Update” button to save the change. 3.2.2 System IP Configuration “System IP Configuration” shows IP configuration, such as, IP address, subnet mask and gateway. -
Page 13: Load Default Setting
Once you make your choice, please click on “Load” button to activate this option. 3.2.5 Firmware Upgrade You will be able to update your VDSL2 LAN Extender’s firmware in this page. Please request the password from CTC Union if you need to upgrade VDSL2 LAN Extender’s firmware. -
Page 14: Reset Device
3.2.6 Reset Device This page provides a way to restart your VDSL2 LAN Extender without turn off and on your VDSL2 LAN Extender’s power. Click on “Confirm” in order to restart your VDSL2 LAN Extender. 3.2.7 Config Backup/ Restore For backup option, click on “Download” and a file explore will be popped up. Then, choose the location you wish to store this backup file. -
Page 15: Port Management
3.3 Port Management 3.3.1 Port Configuration You are able to setup port configurations in this page and check which port to apply these settings (check all ports to apply all ports with the settings in once.). Press “Submit” to take effect on the new settings. All information will be updated to the status table. -
Page 16: Port Mirroring
3.3.3 Port Mirroring “Port Mirroring” page allows you to change mirror setups in two styles. Click on “Change Mirror Mode” to change mirror setup style. In order to accomplish port mirroring function, you need the following information. 1. Mirror Port: select a mirror port to monitor the traffic source. 2. -
Page 17: Bandwidth Control
Mode 2 In mode 2, you can choose either “Disable” or “Mirror source-destination pair” for “Mirror Mode”. In addition, you need to choose destination port and source Please click on “Update” to save the settings after you finish your port. -
Page 18: Broadcast Storm Control
3.3.5 Broadcast Storm Control In this section, you will be able to block excessive broadcast packets. Choose which port you wish to start this protection. Enable “Broadcast Storm” option to execute this function and give a value for “Threshold”. Broadcast packets will be dropped when broadcast packets number is more than threshold value. -
Page 19: Vlan
3.4 VLAN CTC Union VDSL2 LAN Extender provides two possible ways to set VLAN up, by Port base or by Tag base. If you choose to set up VLAN based on Port, the settings in Tag base will not be executed. -
Page 20: Tag Base Vlan
3.4.2 Tag base VLAN Click on “Tag base VLAN” link on the left-hand side to switch to this page. If you see “VLAN Mode” is still “Port Base”, then, click on “Change Mode” to switch to the correct mode. In setup area 1, you can choose VLAN number, and which port you want to add or remove a tag. -
Page 21: Qos Setting
3.5 QoS Setting 3.5.1 Priority Classification “Priority Classification” allow you to enable QoS function based on the selected priority mode. If you need to start QoS function, please make sure you visit this page first and enable the priority mode you wish to apply; otherwise, the QoS function will not be executed. -
Page 22: Port-Based Priority
Choose what kind of algorithm you wish to apply and press “Update” to save this setting. 3.5.3 Port-Based Priority Two items should be selected in order to set this priority up. 1. Port number: choose the port number you wish to apply this policy. 2. -
Page 23: Tos/Dscp Priority
3.5.5 TOS/DSCP Priority In this section, you can assign queue with a DSCP priority. Click on “Submit” and the information will be saved and updated to the table below. (Note: in order to allow QoS running TOS/DSCP priority, please make sure you change “Priority Classification” option to “TOS/DSCP Priority”... -
Page 24: Security Filter
3.6 Security Filter 3.6.1 MAC ID Filter Five MAC addresses can be stored in “MAC ID Filter”. Choose which entry number you wish to save this MAC and fill up its MAC address in “MAC Address setting” and its mode. Click on “Update”... - Page 25 1. Specific IP address Choose which entry you wish to add this set of data. In this mode, you need to provide specific IP addresses. Click “Submit” if you finish your modification. The data you just saved should be updated into the table in the upper part of this page. 2.
-
Page 26: Vdsl Setting
3.7 VDSL Setting 3.7.1 Port Setting In this section, you can change VDSL port settings. After you change the settings, click “Submit” to update your VDSL2 LAN Extender. Click “Refresh” to get the latest information of VDSL status. 3.7.2 Mode Select In “Mode Select”... -
Page 27: Connector Architecture
Appendix I Connector Architecture Ethernet Port Connector (RJ-45) The Ethernet Port interface is a 8 position Modular Jack. The table below displays the pin out assignments. Pin Number Assignment (MDI-X) Figure RX+; Receive data + RX-; Receive data - TX+; Transmit data + Not used Not used... -
Page 28: Chassis Accessory
Appendix II Chassis Accessory CTC Union also provides a Mini-Chassis solution for application on the rack in CO side. The major factor of FMC-CH08 is listed below: 2 U high Support 8-slot in one unit Two units of mini-chassis are able to fit into the 19-inch standard rack to support 16-slot in 2U height., as the illustration below... -
Page 29: Appendix Iii Faq
This will reset all the configurations of CTC Union VDSL2 LAN Extender. You will be able to login this machine with the default login information and default IP address. -
Page 30: Appendix Iv Terminology
Appendix IV Terminology Term Meaning Quality of Service Refers to resource reservation control mechanisms rather than the achieved service quality. QoS is the ability to provide different priority to different applications, users, or data flows, or to guarantee a certain level of performance to a data flow. (ref.
